Explore our existing collection of braking, suspension, steering and engine components. Check each product for fitment and current availability.

Sort

Mazda CX5 Petrol Gearbox Mountain

KSh4,500.00
Mazda CX-5 Petrol Gearbox (Transmission) Mount Technical Specifications
Mount Assembly Specifications
    • Component Function: Rubber-metal or hydraulic-damped structural isolator securing the transaxle to the chassis subframe.
    • Mounting Locations: Left-side (driver-side) upper transaxle bracket (underneath battery tray) and rear lower torque strut mount (transaxle-to-crossmember).
    • OEM Materials: Cast aluminum or stamped steel housing bonded to high-damping natural rubber elastomer.
    • Aftermarket Performance Materials: TIG-welded steel housing with replaceable polyurethane bushings (62A to 95A Shore durometer).
    • OEM Unit Weight: 0.74 kg (1.63 lbs) (standard rubber-metal replacement).
    • Heavy-Duty Unit Weight: 2.27 kg (5.00 lbs) (billet/welded steel construction).
    • Design Service Life: 5 to 7 years (non-serviceable sealed elastomer unit).
OEM Part Number Reference Matrix
Chassis Generation Production Years Compatible Powertrain Mounting Position OEM Part Numbers
KE (1st Gen) 2012–2017 2.0L / 2.5L Skyactiv-G (AT/MT) Left (Transmission) GHR9-39-070, BBM5-39-070
KE / KF (1st & 2nd Gen) 2013–2025 2.0L / 2.5L Skyactiv-G (FWD/AWD) Rear (Torque Strut) BJS7-39-070
KF (2nd Gen) 2017–2025 2.0L / 2.5L / 2.5T Skyactiv-G (AT) Left (Transmission) K123-39-070, K123-39-070A
Supported Gearbox & Powertrain Specifications
    • Automatic Transaxle: 6-speed Skyactiv-Drive (FW6A-EL / GW6A-EL).
    • Manual Transaxle: 6-speed Skyactiv-MT (C66M-R / D66M-R).
    • Supported Petrol Engines: 2.0L Skyactiv-G (1,998 cc, 121 kW / 165 hp, 210 Nm) and 2.5L Skyactiv-G (2,488 cc, 139–143 kW / 187–192 hp, 252–257 Nm).
    • Automatic Fluid Specification: Mazda Original Oil ATF-FZ, 7.8 L total dry capacity.
    • Manual Fluid Specification: API GL-4 SAE 75W-80, 1.65 L (2WD) or 1.70 L (AWD).

Hilux Vigo 4WD Driveshafts

KSh18,000.00
Front CV Drive Shafts (Left & Right Axis)
The front independent front suspension (IFS) uses complete outer CV joint driveshafts with the following physical specifications depending on the exact production month: [1, 2]
  • Spline Count (Wheel/Outer Side): 30 splines
  • Spline Count (Differential/Inner Side): 30 splines
  • Total Component Length (Variant A - Up to 05/2012): 630 mm
  • Total Component Length (Variant B - 05/2012 to 2015): 632 mm
  • Hub Retaining Nut Thread Size: M28 x 1.5
  • Hub/CV Shaft Axle Nut Torque Spec: 235 Nm (173 ft-lb)
  • OEM Reference Numbers: 43430-0K020, 43430-0K030, 43430-0K050, 43430-0K021, 43430-0K022, 43430-0K051, 43430-0K023 [1, 2]
Rear Propeller Shaft (Tail Shaft) & Center Bearing
The longitudinal rear driveshaft delivering power from the transfer case to the rear differential contains the center support bearing assembly and standard universal joints: [1, 2]
  • Driveshaft Flange Nut Torque Spec: 88 Nm (65 ft-lb)
  • Center Bearing Staked Nut Size: 24 mm socket profile
  • Center Bearing Nut Torque Spec: 181 Nm initial, then loosen and final retorque to 82 Nm
  • Transmission Compatibility: Specific models segmented strictly by manual transmission (MT) vs. automatic transmission (AT) layout lengths. [1, 2]

Toyota Noah Model 2003-2015 Rear Heavy Duty Springs

KSh7,000.00
Technical Engineering Specifications
Heavy-duty rear springs deviate from factory dimensions primarily in wire thickness and rate structure to combat load sagging: [1]
  • Material Wire Diameter (Gauge): 13.5 mm to 14.5 mm (Factory standard is typically ~12.0 mm to 12.5 mm).
  • Spring Type: Cylindrical, Progressively Wound (Coil pitch narrows at one end to maintain smooth comfort during unladen driving but stiffens rapidly under load).
  • Free Height (Unloaded): 380 mm to 410 mm (Depending on the specific target lift).
  • Outer Diameter: ~125 mm to 132 mm (Sized exactly to lock cleanly into the factory upper and lower rubber insulators).
  • Stiffness / Spring Rate: Stiffened by 15% to 30% over stock limits to withstand extreme commercial or multi-passenger weights. [1, 2, 3, 4]
Chassis & Architecture Profiles
Rear HD springs are direct-fit replacements but must align with your drivetrain layout, as 4WD versions use specific compression behavior to account for the rear differential weight:
  • 1st Generation (2001–2007): Fits AZR60G (2WD) and AZR65G (4WD) chassis. Uses factory cross-reference base 48231-28A60 (2WD) / 48231-28A70 (4WD).
  • 2nd Generation (2007–2014): Fits ZRR70G / ZRR70W (2WD) and ZRR75G / ZRR75W (4WD) chassis. Uses factory cross-reference base 48231-28C10. [1, 2, 3, 4]
Note: Springs for the 3rd Generation (ZRR80/ZWR80 2014+) feature a slightly modified base seat taper and are generally packaged separately from the 2001–2014 sets.
Installation Torque & Reassembly Rules
When installing heavy-duty springs, ensuring the rear axle beam and shock mounts are properly secured under load prevents premature bushing wear:
  • Lower Shock Absorber Mount Bolt: 90 Nm (66 ft-lbs)
  • Rear Axle Beam-to-Frame Trailing Arm Bolts: 135 Nm (100 ft-lbs)
  • Wheel Lug Nuts: 103 Nm (76 ft-lbs)
  • Installation Tip: Always inspect the Upper Coil Spring Insulator (48257-28060) during replacement. Heavy-duty springs will chew through cracked or worn rubber seats quickly, causing metal-on-metal noise over bumps. [1, 2]

Nissan Wingroad Y12 Wheel Hub Bearing

KSh4,000.00
Front Wheel Hub Assembly Specifications
The front wheel hub is a complete, sealed bolt-on unit containing double-row angular contact ball bearings. The bearing cannot be pressed out independently; the entire unit must be replaced. [1, 2, 3]
  • Flange Outer Diameter: 122 mm
  • Spline/Teeth Count (CV Axle Input): 25 teeth
  • Bolt Pattern (PCD): 4 x 100 mm
  • Wheel Stud Thread Size: M12 x 1.25
  • ABS Integration: Features a built-in 48-teeth magnetic sensor encoder ring on the inner face.
  • Mounting Configuration: 3-bolt triangular pattern securing directly to the steering knuckle.
  • Common OEM Cross-References: 40202-ED000, 40202-ED02A, 40202-ED05A, and PHU58010. [1, 2, 3, 4]
Rear Wheel Hub Assembly Specifications (FWD Modifications)
For standard Front-Wheel Drive models (such as the DBA-Y12 and DBA-JY12), the rear hub assembly houses the spindle sleeve and bolts straight to the rear trailing axle beam. [1, 2]
  • Flange Outer Diameter: 134 mm
  • Inner Diameter (Center Bore): 25 mm
  • Centering/Pilot Diameter: 68 mm
  • Total Unit Height: 69 mm
  • Bolt Pattern (PCD): 4 x 100 mm
  • Mounting Configuration: 4-bolt square mounting flange.
  • Common OEM Cross-References: 43202-ED305 and 0282-Z12WDR. [1, 2, 3]
Critical Installation Torque Specifications
Proper torque loading is essential to set the exact factory preload on the internal double-row ball bearings. Deviations can result in premature bearing noise or complete structural breakdown. [1, 2, 3]
  • Front Axle Spindle/Hub Nut: 113 Nm to 125 Nm (83 to 92 ft-lbs)
  • Hub-to-Steering Knuckle Bolts (Front): 88.3 Nm (65 ft-lbs)
  • Hub-to-Axle Housing Bolts (Rear): 85 Nm (63 ft-lbs)
  • Wheel Lug Nuts: 108 Nm (80 ft-lbs)

Nissan Ad Wheel Hub Bearing

KSh4,000.00
Y12 Generation (2006–Present) Specifications
Built on the global B-platform (sharing architecture with the Nissan Tiida C11 and Wingroad Y12), this generation uses an integrated third-generation bolt-on assembly: [1, 2, 3]
  • Flange Outer Diameter: 122 mm
  • Spline/Teeth Count (Front Drive Axle): 25 teeth
  • Bolt Pattern (PCD): 4 x 100 mm
  • Total Height/Thickness: 80 mm
  • Inner Flange Diameter: 25 mm
  • Wheel Stud Thread: M12 x 1.25
  • ABS Integration: Magnetic sensor encoder ring built directly into the inner face of the bearing. [1, 2]
Y11 Generation (1999–2008) Specifications
This variant operates on a traditional press-fit system. The hub and bearing are separate components; the bearing must be pressed into the knuckle first, followed by the hub. [1]
  • Bearing Dimensions (Inner x Outer x Width): 38 mm x 76 mm x 40/43 mm (Asymmetrical width variant).
  • Bearing Type: Double-row angular contact ball bearing.
  • Bolt Pattern (PCD): 4 x 114.3 mm or 4 x 100 mm (varies depending on heavy-duty Max load capacity vs. standard DX commercial trims). [1, 2]
Torque Specifications
Applying standard B-platform and Y-chassis engineering values ensures the longevity of the bearing assemblies: [1, 2]
  • Front Axle Spindle Nut: 113 Nm to 125 Nm (83 to 92 ft-lbs)
  • Rear Hub Assembly-to-Axle Bolts (Y12 FWD): 85 Nm (63 ft-lbs)
  • Brake Caliper Bracket Bolts: 98 Nm (72 ft-lbs)
  • Wheel Lug Nuts: 108 Nm (80 ft-lbs) [1]

Nissan Tiida Wheel Hub

KSh4,000.00
The Nissan Tiida (primarily the C11 and C12 generations) utilizes a fully integrated wheel hub and bearing assembly for both the front and rear axles. Because specifications differ significantly depending on the market region (e.g., Japan/Australia vs. Europe/Americas) and ABS configurations, the data is split by standard setups. [1, 2, 3, 4]
Front Wheel Hub Specifications
The front wheel hub houses the internal splines that receive power from the CV axle shaft. [1]
  • Spline/Teeth Quantity: 25 teeth on the input shaft.
  • Bolt Pattern (PCD): Commonly 4 x 114.3 mm (Standard JDM/Global models) or 4 x 100 mm (Select European variants).
  • Flange Outer Diameter: 122 mm to 136 mm (depending on PCD configuration).
  • Hub Pilot Diameter: 80 mm.
  • Mounting Configuration: 3-bolt triangular mounting flange to the steering knuckle.
  • Wheel Stud Thread Size: M12 x 1.25. [1, 2, 3, 4, 5, 6, 7]
Rear Wheel Hub Specifications
The rear hub assembly varies drastically between front-wheel drive (FWD) and all-wheel drive (4WD) e-4WD models. The standard FWD rear assembly includes: [1]
  • Flange Outer Diameter: 134 mm to 148 mm.
  • Center Bore / Wheel Pilot Diameter: 66 mm to 68 mm.
  • Mounting Configuration: 4-bolt square pattern to the rear trailing axle.
  • ABS Integration: Available as standard magnetic encoder ring variants or non-ABS variants. [1, 2, 3]
Critical Torque Specifications
Adhering to correct torque specifications is mandatory during installation to avoid premature wheel bearing failure: [1]
  • Front Wheel Hub Central Axle Nut: 113 Nm (83 ft-lbs)
  • Hub Assembly-to-Knuckle Bolts (Front): 88.3 Nm (65 ft-lbs)
  • Hub Assembly-to-Axle Bolts (Rear): 94.3 Nm (70 ft-lbs)
  • Wheel Lug Nuts: 113 Nm (83 ft-lbs)

Toyota Probox Steering Rack

KSh10,000.00
Core Mechanical Specifications
Depending on the specific aftermarket or OEM manufacturer (such as NSK or JTEKT) supplying the system, the core dimensions and technical metrics include: [1, 2]
  • Steering Wheel Turns: 2.88 turns lock-to-lock.
  • Overall Length: Ranges between 1105 mm and 1110 mm.
  • Net Weight: Roughly 5.9 kg to 6.6 kg.
  • Input Shaft Height: 48 mm to 49 mm.
  • Input Shaft Diameter: 17.3 mm.
  • Tie Rod Thread Size: M15x1.5 or M16x1.5 (varies by manufacturer specification). [1, 2]
OEM Part Numbers & Chassis Compatibility
Because the Probox has evolved across multiple generations, steering racks must be matched with exact OEM part numbers to ensure proper fitment for right-hand drive (RHD) configurations: [1, 2]
  • First Generation (XP50 / NCP50 series, 2002–2014): Commonly uses OEM part numbers 44200-52300, 40120-52170, and 44250-52300.
  • Second Generation (NCP150 / NCP160 series, 2014–present): Features part numbers 45510-52420 (often electric/manual rack assembly for NCP160) and 44200-52290 (for NCP150/151 series). [1, 2, 3, 4]

Nissan Note Model E12 Lower Arm Control

KSh4,000.00
Nissan Note (Model E12) Front Lower Control Arm Technical Specifications
  • Suspension Type: MacPherson strut front independent suspension lower track control arm.
  • Control Arm Material: Stamped sheet steel (welded assembly configuration).
  • Component Weight: Approximately 2.49 kg per side (complete assembly including ball joint and bushings).
  • Total Component Length: 338 mm.
  • Ball Joint Cone Pin Size: 16 mm diameter.
  • Bushing Design: Horizontal front rubber pivot mounting bush and an upright rear cylindrical rubber dampening mount.
  • Assembly Inclusions: Pre-installed non-adjustable press-fit outer ball joint and vulcanized rubber mounting bushings. [1, 2, 3, 4]
Genuine OEM Part Numbers
  • Front Right Hand (RH) Lower Arm: 54500-1HM0B, 54500-1HA0C, 54500-1HA5A, 54500-1HA5D, 54500-1HA6A
  • Front Left Hand (LH) Lower Arm: 54501-1HM0B, 54501-1HA0C, 54501-1HA5A, 54501-1HA5D, 54501-1HA6A
  • Chassis/Model Codes: E12 Series (2012–2020)
  • Engine Compatibility: HR12DE, HR12DDR, HR15DE, HR16DE

Mazda Demio 2012 Axel Beam

KSh35,000.00
2012 Mazda Demio (DE Series) Axle Beam Technical Specifications
  • Suspension Type: Torsion beam (twist-beam) semi-independent rear suspension.
  • Beam Material: Welded, high-tensile U-shaped structural steel (serves as a built-in anti-sway bar).
  • Component Weight: Approximately 14 kg (bare beam axle).
  • Hub/Lug Bolt Pattern: 4-Hole (4x100 mm pitch circle diameter).
  • Brake Compatibility: Tailored for rear drum braking systems (standard FWD layout).
  • Bushing Style: Pressed-in rubber or polyurethane integrated cylindrical damping bushings.
  • Vehicle Wheelbase Track: Designed for a 2,490 mm wheelbase configuration with a rear wheel track of 1,455 mm. [1, 2, 3]
Genuine OEM Part Numbers
  • Standard FWD Rear Beam: D03P28B00A, DR61-28-B00A, DF71-28-B00B, D65128B00B
  • 4WD Variant Rear Beam: D03T28B00A
  • Compatible Model Codes: DBA-DE3FS, DBA-DEJFS, DBA-DE3AS, DBA-DE5FS [1, 2]

Mazda Demio 2013 Axel Beam

KSh35,000.00
2013 Mazda Demio (DE Series) Axle Beam Technical Specifications
  • Suspension Type: Torsion beam (twist-beam) semi-independent rear suspension.
  • Beam Material: Welded, high-tensile U-shaped structural steel.
  • Component Weight: Approximately 14 kg (bare beam axle).
  • Hub/Lug Bolt Pattern: 4-Hole (4x100 mm pitch circle diameter).
  • Brake Compatibility: Tailored for rear drum braking systems (standard 2WD layout).
  • Bushing Style: Pressed-in rubber or polyurethane integrated cylindrical damping bushings.
  • Vehicle Wheelbase Track: Designed for a 2,490 mm wheelbase configuration. [1, 2, 3, 4, 5, 6, 7]
Genuine OEM Part Numbers
  • Standard 2WD Rear Beam: D03P28B00A, DR61-28-B00A, DF71-28-B00B, D65128B00B
  • 4WD Variant Rear Beam: D03T28B00A
  • Compatible Model Codes: DBA-DEJFS, DBA-DE3FS, DBA-DE3AS

Mazda Demio 2014 Axel Beam

KSh35,000.00
Core Engineering Specifications
  • Suspension Layout Type: Torsion Beam (also referred to as Twist-Beam semi-independent suspension) [1, 2]
  • Structure Construction: High-tensile U-shaped tubular stamped steel profile designed to flex mechanically and eliminate independent rear sway bars. [1, 2]
  • Drive Configuration Compatibility: 2WD Rear Axle Setup default (Separate differential carrier subframes are utilized for rare 4WD e-4WD layouts). [1]
  • Brake System Interface: Engineered to mount standard trailing-leading type mechanical Drum Brake backplates. [1, 2]
Hub & Geometry Interfacing
  • Wheel Lug Stud Count (PCD Bolt Pattern): 4 Holes x 100 mm (4H)
  • Wheel Hub Housing Integration: Fits a four-bolt integrated hub-and-bearing flange cartridge system.
  • ABS Sensor Mapping: Includes integrated bracket tabs for active ABS wheel speed sensor wire routing looms. [1, 2, 3]
Hardware Part Numbers by Generation Profile
  • DE Series Generation (Production up to September 2014):
    • OEM Component Part Code: D651-28-15X (Sub-variations map up to suffix E) [1]
  • DJ Series Generation (Production from September 2014 Onward):
    • OEM Component Part Code: DA6A-28-B0XG (Features structurally reinforced chassis-bushing wings to address older DE cracking issues). [1, 2, 3]

Toyota Crown Athlete Shocks Absorbers

KSh10,000.00
Front Axle Specifications
  • Suspension Type: Independent Double Wishbone with Coil Springs [1]
  • Shock Absorber System: Twin-Tube Gas Pressure [1]
  • Adaptive Damping: Equipped with factory Adaptive Variable Suspension (AVS) utilizing a top-mounted electronic step-motor actuator to dynamically adjust valving. [1, 2]
  • Mounting Configuration: 3-bolt structural upper strut mount with a heavy-duty lower fork bush mounting directly onto the lower control arm. [1]
  • Aftermarket Cross-Reference: KYB 721001 (Right) / 721002 (Left) (Electronic/AVS series) | TEIN EnduraPro VSC76-A1MS2-R (Non-AVS bypass variant). [1, 2]
Rear Axle Specifications
  • Suspension Type: Independent Multi-Link with Coil Springs
  • Shock Absorber System: Monotube or Twin-Tube Gas Pressure (varies by Athlete trim stiffness levels)
  • Adaptive Damping: Seamless integration with the electronic AVS architecture.
  • Mounting Configuration: Eyelet top pin/stud base plate with a low-slung lower eyelet bush assembly.
  • Aftermarket Cross-Reference: KYB 551120 [1, 2, 3, 4]
Critical Installation Torque Specifications
  • Front Strut Tower Top Nut: 25 N·m (18 ft-lbf)
  • Front Strut Lower Fork Bolt: 157 N·m (116 ft-lbf)
  • Rear Shock Upper Mount Base Bolts: 30 N·m (22 ft-lbf)
  • Rear Shock Lower Eyelet Bush Bolt: 84 N·m (62 ft-lbf)
OEM Part Numbers & Platform Sharing
  • GRS184 (Zero Crown Athlete) Front OEM Numbers: 48510-80255, 48520-80125
  • GRS204 (200-Series Athlete) Front OEM Numbers: 48510-80477, 48520-80277
  • GRS214 (210-Series Athlete) Front OEM Numbers: 48510-80610 (Right), 48520-80324 (Left)
  • Platform Sharing Architecture: Shares identical dampener chassis mount geometry and electronic valving dynamics with the Toyota Mark X (GRX120 / GRX130) and Lexus GS (GRS190 / GRL10) 2WD performance platforms.

Toyota Mark X GRX 120 Shocks Absorbers

KSh10,000.00
Front Axle Specifications
  • Suspension Type: Double Wishbone
  • Shock Absorber System: Twin-Tube Gas Pressure
  • Operating Principle: Hydraulic Double-Acting
  • Mounting Type: Upper structural Strut Mount (3-bolt top plate) with a lower Fork/Eyelet bush mount securing to the lower control arm.
  • Electronic Variable Dampening: Models equipped with AVS (Adaptive Variable Suspension) utilize an electronic actuator port on top of the front piston rod.
  • Aftermarket Cross-Reference (KYB Excel-G): 341357 (Right) / 341358 (Left)
Rear Axle Specifications
  • Suspension Type: Multi-Link Independent
  • Shock Absorber System: Mono-Tube or Twin-Tube Gas Pressure (depending on sport/standard trim levels)
  • Operating Principle: Hydraulic Double-Acting
  • Mounting Type: Top Pin/Stud mount with a lower Eyelet bush mount.
  • Aftermarket Cross-Reference (KYB Excel-G): 341423
Critical Installation Torque Specifications
  • Front Strut Tower Top Nut: 25 N·m (18 ft-lbf)
  • Front Strut Base Fork to Control Arm Bolt: 157 N·m (116 ft-lbf)
  • Rear Shock Upper Mount Base Bolts: 30 N·m (22 ft-lbf)
  • Rear Shock Lower Eyelet Bush Bolt: 84 N·m (62 ft-lbf)
OEM Part Numbers & Platform Sharing
  • Standard Front Left/Right OEM Numbers: 48510-80227, 48520-80047, 48510-30740
  • AVS (Electronic) Front Left/Right OEM Numbers: 48510-80255, 48520-80125
  • Standard Rear OEM Numbers: 48530-80287, 48530-30510
  • AVS (Electronic) Rear OEM Numbers: 48530-80327
  • Platform Architecture: Shares identical dampener chassis mount geometry with the Toyota Crown (GRS180 / GRS182 / GRS200 series) and the Lexus GS (GRS190 series) 2WD platforms.

Toyota Axio Steering Rack

KSh15,000.00
Core Engineering Specifications
  • Steering Gear Type: Rack and Pinion
  • Operating Mode: Electric Power Steering (EPS) manual rack configuration (assisted via a column-mounted motor)
  • Drive Layout: Factory designed for Right-Hand Drive (RHD) setups
  • Total Assembly Length: 1085 mm to 1164.5 mm (depending on specific generation track width variations)
  • Net Weight: 7.5 kg
  • Minimum Turning Radius: 4.9 meters [1, 2, 3]
Hardware & Component Dimensions
  • Rack End Mounting Thread Size: M14 x 1.5
  • Mounting Bracket Distance: 448 mm
  • Key Internal Sub-Assemblies: Tie rod inner rack ends, rubber dust protection boots, outer tie rod ends, and internal micro-bushing [1, 2, 3]
Part Numbers & Platform Compatibility
  • E140 Series (2006–2012) OEM Part Numbers: 45510-12410, 45510-12290
  • E160 Series (2012–Present) OEM Part Numbers: 45510-52241, 45510-52300
  • Chassis Code Fitment: Fits DBA-NZE141, DBA-NZE161 (1.5L 1NZ-FE), and NKE165 (1.5L Hybrid) variants.
  • Platform Sharing Architecture: Fully interchangeable within respective generation platforms, sharing sub-assembly geometry with the Toyota Corolla Fielder, Aqua (NHP10), Vitz/Yaris (P130 series), Sienta (P170 series), Ractis, and Sienta. [1, 2, 3, 4, 5, 6]

Toyota Premio 260 Steering Rack

KSh18,000.00
Core Engineering Specifications
  • Steering Gear Type: Rack and Pinion
  • Operating Mode: Electric Power Steering (EPS) with column-mounted or rack-integrated motor assistance
  • Drive Layout: Factory configured for Right-Hand Drive (RHD) setups
  • Lock-to-Lock Turns: Approximately 3.2 turns
  • Power Assist Mechanism: Electronic Actuator (Does not utilize hydraulic fluid, pumps, or pressure lines)
Hardware & Component Dimensions
  • Rack End / Tie Rod Inner Thread: M15 x 1.5
  • Tie Rod End Cross-Reference (555 Brand): SR-T360 / SE-T361
  • Boot Kit Code Hardware: 45535 (No.1 Boot) and 45536 (No.2 Boot)
  • Material Housing: Lightweight cast aluminum alloy shell with high-tensile steel internal rack shaft [1, 2]
Part Numbers & Platform Compatibility
  • Primary OEM Part Numbers: 45510-20100, 44200-28510
  • Chassis Code Coverage: Fits NZT260 (1.5L 1NZ-FE), ZRT260 (1.8L 2ZR-FE/FAE), ZRT261 (2.0L 3ZR-FAE), and 4WD variants (ZRT265).
  • Platform Sharing Architecture: Fully interchangeable with the T260-generation Toyota Allion (NZT260 / ZRT260) and shares geometric sub-assembly dimensions with the Toyota Premio/Allion T240 or Prius systems depending on localized revision cycles. [1, 2, 3, 4]

Suzuki Alto 2015-2018 Driveshaft

KSh5,000.00
Core Spline & Toothing Geometry
  • External Toothing (Wheel/Hub Side): 23 teeth
  • External Toothing (Differential Side): 22 teeth
  • Internal Toothing (Inner Wheel-Side CV Joint): 19 teeth (up to 20 teeth on select localized HA36 versions)
  • ABS Tone Ring Tooth Count: 43 teeth [1]
Physical Dimensions & Hardware
  • Overall Length (Left / Short Side Compressed): 638 mm to 662 mm
  • Overall Length (Right / Long Side Compressed): 820 mm to 837 mm
  • Outboard Joint Thread Size (Hub Nut): M18 x 1.5
  • Seal Ring Diameter (Wheel Side): 49 mm
  • Drive Shaft Seal ID (Inner): Left Side: 38 mm | Right Side: 40 mm
  • Joint Configuration: Tripod-type inboard joint with a ball-type outboard CV joint [1, 2, 3]
OEM Part Numbers & Platform Compatibility
  • Front Passenger Side (Left) OEM Numbers: 44102-74P00, 44102-74P02
  • Inner CV Joint OEM Reference: 44117-84330-002
  • Engine & Transmission Pairing: Optimized for 660cc R06A (NA & Turbo) and 1.0L K10B engine configurations matched with CVT, 5-speed Manual, or AGS (Auto Gear Shift) transmissions. [1, 2, 3]
  • Platform Sharing: Components maintain structural layout sharing with matching-era Suzuki Wagon R (MH55S) and Alto Lapin (HE33S) platforms.

Suzuki Alto 2015 Driveshaft

KSh5,000.00
Core Spline & Toothing Geometry
  • External Toothing (Wheel/Hub Side): 23 teeth
  • External Toothing (Differential Side): 22 teeth
  • Internal Toothing (Inner Wheel-Side CV Joint): 19 teeth (varies up to 20 teeth on some HA36 versions)
  • ABS Ring Tooth Count: 43 teeth [1, 2, 3, 4]
Physical Dimensions & Hardware
  • Overall Length (Left / Short Side Compressed): 638 mm to 662 mm
  • Overall Length (Right / Long Side Compressed): 837 mm
  • Outboard Joint Thread Size (Hub Nut): M18 x 1.5
  • Seal Ring Diameter (Wheel Side): 49 mm
  • Drive Shaft Seal ID (Inner): Left Side: 38 mm | Right Side: 40 mm
  • Joint Configuration: Tripod-type inboard joint with a ball-type outboard CV joint. [1, 2, 3, 4]
OEM Part Numbers & Compatibility
  • Front Passenger Side (Left) OEM Numbers: 44102-74P00, 44102-74P02
  • Inner CV Joint OEM Reference: 44117-84330-002
  • Platform Sharing: Components maintain structural layout sharing with matching-era Suzuki Wagon R (MH55S) and Alto Lapin (HE33S) platforms.[1, 2]

Toyota AE91 Steering Rack

KSh20,000.00
Core Engineering Specifications
  • Steering Gear Type: Rack and Pinion
  • Operating Mode Option 1: Hydraulic Power Steering (HPS)
  • Operating Mode Option 2: Manual / Mechanical steering (non-servotronic configurations)
  • Drive Layout: Right-Hand Drive (RHD) factory standard (Left-Hand Drive [LHD] aftermarket replacements available)
  • Overall Assembly Length: 836 mm (Hydraulic unit) to 1165 mm (Manual unit variants depending on the integrated tie-rod span).
  • Net Weight: 7.5 kg to 8.2 kg [1, 2, 3]
Hardware & Interface Dimensions
  • Axle Joint Thread Size (Rack End): M14 x 1.5
  • Input Shaft Pinion Connector Type: Toothed / Splined spline configuration
  • Cylinder Sealing System: Uses a primary power steering rack piston ring and secondary rubber dust bellows. [1, 2]
Part Numbers & Platform Compatibility
  • Hydraulic OEM Part Numbers: 44250-12230, 44250-12231, 44250-12232, 44250-12060
  • Manual OEM Part Numbers: 45510-12170, 45510-02020
  • Chassis Platform Sharing: Directly interchangeable within the Toyota E90 platform architecture, including the Toyota Corolla EE90, AE92, AE95 4WD, and Sprinter variants of the same era. [1, 2, 3]

Toyota G Touring Steering Rack

KSh20,000.00
Core Engineering Specifications
  • Steering Gear Type: Rack and Pinion
  • Operating Mode: Hydraulic Power Steering (HPS)
  • Drive Layout: Right-Hand Drive (RHD) default configuration (LHD aftermarket cross-references available)
  • Total Assembly Length: Approximately 955 mm
  • Net Weight: 6.9 kg to 7.2 kg [1, 2, 3, 4, 5]
Hardware & Interface Dimensions
  • Input Shaft Pinion Diameter: 17.3 mm
  • Input Shaft Splines: 36 teeth
  • Input Shaft Connector Type: Toothed / Splined
  • Tie Rod Thread Connection: Female tierods / inner rack end configuration [1]
Installation Torque Specifications
  • Rack Guide Spring Cap / Lock Nut: 70 N·m (51 ft-lbf)
  • Rack Housing End Cap: 60 N·m (43 ft-lbf)
  • Turn Pressure Tubes / Lines: 13.5 N·m to 15 N·m (10 to 11 ft-lbf)
  • Fluid Lubricant Type: Dexron II / III Automatic Transmission Fluid (ATF) / Power Steering Fluid [1]
Part Numbers & Platform Compatibility
  • OEM Part Numbers: 44250-12530, 44250-12400, 44250-12480, 44250-12330
  • Chassis Platform Sharing: Directly interchangeable within the E100/E110 platform ecosystem, including the Toyota Corolla Sedan/Wagon (AE100, AE101, AE110), Corolla L Touring, and Sprinter variants. [1, 2, 3, 4]

Toyota Mark X Hub Knuckle

KSh6,000.00
Core Engineering & Structural Specs
    • Material Composition: High-tensile cast iron or forged steel alloy for structural load-bearing rigidity.
    • Suspension System Design: Integrated components built specifically for a Double-Wishbone front suspension configuration.
    • ABS Integration: Provisions built into the knuckle body to accept an active wheel speed sensor with specialized harness mounting tabs. [1, 2, 3, 4]
Hub & Bearing Interface Geometry
    • Wheel Lug Pattern (PCD): 5 x 114.3 mm
    • Wheel Rim Center Bore (Hub Pilot): 60.1 mm
    • Wheel Stud Thread Size: M12 x 1.5
    • Wheel Bearing Outer Housing Type: Bolted-flange unit (4-bolt mounting pattern directly to the steering knuckle assembly). [1, 2]
Critical Installation Torque Specifications
    • Steering Knuckle to Upper Control Arm (Ball Joint): 110 N·m (81 ft-lb)
    • Steering Knuckle to Lower Control Arm (Ball Joint): 159 N·m (118 ft-lb)
    • Steering Knuckle Arm to Tie Rod End: 122 N·m (90 ft-lb)
    • Brake Caliper Mounting Bracket to Knuckle: 123 N·m (91 ft-lb)
    • ABS Speed Sensor Mounting Bolt: 8.0 N·m (71 in-lbf) [1, 2, 3]
OEM Part Numbers & Platform Sharing
  • Front Steering Knuckle (Right): 43201-30010
  • Front Steering Knuckle (Left): 43202-30020
  • Front Axle Hub Assembly: 43550-30010
  • Chassis Cross-Compatibility: Shared architectural structural points across the Toyota Crown (GRS180 / GRS200 series) and Lexus GS (GRS190 series).

Toyota Crown Athlete Steering Rack

KSh25,000.00
Core Engineering Specifications
  • Steering Gear Type: Rack and Pinion
  • Operating Mode: Electric Power Steering (EPS) with an integrated motor-actuator
  • Drive Layout: Built for Right-Hand Drive (RHD) configurations
  • Turning Radius: Approx. 5.2m to 5.4m (dependent on the specific wheel/tire Athlete packages)
  • Rack sliding force: 210.6 to 269.4 N (equivalent to the shared architecture of Toyota's premium RWD platforms) [1, 2]
Fitment & Hardware Details
  • Rack End Mounting Thread Size: M15 x 1.5
  • Chassis Platform Group: Shared Toyota "S" platform architecture (rear-wheel drive layout)
  • Key Components: Internal digital torque sensor assembly, high-output electric motor, inner tie rods, tie rod ends, and protective rubber bellows. [1]
Part Numbers & Platform Compatibility
  • GRS184 (Zero Crown Athlete) OEM Number: 44200-30330, 44200-30300
  • GRS204 (200-Series Athlete) OEM Number: 44200-30580, 44200-30581
  • GRS214 (210-Series Athlete) OEM Number: 44200-30A10
  • Tie Rod End OEM Number: 45503-30070
  • Platform Sharing: Component cross-compatibility with the Toyota Mark X (GRX120/130) 2WD and Lexus GS (GRS190) platforms. [1, 2, 3]

Toyota Markx 2WD Steering Rack

KSh25,000.00
Core Engineering Specifications
  • Steering Gear Type: Rack and Pinion
  • Operating Mode: Electric Power Steering (EPS) with integrated motor/actuator assembly
  • Drive Layout: Built exclusively for Right-Hand Drive (RHD) configurations
  • Rack Sliding Force: 210.6 to 269.4 N (21.5 to 27.5 kg)
  • Wheel Turning Angle (Inner): Minimum 32° 31′ | Nominal 35° 31′ | Maximum 36° 31′ [1, 2, 3, 4]
Fitment & Hardware Details
  • Rack End Mounting Thread: M15 x 1.5
  • Primary Components: Includes internal torque sensor, EPS rack housing, dual inner tie-rod end sub-assemblies, outer rods, and rubber dust boots.
  • Chassis Platform Group: Shared system geometry across Toyota's rear-wheel-drive (RWD) "S" platform architecture. [1, 2, 3]
Part Numbers & Platform Compatibility
  • OEM Part Numbers: 44200-30302, 44200-30300, 44200-30330, 44200-30610
  • Tie Rod End OEM Number: 45503-30070
  • Vehicle Compatibility: Toyota Mark X 250G/350S (GRX120, GRX130 chassis), Toyota Crown (GRS180, GRS200 series), and Lexus GS (GRS190 series) 2WD platforms.

Toyota Passo Sette Shock Absorber

KSh7,500.00
Front Axle Specifications
  • Suspension Type: MacPherson Strut
  • Shock Absorber System: Twin-Tube Gas Pressure
  • Operating Principle: Hydraulic Double-Acting
  • Mounting Type: Top Pin/Stud (Strut Mount) with Bottom Bracket clamp (Two-Bolt Steering Knuckle mount)
  • Aftermarket Cross-Reference (KYB): 3340117 / 3340116 (Varies by Left/Right side orientation) [1]
Rear Axle Specifications
  • Suspension Type: Torsion Beam (Trailing Arm layout)
  • Shock Absorber System: Separate Spring and Damper configuration
  • Operating Principle: Twin-Tube Gas Pressure
  • Mounting Type: Top Pin/Eyelet and Bottom Eyelet bush [1]
OEM Part Numbers & Compatibility
  • Front Right OEM Part Number: 48510-B1130, 48510-B1140
  • Front Left OEM Part Number: 48520-B1130, 48520-B1140
  • Rear OEM Part Number: 48531-B1090
  • Platform Sharing: Component configuration shares architectural commonality with the Daihatsu Boon Luminas, Toyota Avanza, and Perodua Alza platforms. [1, 2]

Harrier 240 Steering Rack

KSh25,000.00
Core Engineering Specifications
  • Steering Gear Type: Rack and Pinion
  • Operating Mode: Hydraulic Power Steering (HPS)
  • Steering Wheel Lock-to-Lock: 2.88 turns
  • Drive Layout: Built for Right-Hand Drive (RHD) configurations
  • Total Length: 1105 mm
  • Net Weight: 6.6 kg to 8.0 kg (varies by manufacturer) [1, 2, 3, 4, 5]
Fitment & Component Dimensions
  • Tie Rod Thread Size: M16 x 1.5
  • Input Shaft Height: 48 mm
  • Input Shaft Diameter: 17.4 mm
  • Input Shaft Splines: 36 teeth
  • Input Shaft Connector: Toothed
  • Original Equipment Manufacturer: NSK [1, 2]
Part Numbers & Interchangability
  • OEM Part Numbers: 44200-48080, 44200-48150, 40120-48080
  • Vehicle Platform Compatibility: Toyota Harrier 240G (2AZ-FE engine), Toyota Kluger V, Lexus RX300, Lexus RX330, and Lexus RX350.

Toyota Wish Model 2015 Steering Rack

KSh18,000.00
Part Numbers & Identification
  • OEM Part Number (Standard 2WD - ZGE20G / ZGE21G): 45510-68020, 45510-68021
  • OEM Part Number (4WD - ZGE25G / ZGE25W): 45510-68051
  • Chassis Platform Base: Toyota New MC Platform (Shared profile elements with the Toyota Isis ZGM10G)
  • Chassis Layout Codes: DBA-ZGE20G, DBA-ZGE20W, DBA-ZGE21G, DBA-ZGE25G
  • Compatible Engine Platforms: 1.8L 2ZR-FAE I4, 2.0L 3ZR-FAE I4 [1, 2]
System Specifications
  • Operating Mode: Manual Gear-type Rack / Column-Assisted Electric Power Steering (EPS)
  • Steering Gear Type: Rack and Pinion
  • Input Shaft Pinion Configuration: Toothed spline connection
  • Input Shaft Spline Count: 36 Teeth
  • Input Shaft Diameter: 17.4 mm
  • Input Shaft Pinion Height: 43 mm
  • Overall Assembly Length: ~952 mm (Standard baseline chassis tracking width)
  • Rack End Lock Nut Thread Fitment: M15 x 1.5
  • Housing Construction: Light-weight die-cast Aluminum alloy casing with high-tensile carbon steel internal rack gear teeth

Toyota Corolla AE100 Steering Rack

KSh20,000.00
Part Numbers & Identification
  • OEM Part Numbers (RHD - Right Hand Drive): 44250-12480, 44250-12620, 44250-12180, 44250-12181
  • OEM Part Numbers (LHD - Left Hand Drive): 44250-02010, 44250-12400, 44250-12560, 44250-12232
  • Chassis Compatibility: AE100, AE101, EE100, CE100 (Corolla Sedan, Ceres, FX Hatchback, and Wagon variants)
  • Associated Engine Platforms: 1.5L 5A-FE, 1.6L 4A-FE / 4A-GE, 1.3L 2E / 4E-FE, 2.0L 2C Diesel [1, 2, 3, 4]
System Specifications
  • Operating Mode: Hydraulic Power Assisted Steering (HPS)
  • Steering Gear Type: Rack and Pinion
  • Total Assembly Length: ~1045 mm – 1050 mm (excluding outer tie rod ends)
  • Input Shaft configuration: 36-spline configuration
  • Input Shaft Diameter: 17.5 mm
  • Inner Tie Rod (Rack End) Thread Size: M14 x 1.5
  • Outer Tie Rod End Thread Size: M12 x 1.25
  • Hydraulic Pressure Port Thread (Inlet): M14 x 1.5 flare nut
  • Hydraulic Return Port Thread (Outlet): M16 x 1.5 flare nut
  • Main Housing Material: Die-cast Aluminum alloy cylinder body with structural steel rack shaft

Mazda Verisa Steering Rack

KSh12,000.00
Part Numbers & Identification
  • OEM Part Number (Standard Baseline): D521-32-110 / D521-32-110A / D521-32-110B
  • Alternative OEM Part Numbers: D350-32-110E, D521-32-960
  • Chassis Layout Codes: DBA-DC5W (2WD / Front-Wheel Drive), DBA-DC5R (e-4WD / 4x4)
  • Compatible Engine Format: 1.5L ZY-VE I4 [1, 2, 3, 4]
System Specifications
  • Operating Mode: Electric Power Steering (EPS) / Manual Gear type with Column Assist
  • Steering Gear Type: Rack and Pinion
  • Total Assembly Length: 1075 mm – 1076 mm
  • Total Rack Stroke: 157 mm
  • Number of Steering Wheel Turns (Lock-to-Lock): 2.9 turns
  • Input Shaft Diameter: 17.4 mm
  • Input Shaft Toothing/Splines: 36 Teeth
  • Axle Joint / Tie Rod Thread Size: M14 x 1.5
  • Minimum Vehicle Turning Radius: 4.9 meters [1, 2, 3]

Mazda Demio Model 2005 Steering Rack

KSh12,000.00
Part Numbers & Identification
  • OEM Part Number (Standard 2WD): D521-32-110, D52132110
  • Alternative OEM Part Numbers: D350-32-110C, DD32-32-110
  • Chassis Codes: DBA-DY3W, DBA-DY5W, LA-DY3W, LA-DY5W
  • Compatible Engine Formats: 1.3L ZJ-VE, 1.5L ZY-VE [1]
Electric Steering Rack Specs (JDM/Standard)
  • Operating Mode: Electric Power Steering (EPS) / Manual Gear type with Column Assist
  • Steering Gear Type: Rack and Pinion
  • Total Length: 1075 mm – 1076 mm
  • Total Rack Stroke: 157 mm
  • Number of Steering Wheel Turns (Lock-to-Lock): 2.9 turns
  • Input Shaft Diameter: 17.4 mm
  • Input Shaft Toothing: 36 Teeth
  • Axle Joint / Tie Rod Thread Size: M14 x 1.5 [1, 2]
Hydraulic Steering Rack Specs (Alternative/Euro Variant)
  • Operating Mode: Hydraulic Power Steering
  • Steering Gear Type: Hydraulic Rack and Pinion
  • Manufacturer Architecture: FoMoCo (Ford Motor Company) / JTEKT
  • Total Length: 1131 mm
  • Total Rack Stroke: 162 mm
  • Number of Steering Wheel Turns (Lock-to-Lock): 3.3 turns
  • Input Shaft Diameter: 18.3 mm
  • Hydraulic Port Line Entry Thread: M14 x 2
  • Hydraulic Port Line Exit Thread: M16 x 1.5
  • Axle Joint / Tie Rod Thread Size: M14 x 1.5 [1, 2]
Showing 28 of 641 results
Please select your product
Product has been added to your cart
Compare (0)
