Mazda CX5 Petrol Gearbox Mountain

KSh4,500.00
Mazda CX-5 Petrol Gearbox (Transmission) Mount Technical Specifications
Mount Assembly Specifications
    • Component Function: Rubber-metal or hydraulic-damped structural isolator securing the transaxle to the chassis subframe.
    • Mounting Locations: Left-side (driver-side) upper transaxle bracket (underneath battery tray) and rear lower torque strut mount (transaxle-to-crossmember).
    • OEM Materials: Cast aluminum or stamped steel housing bonded to high-damping natural rubber elastomer.
    • Aftermarket Performance Materials: TIG-welded steel housing with replaceable polyurethane bushings (62A to 95A Shore durometer).
    • OEM Unit Weight: 0.74 kg (1.63 lbs) (standard rubber-metal replacement).
    • Heavy-Duty Unit Weight: 2.27 kg (5.00 lbs) (billet/welded steel construction).
    • Design Service Life: 5 to 7 years (non-serviceable sealed elastomer unit).
OEM Part Number Reference Matrix
Chassis Generation Production Years Compatible Powertrain Mounting Position OEM Part Numbers
KE (1st Gen) 2012–2017 2.0L / 2.5L Skyactiv-G (AT/MT) Left (Transmission) GHR9-39-070, BBM5-39-070
KE / KF (1st & 2nd Gen) 2013–2025 2.0L / 2.5L Skyactiv-G (FWD/AWD) Rear (Torque Strut) BJS7-39-070
KF (2nd Gen) 2017–2025 2.0L / 2.5L / 2.5T Skyactiv-G (AT) Left (Transmission) K123-39-070, K123-39-070A
Supported Gearbox & Powertrain Specifications
    • Automatic Transaxle: 6-speed Skyactiv-Drive (FW6A-EL / GW6A-EL).
    • Manual Transaxle: 6-speed Skyactiv-MT (C66M-R / D66M-R).
    • Supported Petrol Engines: 2.0L Skyactiv-G (1,998 cc, 121 kW / 165 hp, 210 Nm) and 2.5L Skyactiv-G (2,488 cc, 139–143 kW / 187–192 hp, 252–257 Nm).
    • Automatic Fluid Specification: Mazda Original Oil ATF-FZ, 7.8 L total dry capacity.
    • Manual Fluid Specification: API GL-4 SAE 75W-80, 1.65 L (2WD) or 1.70 L (AWD).

Mazda Demio 2012 Axel Beam

KSh35,000.00
2012 Mazda Demio (DE Series) Axle Beam Technical Specifications
  • Suspension Type: Torsion beam (twist-beam) semi-independent rear suspension.
  • Beam Material: Welded, high-tensile U-shaped structural steel (serves as a built-in anti-sway bar).
  • Component Weight: Approximately 14 kg (bare beam axle).
  • Hub/Lug Bolt Pattern: 4-Hole (4x100 mm pitch circle diameter).
  • Brake Compatibility: Tailored for rear drum braking systems (standard FWD layout).
  • Bushing Style: Pressed-in rubber or polyurethane integrated cylindrical damping bushings.
  • Vehicle Wheelbase Track: Designed for a 2,490 mm wheelbase configuration with a rear wheel track of 1,455 mm. [1, 2, 3]
Genuine OEM Part Numbers
  • Standard FWD Rear Beam: D03P28B00A, DR61-28-B00A, DF71-28-B00B, D65128B00B
  • 4WD Variant Rear Beam: D03T28B00A
  • Compatible Model Codes: DBA-DE3FS, DBA-DEJFS, DBA-DE3AS, DBA-DE5FS [1, 2]

Mazda Demio 2013 Axel Beam

KSh35,000.00
2013 Mazda Demio (DE Series) Axle Beam Technical Specifications
  • Suspension Type: Torsion beam (twist-beam) semi-independent rear suspension.
  • Beam Material: Welded, high-tensile U-shaped structural steel.
  • Component Weight: Approximately 14 kg (bare beam axle).
  • Hub/Lug Bolt Pattern: 4-Hole (4x100 mm pitch circle diameter).
  • Brake Compatibility: Tailored for rear drum braking systems (standard 2WD layout).
  • Bushing Style: Pressed-in rubber or polyurethane integrated cylindrical damping bushings.
  • Vehicle Wheelbase Track: Designed for a 2,490 mm wheelbase configuration. [1, 2, 3, 4, 5, 6, 7]
Genuine OEM Part Numbers
  • Standard 2WD Rear Beam: D03P28B00A, DR61-28-B00A, DF71-28-B00B, D65128B00B
  • 4WD Variant Rear Beam: D03T28B00A
  • Compatible Model Codes: DBA-DEJFS, DBA-DE3FS, DBA-DE3AS

Mazda Demio 2014 Axel Beam

KSh35,000.00
Core Engineering Specifications
  • Suspension Layout Type: Torsion Beam (also referred to as Twist-Beam semi-independent suspension) [1, 2]
  • Structure Construction: High-tensile U-shaped tubular stamped steel profile designed to flex mechanically and eliminate independent rear sway bars. [1, 2]
  • Drive Configuration Compatibility: 2WD Rear Axle Setup default (Separate differential carrier subframes are utilized for rare 4WD e-4WD layouts). [1]
  • Brake System Interface: Engineered to mount standard trailing-leading type mechanical Drum Brake backplates. [1, 2]
Hub & Geometry Interfacing
  • Wheel Lug Stud Count (PCD Bolt Pattern): 4 Holes x 100 mm (4H)
  • Wheel Hub Housing Integration: Fits a four-bolt integrated hub-and-bearing flange cartridge system.
  • ABS Sensor Mapping: Includes integrated bracket tabs for active ABS wheel speed sensor wire routing looms. [1, 2, 3]
Hardware Part Numbers by Generation Profile
  • DE Series Generation (Production up to September 2014):
    • OEM Component Part Code: D651-28-15X (Sub-variations map up to suffix E) [1]
  • DJ Series Generation (Production from September 2014 Onward):
    • OEM Component Part Code: DA6A-28-B0XG (Features structurally reinforced chassis-bushing wings to address older DE cracking issues). [1, 2, 3]

Mazda Verisa Steering Rack

KSh12,000.00
Part Numbers & Identification
  • OEM Part Number (Standard Baseline): D521-32-110 / D521-32-110A / D521-32-110B
  • Alternative OEM Part Numbers: D350-32-110E, D521-32-960
  • Chassis Layout Codes: DBA-DC5W (2WD / Front-Wheel Drive), DBA-DC5R (e-4WD / 4x4)
  • Compatible Engine Format: 1.5L ZY-VE I4 [1, 2, 3, 4]
System Specifications
  • Operating Mode: Electric Power Steering (EPS) / Manual Gear type with Column Assist
  • Steering Gear Type: Rack and Pinion
  • Total Assembly Length: 1075 mm – 1076 mm
  • Total Rack Stroke: 157 mm
  • Number of Steering Wheel Turns (Lock-to-Lock): 2.9 turns
  • Input Shaft Diameter: 17.4 mm
  • Input Shaft Toothing/Splines: 36 Teeth
  • Axle Joint / Tie Rod Thread Size: M14 x 1.5
  • Minimum Vehicle Turning Radius: 4.9 meters [1, 2, 3]

Mazda Demio Model 2005 Steering Rack

KSh12,000.00
Part Numbers & Identification
  • OEM Part Number (Standard 2WD): D521-32-110, D52132110
  • Alternative OEM Part Numbers: D350-32-110C, DD32-32-110
  • Chassis Codes: DBA-DY3W, DBA-DY5W, LA-DY3W, LA-DY5W
  • Compatible Engine Formats: 1.3L ZJ-VE, 1.5L ZY-VE [1]
Electric Steering Rack Specs (JDM/Standard)
  • Operating Mode: Electric Power Steering (EPS) / Manual Gear type with Column Assist
  • Steering Gear Type: Rack and Pinion
  • Total Length: 1075 mm – 1076 mm
  • Total Rack Stroke: 157 mm
  • Number of Steering Wheel Turns (Lock-to-Lock): 2.9 turns
  • Input Shaft Diameter: 17.4 mm
  • Input Shaft Toothing: 36 Teeth
  • Axle Joint / Tie Rod Thread Size: M14 x 1.5 [1, 2]
Hydraulic Steering Rack Specs (Alternative/Euro Variant)
  • Operating Mode: Hydraulic Power Steering
  • Steering Gear Type: Hydraulic Rack and Pinion
  • Manufacturer Architecture: FoMoCo (Ford Motor Company) / JTEKT
  • Total Length: 1131 mm
  • Total Rack Stroke: 162 mm
  • Number of Steering Wheel Turns (Lock-to-Lock): 3.3 turns
  • Input Shaft Diameter: 18.3 mm
  • Hydraulic Port Line Entry Thread: M14 x 2
  • Hydraulic Port Line Exit Thread: M16 x 1.5
  • Axle Joint / Tie Rod Thread Size: M14 x 1.5 [1, 2]

Mazda Demio 2007-2014 Axel Beam

KSh35,000.00
Part Numbers & Identification
  • OEM Part Numbers (2WD Variants): D651-28-B00B, D521-28-B00A, DR61-28-B00A
  • OEM Part Number (4WD / e-4WD Variants): DA6A-28-B0XG
  • Ford Platform Reference: 8V51-5K952-CK (Shares global architecture with the Ford Fiesta Mark 7/WT series)
  • Chassis Layout Codes: DBA-DE3FS (1.3L 2WD), DBA-DE5FS (1.5L 2WD), DBA-DE3AS (1.3L 4WD), DBA-DEJFS (1.3L SkyActiv) [1, 2, 3, 4, 5]
Structural & Suspension Specs
  • Suspension Design Type: Twist-beam / Torsion beam rear axle assembly with integrated trailing arms.
  • Braking System Layout: Integrated mounting flanges for standard drum brake backplates (with ABS speed sensor routing provisions).
  • Spring Seat Configuration: Lower spring pans welded to the beam structural tube, optimized for linear barrel-type coil springs.
  • Damper Mounts: Single-bolt pin/clevis mount welded to the trailing arm configuration. [1, 2, 3]
Axle Bushing Dimensions
  • OEM Bushing Part Numbers: D651-28-460, DG80-28-460, DR61-28-460
  • Bushing Inside Diameter (ID): 17 mm
  • Bushing Outside Diameter (OD): 71 mm
  • Bushing Total Length (L): 78 mm
  • Composition: Vulcanized rubber-to-metal bonded hydraulic or solid isolation bushing.

Mazda CX3 Lower Control Arms

KSh6,000.00
Part Identification & Platform Fitment
    • OEM Right (Passenger Side) Part Number: D10E-34-300 (2015–2018) / D24H-34-300C (2018–2021) [1, 2]
    • OEM Left (Driver Side) Part Number: D10E-34-350 (2015–2018) / D24H-34-350C (2018–2021) [1, 2, 3]
    • Design Type: Triangular A-Arm / L-Shaped Lower Suspension Arm
    • Component Assembly: One-piece stamped high-tensile steel frame with pre-pressed inner horizontal pivot rubber bushing, an outer rear compliance vertical bushing, and a non-serviceable factory-integrated lower ball joint. [1, 2]
    • Drivetrain Compatibility: Direct replacement fitment for both Front-Wheel Drive (FWD) and All-Wheel Drive (AWD) variants across 1.5L TD, 1.8L TD, and 2.0L SkyActiv-G engines. [1, 2]
Component Construction & Mass Dimensions
    • Material Treatment: Electro-deposition (ED) coating/painting for anti-corrosion resistance
    • Average Shipping Weight: ~3.65 kg (8.05 lbs) per side
    • Ball Joint Stud Profile: Tapered pin, designed for a cross-axis pinch bolt fixing mechanism on the steering knuckle housing. [1]
Tightening Torque Specifications
    • Front (Horizontal Pivot) Bushing Bolt to Subframe: 97 to 116 N·m (72 to 85 ft-lbs)
    • Rear (Vertical Compliance Bushing) Retaining Bracket Bolts: 130 to 154 N·m (96 to 113 ft-lbs)
    • Lower Ball Joint Pinch Bolt to Steering Knuckle: 44 to 53 N·m (33 to 39 ft-lbs)
    • Front Anti-Roll / Stabilizer Bar End Link to Lower Arm Nut: 44 to 53 N·m (33 to 39 ft-lbs)

Mazda Demio Model 2014 Driveshafts

KSh6,500.00
OEM Part Numbers
  • Fourth Generation (DJ Series: DJ3FS / DJ5FS / DJ5AS – Late 2014 onwards):
    • Front Right Side (RHS / Long Shaft): FTD1-25-50XA / FTD1-25-50X
    • Front Left Side (LHS / Short Shaft): FTD1-25-60XA / FTD1-25-60X [1, 2, 3]
  • Third Generation (DE Series: DE3FS / DE5FS – Early 2014 production):
    • Front Right Side (RHS): F051-25-50X / FA81-25-500A
    • Front Left Side (LHS): F051-25-60X / FA80-25-600A [1]
Spline Counts & Joint Engagement
  • Fourth Generation (DJ Chassis):
    • External Toothing (Wheel/Hub Side): 26 Teeth
    • External Toothing (Differential/Gearbox Side): 31 Teeth (Automatic/SkyActiv-Drive) [1, 2]
  • Third Generation (DE Chassis):
    • External Toothing (Wheel/Hub Side): 25 Teeth
    • External Toothing (Differential/Gearbox Side): 24 Teeth (Manual) / 26 Teeth (CVT/Automatic) [1]
Dimensional Specifications
  • Fourth Generation (DJ Chassis):
    • Compressed Length (Right Hand / RHS): ~956 mm (includes integrated extension shaft profile)
    • Extension Shaft Length: 415 mm
    • Extension Bearing Outer Diameter: 70 mm
    • Extension Bearing Width: 25 mm [1, 2]
  • Third Generation (DE Chassis):
    • Compressed Length (Left Hand / LHS): ~590 mm to 620 mm
    • Compressed Length (Right Hand / RHS): ~915 mm to 920 mm
    • Wheel-Sided Joint Outer Diameter: 76 mm
    • Transmission-Sided Joint Outer Diameter: 78 mm to 80 mm
Material & Component Properties
  • Shaft Core Construction: Solid, high-tensile heat-treated induction-hardened chrome steel alloy. [1]
  • Dust Boots / Bellows: Premium, high-flexibility Neoprene or Chloroprene rubber compounds tailored for deep-angle torsional fatigue resistance. [1]
  • Lubrication System: Pre-packed internally with heavy-duty, high-temperature molybdenum disulfide (MoS2) friction-reducing lithium grease.

Mazda Demio Model 2013 Driveshafts

KSh6,500.00
OEM Part Numbers
  • Front Right Side (RHS / Long Shaft): F051-25-50X / FA81-25-500A / DG01-25-50X / D09V-25-50X (SkyActiv)
  • Front Left Side (LHS / Short Shaft): F051-25-60X / FA80-25-600A / DG01-25-60X / FA81-25-600B / D09V-25-60X (SkyActiv)
Spline Counts & Joint Engagement
  • External Toothing (Wheel/Hub Side): 25 Teeth
  • External Toothing (Differential/Gearbox Side):
    • Manual Transmission: 24 Teeth
    • CVT / Automatic / SkyActiv-Drive Variants: 26 Teeth
  • Wheel-Sided (Outboard) Joint Type: Ball-type Rzeppa joint
  • Transmission-Sided (Inboard) Joint Type: Tripod-type plunging joint
Dimensional Specifications
  • Compressed Length (Left Hand / LHS): ~590 mm to 620 mm (varies based on specific transmission pairing)
  • Compressed Length (Right Hand / RHS): ~915 mm to 920 mm (includes the integrated intermediate shaft assembly)
  • Wheel-Sided Joint Outer Diameter: 76 mm
  • Transmission-Sided Joint Outer Diameter: 78 mm to 80 mm
  • Hub Oil Seal Seat / ABS Ring Diameter: 54 mm
  • Hub Thread Size (Outer CV Stub): M22 x 1.5
Material & Component Properties
  • Shaft Core Construction: Solid, high-tensile induction-hardened chrome steel alloy.
  • Dust Boots / Bellows: High-durability Chloroprene or Neoprene rubber compound engineered for high-angle torsional stress.
  • Lubrication System: Pre-packed with heavy-duty, high-temperature lithium-based molybdenum disulfide (MoS2) friction-reducing grease.

Mazda Demio Model 2012 Driveshafts

KSh6,500.00
OEM Part Numbers
  • Front Right Side (RHS / Long Shaft): F051-25-50X / FA81-25-500A / DG01-25-50X / D09V-25-50X (SkyActiv)
  • Front Left Side (LHS / Short Shaft): F051-25-60X / FA80-25-600A / DG01-25-60X / FA81-25-600B / D09V-25-60X (SkyActiv) [1]
Spline Counts & Joint Engagement
  • External Toothing (Wheel/Hub Side): 25 Teeth [1, 2]
  • External Toothing (Differential/Gearbox Side):
    • Manual Transmission: 24 Teeth
    • CVT / Automatic / SkyActiv-Drive Variants: 26 Teeth
  • Wheel-Sided (Outboard) Joint Type: Ball-type Rzeppa joint [1]
  • Transmission-Sided (Inboard) Joint Type: Tripod-type plunging joint [1]
Dimensional Specifications
  • Compressed Length (Left Hand / LHS): ~590 mm to 620 mm (varies based on specific transmission pairing)
  • Compressed Length (Right Hand / RHS): ~915 mm to 920 mm (includes the integrated intermediate shaft assembly)
  • Wheel-Sided Joint Outer Diameter: 76 mm
  • Transmission-Sided Joint Outer Diameter: 78 mm to 80 mm
  • Hub Oil Seal Seat / ABS Ring Diameter: 54 mm
  • Hub Thread Size (Outer CV Stub): M22 x 1.5 [1]
Material & Component Properties
  • Shaft Core Construction: Solid, high-tensile induction-hardened chrome steel alloy.
  • Dust Boots / Bellows: High-durability Chloroprene or Neoprene rubber compound engineered for high-angle torsional stress.
  • Lubrication System: Pre-packed with heavy-duty, high-temperature lithium-based molybdenum disulfide (MoS2) friction-reducing grease.

Mazda Demio Model 2011 Driveshafts

KSh6,500.00
OEM Part Numbers
  • Front Right Side (RHS / Long Shaft): F051-25-50X / FA81-25-500A / DG01-25-50X / D09V-25-50X (SkyActiv)
  • Front Left Side (LHS / Short Shaft): F051-25-60X / FA80-25-600A / DG01-25-60X / D09V-25-60X (SkyActiv)
Spline Counts & Joint Engagement
  • External Toothing (Wheel/Hub Side): 25 Teeth
  • External Toothing (Differential/Gearbox Side):
    • Manual Transmission: 24 Teeth
    • CVT / Automatic / SkyActiv-Drive Variants: 26 Teeth
  • Wheel-Sided (Outboard) Joint Type: Ball-type Rzeppa joint
  • Transmission-Sided (Inboard) Joint Type: Tripod-type plunging joint
Dimensional Specifications
  • Compressed Length (Left Hand / LHS): ~590 mm to 620 mm (varies based on specific transmission type)
  • Compressed Length (Right Hand / RHS): ~915 mm to 920 mm (includes the integrated intermediate shaft assembly)
  • Wheel-Sided Joint Outer Diameter: 76 mm
  • Transmission-Sided Joint Outer Diameter: 78 mm to 80 mm
  • Hub Oil Seal Seat / ABS Ring Diameter: 54 mm
  • Hub Thread Size (Outer CV Stub): M22 x 1.5
Material & Component Properties
  • Shaft Core Construction: Solid, high-tensile induction-hardened chrome steel alloy.
  • Dust Boots / Bellows: High-durability Chloroprene or Neoprene rubber compound engineered for high-angle torsional stress.
  • Lubrication System: Pre-packed with heavy-duty, high-temperature lithium-based molybdenum disulfide (MoS2) friction-reducing grease.

Mazda Demio Model 2010 Driveshafts

KSh6,500.00
OEM Part Numbers
  • Front Right Side (RHS / Long Shaft): F051-25-50X / FA81-25-500A / DG01-25-50X
  • Front Left Side (LHS / Short Shaft): F051-25-60X / FA80-25-600A / DG01-25-60X
Spline Counts & Joint Engagement
  • External Toothing (Wheel/Hub Side): 25 Teeth
  • External Toothing (Differential/Gearbox Side):
    • Manual Transmission (5-Speed): 24 Teeth
    • CVT / Automatic Variants: 26 Teeth
  • Wheel-Sided (Outboard) Joint Type: Ball-type Rzeppa joint
  • Transmission-Sided (Inboard) Joint Type: Tripod-type plunging joint
Dimensional Specifications
  • Compressed Length (Left Hand / LHS): ~590 mm to 620 mm (varies based on specific transmission type)
  • Compressed Length (Right Hand / RHS): ~915 mm to 920 mm (includes the integrated intermediate shaft assembly)
  • Wheel-Sided Joint Outer Diameter: 76 mm
  • Transmission-Sided Joint Outer Diameter: 78 mm to 80 mm
  • Hub Oil Seal Seat / ABS Ring Diameter: 54 mm
  • Hub Thread Size (Outer CV Stub): M22 x 1.5
Material & Component Properties
  • Shaft Core Construction: Solid, high-tensile induction-hardened chrome steel alloy.
  • Dust Boots / Bellows: High-durability Chloroprene or Neoprene rubber compound engineered for high-angle torsional stress.
  • Lubrication System: Pre-packed with heavy-duty, high-temperature lithium-based molybdenum disulfide (MoS2) friction-reducing grease.

Mazda Demio Model 2009 Driveshafts

KSh6,500.00
OEM Part Numbers
  • Front Right Side (RHS / Long Shaft): F051-25-50X / FA81-25-500A / DG01-25-50X
  • Front Left Side (LHS / Short Shaft): F051-25-60X / FA80-25-600A / DG01-25-60X
Spline Counts & Joint Engagement
  • External Toothing (Wheel/Hub Side): 25 Teeth
  • External Toothing (Differential/Gearbox Side):
    • Manual Transmission (5-Speed): 24 Teeth
    • CVT / Automatic Variants: 26 Teeth
  • Wheel-Sided (Outboard) Joint Type: Ball-type Rzeppa joint
  • Transmission-Sided (Inboard) Joint Type: Tripod-type plunging joint
Dimensional Specifications
  • Compressed Length (Left Hand / LHS): ~590 mm to 620 mm (varies based on specific transmission type)
  • Compressed Length (Right Hand / RHS): ~915 mm to 920 mm (includes the integrated intermediate shaft assembly)
  • Wheel-Sided Joint Outer Diameter: 76 mm
  • Transmission-Sided Joint Outer Diameter: 78 mm to 80 mm
  • Hub Oil Seal Seat / ABS Ring Diameter: 54 mm
  • Hub Thread Size (Outer CV Stub): M22 x 1.5
Material & Component Properties
  • Shaft Core Construction: Solid, high-tensile induction-hardened chrome steel alloy.
  • Dust Boots / Bellows: High-durability Chloroprene or Neoprene rubber compound engineered for high-angle torsional stress.
  • Lubrication System: Pre-packed with heavy-duty, high-temperature lithium-based molybdenum disulfide (MoS2) friction-reducing grease.

Mazda Demio Model 2008 Driveshafts

KSh6,500.00
OEM Part Numbers
  • Front Right Side (RHS / Long Shaft): F051-25-50X / FP01-25-500B / FA81-25-500A
  • Front Left Side (LHS / Short Shaft): F051-25-60X / FA80-25-600A [1]
Spline Counts & Joint Engagement
  • External Toothing (Wheel/Hub Side): 25 Teeth
  • External Toothing (Differential/Gearbox Side):
    • Manual Transmission (5-Speed): 24 Teeth
    • CVT / Automatic Variants: 26 Teeth
  • Wheel-Sided (Outboard) Joint Type: Ball-type Rzeppa joint
  • Transmission-Sided (Inboard) Joint Type: Tripod-type plunging joint
Dimensional Specifications
  • Compressed Length (Left Hand / LHS): ~590 mm to 620 mm (varies slightly by specific transmission type)
  • Compressed Length (Right Hand / RHS): ~915 mm to 920 mm (models utilizing integrated intermediate bearing bracket supports)
  • Wheel-Sided Joint Outer Diameter: 76 mm
  • Transmission-Sided Joint Outer Diameter: 78 mm to 80 mm
  • Hub Oil Seal Seat / ABS Ring Diameter: 54 mm
  • Hub Thread Size (Outer CV Stub): M22 x 1.5
Material & Component Properties
  • Shaft Core Construction: Solid, high-tensile induction-hardened chrome steel alloy.
  • Dust Boots / Bellows: High-flexibility Chloroprene or Neoprene rubber compound formulated for high-angle torsional stress.
  • Lubrication System: Pre-packed with heavy-duty, high-temperature lithium-based molybdenum disulfide (MoS2) friction-reducing grease.

Mazda Demio Model 2007 Driveshafts

KSh6,500.00
OEM / Reference Part Numbers
  • Third Generation (DE3FS / DE5FS – 1.3L ZJ / 1.5L ZY engines with CVT or Manual):
    • Front Right Side (RHS): FA81-25-500A / F051-25-50X
    • Front Left Side (LHS): FA80-25-600A / F051-25-60X
  • Second Generation (DY3W / DY5W – 1.3L / 1.5L FWD variants):
    • Front Right Side (RHS): D351-25-50X
    • Front Left Side (LHS): D351-25-60X
Spline Counts & Joint Engagement
  • External Toothing (Wheel/Hub Side): 25 Teeth [1]
  • External Toothing (Differential/Gearbox Side):
    • DE Series (Third Gen): 24 Teeth (Manual) / 26 Teeth (CVT/Auto variants)
    • DY Series (Second Gen): 26 Teeth [1]
  • Wheel-Sided (Outboard) Joint Type: Ball-type Rzeppa joint
  • Transmission-Sided (Inboard) Joint Type: Tripod-type plunging joint [1]
Dimensional Specifications
  • Compressed Length (Left Hand / Short Side): ~590 mm to 640 mm (varies slightly by transmission pairing)
  • Compressed Length (Right Hand / Long Side): ~919 mm (models utilizing intermediate bearing supports extend up to this bracket profile)
  • Wheel-Sided Joint Diameter: 72.8 mm to 76 mm
  • Transmission-Sided Joint Diameter: 75 mm to 80 mm
  • Hub Oil Seal/ABS Ring Seat Diameter: 53.7 mm to 54 mm
  • Hub Thread Size (Outer CV Stub): M22 x 1.5 [1, 2, 3]
Material & Component Properties
  • Shaft Body: Solid, high-tensile heat-treated chrome steel alloy.
  • Dust Boots / Bellows: High-flexibility Chloroprene or Neoprene rubber compound built to withstand high torsional fatigue.
  • Lubrication: Pre-packed with heavy-duty, high-temperature molybdenum disulfide (MoS2) grease. [1]

Mazda Demio Model 2018 Crossmember Mountain

KSh4,000.00
Component Overview & Construction
  • Component Type: Front Suspension Axle Subframe Member / Engine Carrier Support Cradle.
  • Material Composition: Stamped high-tensile structural steel.
  • Mounting Design: Multi-point isolated perimeter layout containing factory press-fitted, high-density elastomer damping rubber bushings.
Part Numbers & Identifiers
  • Primary OE/OEM Reference: DA6A-34-80X (or DA6A3480X).
  • Alternative / Factory Variation Numbers: DA6A-34-800, DB2R-34-80X, DB2R3480X.
  • Component Interchange Warning: The crossmember layout changed between generations. A front crossmember from the prior generation (DE Series) will not interchange with the 2018 DJ Series vehicle.
Platform & Vehicle Compatibility
  • Chassis Platform: Mazda DJ Platform (SkyActiv-Chassis architecture).
  • Model Codes: DJ3FS, DJ5FS, DJ3AS, DJ5AS, DJLFS.
  • Model Range Variants: Demio 13C, 13S, XD, Touring, Touring L Package, and 15MB.
  • Production Range: 2014–2019 (Japan-market Demio nameplate, later renamed globally as the MAZDA2).
  • Cross-Brand Footprint: Shares basic structural architecture and mounting geometric parameters with the Toyota Yaris iA / Scion iA (North American variants co-developed on this SkyActiv platform).
Powertrain & Alignment Specifications
  • Compatible Engine Applications: 1.3L Petrol (P3-VPS), 1.5L Petrol (P5-VPS), and 1.5L SkyActiv-D Clean Diesel (S5-DPTS / S5-DPTR).
  • Drivetrain Constraints: Configured for Front-Wheel Drive (FF) models, with altered structural clearances on the "AS" suffix all-wheel-drive (4WD / AWD) chassis codes.
  • Baseline Alignment Settings (Unladen Member Geometry):
    • Camber: -0°05' (Acceptable factory tolerance: -1°05' to +0°55')
    • Caster: 4°20' (Acceptable factory tolerance: 3°20' to 5°20')
    • Total Toe-In: 1.0 mm to 3.0 mm
Tightening Torque Specifications
  • Main Subframe-to-Chassis Structural Bolts: 115 Nm to 140 Nm {85 to 103 ft-lbs} (Two-stage torque-to-yield tracking on primary frame mounting layers).
  • Steering Rack Gearbox to Subframe Connecting Bolts: 75 Nm to 104 Nm {56 to 76 ft-lbs}.
  • Sway Bar Center Bracket-to-Crossmember Fasteners: 33 Nm to 42 Nm {24 to 31 ft-lbs}.
  • Lower Control Arm Rear Pivot Bolt (Large Bushing): 135 Nm to 160 Nm {100 to 118 ft-lbs}.

Mazda Demio Model 2017 Crossmember Mountain

KSh4,000.00
Component Overview & Construction
  • Component Type: Front Suspension Axle Subframe Member / Engine Carrier Support Cradle.
  • Material Composition: Stamped high-tensile structural steel.
  • Mounting Design: Multi-point isolated perimeter layout containing factory press-fitted, high-density elastomer damping rubber bushings.
Part Numbers & Identifiers
  • Primary OE/OEM Reference: DA6A-34-80X (or DA6A3480X).
  • Alternative / Factory Variation Numbers: DA6A-34-800, DB2R-34-80X, DB2R3480X.
  • Component Interchange Warning: The crossmember layout changed between generations. A front crossmember from the prior generation (DE Series) will not interchange with the 2017 DJ Series vehicle.
Platform & Vehicle Compatibility
  • Chassis Platform: Mazda DJ Platform (SkyActiv-Chassis architecture).
  • Model Codes: DJ3FS, DJ5FS, DJ3AS, DJ5AS, DJLFS.
  • Model Range Variants: Demio 13C, 13S, XD, Touring, Touring L Package, and 15MB.
  • Production Range: 2014–2019 (Japan-market Demio nameplate, later renamed globally as the MAZDA2).
  • Cross-Brand Footprint: Shares basic structural architecture and mounting geometric parameters with the Toyota Yaris iA / Scion iA (North American variants co-developed on this SkyActiv platform).
Powertrain & Alignment Specifications
  • Compatible Engine Applications: 1.3L Petrol (P3-VPS), 1.5L Petrol (P5-VPS), and 1.5L SkyActiv-D Clean Diesel (S5-DPTS / S5-DPTR).
  • Drivetrain Constraints: Configured for Front-Wheel Drive (FF) models, with altered structural clearances on the "AS" suffix all-wheel-drive (4WD / AWD) chassis codes.
  • Baseline Alignment Settings (Unladen Member Geometry):
    • Camber: -0°05' (Acceptable factory tolerance: -1°05' to +0°55')
    • Caster: 4°20' (Acceptable factory tolerance: 3°20' to 5°20')
    • Total Toe-In: 1.0 mm to 3.0 mm
Tightening Torque Specifications
  • Main Subframe-to-Chassis Structural Bolts: 115 Nm to 140 Nm {85 to 103 ft-lbs} (Two-stage torque-to-yield tracking on primary frame mounting layers).
  • Steering Rack Gearbox to Subframe Connecting Bolts: 75 Nm to 104 Nm {56 to 76 ft-lbs}.
  • Sway Bar Center Bracket-to-Crossmember Fasteners: 33 Nm to 42 Nm {24 to 31 ft-lbs}.
  • Lower Control Arm Rear Pivot Bolt (Large Bushing): 135 Nm to 160 Nm {100 to 118 ft-lbs}.

Mazda Demio Model 2016 Crossmember Mountain

KSh4,000.00
Component Overview & Construction
  • Component Type: Front Suspension Axle Subframe Member / Engine Carrier Support Cradle.
  • Material Composition: Stamped high-tensile structural steel.
  • Component Weight: Approximately 11.0 kg to 14.6 kg (depending on specific factory underbody guarding and regional market specs).
  • Mounting Design: Multi-point isolated perimeter layout containing factory press-fitted, high-density elastomer damping rubber bushings. [1, 2, 3]
Part Numbers & Identifiers
  • Primary OE/OEM Reference: DA6A-34-80X (or DA6A3480X).
  • Alternative / Factory Variation Numbers: DA6A-34-800, DB2R-34-80X, DB2R3480X.
  • Component Interchange Warning: The crossmember layout changed between generations. A front crossmember from the prior generation (DE Series) will not interchange with the 2016 DJ Series vehicle. [1, 2, 3]
Platform & Vehicle Compatibility
  • Chassis Platform: Mazda DJ Platform (SkyActiv-Chassis architecture).
  • Model Codes: DJ3FS, DJ5FS, DJ3AS, DJ5AS, DJLFS.
  • Model Range Variants: Demio 13C, 13S, XD, Touring, Touring L Package, and 15MB.
  • Production Range: 2014–2019 (Japan-market Demio nameplate, later renamed globally as the MAZDA2).
  • Cross-Brand Footprint: Shares basic structural architecture and mounting geometric parameters with the Toyota Yaris iA / Scion iA (North American variants co-developed on this SkyActiv platform). [1, 2, 3]
Powertrain & Alignment Specifications
  • Compatible Engine Applications: 1.3L Petrol (P3-VPS), 1.5L Petrol (P5-VPS), and 1.5L SkyActiv-D Clean Diesel (S5-DPTS / S5-DPTR). [1]
  • Drivetrain Constraints: Configured for Front-Wheel Drive (FF) models, with altered structural clearances on the "AS" suffix all-wheel-drive (4WD / AWD) chassis codes. [1]
  • Baseline Alignment Settings (Unladen Member Geometry):
    • Camber: -0°05' (Acceptable factory tolerance: -1°05' to +0°55')
    • Caster: 4°20' (Acceptable factory tolerance: 3°20' to 5°20')
    • Total Toe-In: 1.0 mm to 3.0 mm
Tightening Torque Specifications
  • Main Subframe-to-Chassis Structural Bolts: 115 Nm to 140 Nm {85 to 103 ft-lbs} (Two-stage torque-to-yield tracking on primary frame mounting layers).
  • Steering Rack Gearbox to Subframe Connecting Bolts: 75 Nm to 104 Nm {56 to 76 ft-lbs}.
  • Sway Bar Center Bracket-to-Crossmember Fasteners: 33 Nm to 42 Nm {24 to 31 ft-lbs}.
  • Lower Control Arm Rear Pivot Bolt (Large Bushing): 135 Nm to 160 Nm {100 to 118 ft-lbs}.

Mazda CX5 Petrol Model 2015 Gearbox Mountain

KSh4,000.00
Part Numbers & Interchanges
  • OEM Part Numbers: GHR9-39-070, GHR9-39-070A, KD45-39-070A, KR11-39-070A
  • Aftermarket Cross-References: A4438, SKMA4438, 9813
Physical & Material Specifications
  • Mounting Type: Rubber-to-Metal Insulator Mount (Elastomer dampened, solid rubber core)
  • Chassis Bracket Material: Heavy-duty Stamped Steel / Cast Aluminum
  • Fitting Position: Left Front (Engine/Gearbox Left Side Bay, structurally positioned beneath the air intake box, ECU assembly, and battery tray)
  • Inner Bushing Diameter: 14 mm to 15 mm
  • Average Mount Width: 75 mm
  • Average Weight: Approx. 0.96 kg to 1.1 kg (insulator core only)
Installation Torque Specifications
  • Chassis Mounting Bolts (19mm socket): 131 – 153 N·m (96 – 113 lb-ft)
  • Transmission Mounting Nut (17mm socket): 54 – 62 N·m (40 – 45 lb-ft)
  • Long Main Support Through-Bolt (17mm socket): 81 – 99 N·m (60 – 73 lb-ft)

Mazda CX5 Petrol Model 2016 Gearbox Mountain

KSh4,000.00
Part Numbers & Interchanges
  • OEM Part Numbers: GHR9-39-070, GHR9-39-070A, KD45-39-070A, KR11-39-070A
  • Aftermarket Cross-References: A4438, SKMA4438, 9813 [1, 2, 3]
Physical & Material Specifications
  • Mounting Type: Rubber-to-Metal Insulator Mount (Elastomer dampened, solid rubber core)
  • Chassis Bracket Material: Heavy-duty Stamped Steel / Cast Aluminum
  • Fitting Position: Left Front (Engine/Gearbox Left Side Bay, structurally positioned beneath the air intake box, ECU assembly, and battery tray)
  • Inner Bushing Diameter: 14 mm to 15 mm
  • Average Mount Width: 75 mm
  • Average Weight: Approx. 0.96 kg to 1.1 kg (insulator core only) [1, 2, 3, 4]
Installation Torque Specifications
  • Chassis Mounting Bolts (19mm socket): 131 – 153 N·m (96 – 113 lb-ft)
  • Transmission Mounting Nut (17mm socket): 54 – 62 N·m (40 – 45 lb-ft)
  • Long Main Support Through-Bolt (17mm socket): 81 – 99 N·m (60 – 73 lb-ft) [1]

Mazda CX5 Diesel Model 2018 Gearbox Mountain

KSh4,000.00
Part Numbers & Interchanges
  • OEM Part Numbers: K123-39-070A, K123-39-070, KD45-39-070A
  • Aftermarket Cross-References: U9813, TED40312, TED98369 [1, 2]
Physical & Material Specifications
  • Mounting Type: Rubber-to-Metal Insulator Mount (Elastomer dampened structural support)
  • Chassis Bracket Material: Heavy-duty Cast Aluminum / Stamped Steel
  • Fitting Position: Left Front / Rear Left (Engine/Gearbox Left Side Bay, structurally positioned beneath the battery tray and ECU assembly)
  • Inner Bushing Diameter: 14 mm to 15 mm
  • Average Weight: Approx. 1.2 kg to 1.4 kg (complete assembly) [1, 2]
Installation Torque Specifications
  • No. 4 Engine Mount Bracket Installation Nuts (Main Frame): 92 – 116 N·m (68 – 85 lb-ft)
  • Transaxle Stud Bolts: 15 – 25 N·m (12 – 18 lb-ft)
  • Chassis Alignment Bolts (19mm socket): 131 – 153 N·m (96 – 113 lb-ft)
  • Transmission Mounting Nut (17mm socket): 54 – 62 N·m (40 – 45 lb-ft)
  • Long Main Support Through-Bolt (17mm socket): 81 – 99 N·m (60 – 73 lb-ft) [1]

Mazda CX5 Diesel Model 2017 Gearbox Mountain

KSh4,000.00
Part Numbers & Interchanges
  • OEM Part Numbers: K123-39-070A, K123-39-070, KD45-39-070A
  • Aftermarket Cross-References: TED40312, TED98369 [1, 2, 3]
Physical & Material Specifications
  • Mounting Type: Rubber-to-Metal Insulator Mount (Elastomer dampened structural mount)
  • Chassis Bracket Material: Heavy-duty Cast Aluminum / Stamped Steel
  • Fitting Position: Left Front / Rear Left (Engine/Gearbox Left Side Bay, structurally positioned beneath the battery tray and ECU assembly)
  • Inner Bushing Diameter: 14 mm to 15 mm
  • Average Weight: Approx. 1.2 kg to 1.4 kg (complete assembly) [1, 2, 3]
Installation Torque Specifications
  • No. 4 Engine Mount Bracket Installation Nuts (Main Frame): 92 – 116 N·m (68 – 85 lb-ft)
  • Transaxle Stud Bolts: 15 – 25 N·m (12 – 18 lb-ft)
  • Chassis Alignment Bolts (19mm assembly variant): 131 – 153 N·m (96 – 113 lb-ft)
  • Transmission Mounting Nut / Support Bolt: 54 – 62 N·m (40 – 45 lb-ft) [1, 2]

Mazda CX5 Diesel Model 2016 Gearbox Mountain

KSh4,000.00
Part Numbers & Interchanges
    • OEM Part Numbers: GHR9-39-070, GHR9-39-070A, KD45-39-070A, KR11-39-070A
    • Aftermarket Cross-References: A4438, SKMA4438, 9813 [1, 2, 3, 4]
Physical & Material Specifications
    • Mounting Type: Rubber-to-Metal Insulator Mount (Solid/Elastomer dampened)
    • Chassis Bracket Material: Heavy-duty Stamped Steel / Cast Aluminum
    • Fitting Position: Left Front (Engine/Gearbox Left Side Bay, underneath the battery tray/ECU assembly)
    • Inner Bushing Diameter: 14 mm to 15 mm
    • Average Mount Width: 75 mm
    • Average Weight: Approx. 0.96 kg to 1.1 kg (insulator core only) [1, 2, 3]
Installation Torque Specifications
  • Chassis Mounting Bolts (19mm socket): 131 – 153 N·m (96 – 113 lb-ft)
  • Transmission Mounting Nut (17mm socket): 54 – 62 N·m (40 – 45 lb-ft)
  • Long Main Support Through-Bolt (17mm socket): 81 – 99 N·m (60 – 73 lb-ft) [1]

Mazda CX5 Diesel Model 2015 Gearbox Mountain

KSh4,000.00
Part Numbers & Interchanges
    • OEM Part Numbers: GHR9-39-070, GHR9-39-070A, KD45-39-070A, KR11-39-070A
    • Aftermarket Cross-References: A4438, SKMA4438, 9813 [1, 2, 3]
Physical & Material Specifications
    • Mounting Type: Rubber-to-Metal Insulator Mount (Elastomer dampened)
    • Chassis Bracket Material: Heavy-duty Stamped Steel / Cast Aluminum
    • Fitting Position: Left Front (Engine/Gearbox Left Side Bay, beneath the battery tray/ECU assembly)
    • Inner Bushing Diameter: 14 mm to 15 mm
    • Average Mount Width: 75 mm
    • Average Weight: Approx. 0.96 kg to 1.1 kg (insulator core only) [1, 2, 3, 4, 5, 6]
Installation Torque Specifications
  • Chassis Mounting Bolts (19mm socket): 131 – 153 N·m (96 – 113 lb-ft)
  • Transmission Mounting Nut (17mm socket): 54 – 62 N·m (40 – 45 lb-ft)
  • Long Main Support Through-Bolt (17mm socket): 81 – 99 N·m (60 – 73 lb-ft) [1]

Mazda CX5 Model 2015 Gearbox Mountain

KSh4,000.00
1. Component Breakdown & OEM Part Numbers
The 2015 Mazda CX-5 utilizes a multi-point SkyActiv powertrain isolation layout, relying on two distinct mounting components directly responsible for holding and stabilizing the gearbox assembly:
  • Left-Hand Gearbox Mount (Transmission Main Insulator):
    • OEM Part Numbers: BJS7-39-070 / GHR9-39-070B / KD47-39-070
    • Function: Primary weight-bearing insulator for the transmission housing. It fastens the gearbox structural casing to the left frame rail to isolate high-frequency driveline harmonics. [1]
  • Rear Torque Strut Mount (Lower "Dog-Bone" Roll Stopper):
    • OEM Part Numbers: KF59-39-040A / KD45-39-040
    • Function: Drivetrain pitch control arm. Anchors the rear lower transmission casing directly to the front suspension cross-member subframe to prevent back-and-forth movement under heavy acceleration or shifting. [1, 2]
2. Vehicle Structural Fitment
  • Engine & Gearbox Alignment: Transverse configuration (East-West installation)
  • Chassis Series Covered: Mazda CX-5 (KE Platform / First Gen Pre-facelift & Facelift crossover periods). [1, 2]
  • Powertrain Compatibility:
    • 2.0L SkyActiv-G paired with the 6-speed manual (SKYACTIV-MT) or 6-speed automatic (SKYACTIV-Drive).
    • 2.5L SkyActiv-G paired with the 6-speed automatic.
    • 2.2L SkyActiv-D (Twin-Turbo Diesel global variants). [1, 2, 3, 4]
  • Drivetrain Adaptability: Identical mounting geometry handles both Front-Wheel Drive (FWD) and All-Wheel Drive (AWD) intelligent subframe layouts. [1]
3. Material Specifications
  • Structural Composition: Laser-cut, stamped high-tensile structural steel combined with cast aluminum frame adapters.
  • Damping Material: Heavy-duty vulcanized natural rubber (NBR-metal bonded matrix).
  • Damping Classification: Passive elastomeric design. The left transmission side features a solid-core rubber cushion block specifically calibrated to isolate SkyActiv-Drive torque converter lockup frequencies. [1, 2, 3]
4. Standard Factory Torque Specifications
  • Main Transmission Mount-to-Chassis Frame Bolts: ~62 Nm to 80 Nm (approx. 45 to 59 ft-lbs)
  • Transmission Mount-to-Gearbox Bracket Center Nut: ~85 Nm to 100 Nm (approx. 62 to 74 ft-lbs)
  • Rear Torque Strut Lower Subframe Cross-bolt: ~90 Nm (approx. 66 ft-lbs)

Mazda Demio Model 2018 Lower Control Arm

KSh5,500.00
1. Dimensional & Sizing Specifications
  • Total Component Length: 350 mm (Note: Certain unbracketed aftermarket replacements indicate up to 422 mm across extended geometric measurement points).
  • Total Component Height: 82 mm
  • Component Width: ~50 mm (at base structural track profile)
  • Ball Joint Cone/Pin Diameter: Ø 16 mm (Note: Factory-fitted original equipment measures 16 mm, though some heavy-duty replacement matrices use a 17.5 mm variant).
  • Fitting Configuration Type: Pinch Bolt alignment configuration (16 mm)
  • Inner Bushing Bolt Hole Diameter: 10.4 mm
2. OEM Part Numbers & Cross-References
  • Left-Hand Side (LH):
    • Mazda Original Equipment (OE) Codes: DA7H-34-350B, DA6A-34-350C, DB2R-34-350
    • Major Aftermarket Match: Delphi TC3286
  • Right-Hand Side (RH):
    • Mazda Original Equipment (OE) Codes: DA7H-34-300B, DA6A-34-300C, DB2R-34-300
    • Major Aftermarket Match: Delphi TC3287
3. Material & Component Architecture
  • Structural Material: High-tensile forged or stamped steel alloy structural matrix finished with an anti-corrosion black powder layer.
  • Pre-Assembled Bushings: Premium vulcanized natural rubber silent-block bushings (one forward cylindrical pivot bushing and one large rear compliance load bushing) engineered to minimize cabin NVH (Noise, Vibration, and Harshness).
  • Ball Joint Mechanism: Maintenance-free, non-adjustable, factory-sealed, pre-greased low-friction ball joint enclosed in a flexible neoprene protective dust boot.
4. Vehicle & Platform Fitment Geometry
  • Chassis Codes Covered: Mazda Demio / Mazda 2 Hatchback and Sedan (DBA-DJ3FS, DBA-DJ3AS 4WD, 3BA-DJLFS, 5BA-DJLFS, DJ5FS, DJ5AS).
  • Powertrain Compatibility: 1.3L SkyActiv-G (P3-VPS), 1.5L SkyActiv-G (F5-VPT / P5-VPS), and 1.5L SkyActiv-D Diesel (S5-DPTS).
  • Platform Sharing: Shared geometric subframe attachment layout with the Toyota Yaris / Yaris iA (North American variants derived from the Mazda DJ platform partnership).

Mazda Demio Model 2017 Lower Control Arm

KSh5,500.00
1. Dimensional & Sizing Specifications
  • Total Component Length: 350 mm (Note: Certain unbracketed aftermarket replacements indicate up to 422 mm across extended geometric points). [1]
  • Total Component Height: 82 mm [1]
  • Component Width: ~50 mm (at base structural track profile)
  • Ball Joint Cone/Pin Diameter: Ø 16 mm (Note: Some heavy-duty premium replacement matrices specify a 17.5 mm cone variant; standard factory factory-fitted OE measures 16 mm). [1]
  • Fitting Configuration Type: Pinch Bolt alignment configuration (16 mm)
  • Inner Bushing Bolt Hole Diameter: 10.4 mm
2. OEM Part Numbers & Cross-References
  • Left-Hand Side (LH):
    • Mazda Original Equipment (OE) Codes: DA7H-34-350B, DA6A-34-350C, DA7H-34-350
    • Major Aftermarket Match: Delphi TC3286 [1, 2]
  • Right-Hand Side (RH):
    • Mazda Original Equipment (OE) Codes: DA7H-34-300B, D23H-34-300, DA6A-34-300C
    • Major Aftermarket Match: Delphi TC3287 [1, 2]
3. Material & Component Architecture
  • Structural Material: High-tensile forged or stamped steel alloy structural matrix finished with an anti-corrosion black powder layer.
  • Pre-Assembled Bushings: Premium vulcanized natural rubber silent-block bushings (one forward cylindrical pivot bushing and one large rear compliance load bushing) engineered to minimize cabin NVH (Noise, Vibration, and Harshness).
  • Ball Joint Mechanism: Maintenance-free, non-adjustable, factory-sealed, pre-greased low-friction ball joint enclosed in a flexible neoprene protective dust boot. [1, 2]
4. Vehicle & Platform Fitment Geometry
  • Chassis Codes Covered: Mazda Demio / Mazda 2 Hatchback and Sedan (DBA-DJ3FS, DBA-DJ3AS 4WD, DJ5FS, DJ5AS).
  • Powertrain Compatibility: 1.3L SkyActiv-G (P3-VPS), 1.5L SkyActiv-G (F5-VPT), and 1.5L SkyActiv-D Diesel (S5-DPTS).
  • Platform Sharing: Shared geometric subframe attachment layout with the Toyota Yaris / Yaris iA (2016+ North American variants derived from the Mazda DJ platform partnership). [1, 2]
Showing 28 of 88 results
Please select your product
Product has been added to your cart
Compare (0)
