Mazda Demio Model 2014 Driveshafts

KSh6,500.00
OEM Part Numbers
  • Fourth Generation (DJ Series: DJ3FS / DJ5FS / DJ5AS – Late 2014 onwards):
    • Front Right Side (RHS / Long Shaft): FTD1-25-50XA / FTD1-25-50X
    • Front Left Side (LHS / Short Shaft): FTD1-25-60XA / FTD1-25-60X [1, 2, 3]
  • Third Generation (DE Series: DE3FS / DE5FS – Early 2014 production):
    • Front Right Side (RHS): F051-25-50X / FA81-25-500A
    • Front Left Side (LHS): F051-25-60X / FA80-25-600A [1]
Spline Counts & Joint Engagement
  • Fourth Generation (DJ Chassis):
    • External Toothing (Wheel/Hub Side): 26 Teeth
    • External Toothing (Differential/Gearbox Side): 31 Teeth (Automatic/SkyActiv-Drive) [1, 2]
  • Third Generation (DE Chassis):
    • External Toothing (Wheel/Hub Side): 25 Teeth
    • External Toothing (Differential/Gearbox Side): 24 Teeth (Manual) / 26 Teeth (CVT/Automatic) [1]
Dimensional Specifications
  • Fourth Generation (DJ Chassis):
    • Compressed Length (Right Hand / RHS): ~956 mm (includes integrated extension shaft profile)
    • Extension Shaft Length: 415 mm
    • Extension Bearing Outer Diameter: 70 mm
    • Extension Bearing Width: 25 mm [1, 2]
  • Third Generation (DE Chassis):
    • Compressed Length (Left Hand / LHS): ~590 mm to 620 mm
    • Compressed Length (Right Hand / RHS): ~915 mm to 920 mm
    • Wheel-Sided Joint Outer Diameter: 76 mm
    • Transmission-Sided Joint Outer Diameter: 78 mm to 80 mm
Material & Component Properties
  • Shaft Core Construction: Solid, high-tensile heat-treated induction-hardened chrome steel alloy. [1]
  • Dust Boots / Bellows: Premium, high-flexibility Neoprene or Chloroprene rubber compounds tailored for deep-angle torsional fatigue resistance. [1]
  • Lubrication System: Pre-packed internally with heavy-duty, high-temperature molybdenum disulfide (MoS2) friction-reducing lithium grease.

Mazda Demio Model 2013 Driveshafts

KSh6,500.00
OEM Part Numbers
  • Front Right Side (RHS / Long Shaft): F051-25-50X / FA81-25-500A / DG01-25-50X / D09V-25-50X (SkyActiv)
  • Front Left Side (LHS / Short Shaft): F051-25-60X / FA80-25-600A / DG01-25-60X / FA81-25-600B / D09V-25-60X (SkyActiv)
Spline Counts & Joint Engagement
  • External Toothing (Wheel/Hub Side): 25 Teeth
  • External Toothing (Differential/Gearbox Side):
    • Manual Transmission: 24 Teeth
    • CVT / Automatic / SkyActiv-Drive Variants: 26 Teeth
  • Wheel-Sided (Outboard) Joint Type: Ball-type Rzeppa joint
  • Transmission-Sided (Inboard) Joint Type: Tripod-type plunging joint
Dimensional Specifications
  • Compressed Length (Left Hand / LHS): ~590 mm to 620 mm (varies based on specific transmission pairing)
  • Compressed Length (Right Hand / RHS): ~915 mm to 920 mm (includes the integrated intermediate shaft assembly)
  • Wheel-Sided Joint Outer Diameter: 76 mm
  • Transmission-Sided Joint Outer Diameter: 78 mm to 80 mm
  • Hub Oil Seal Seat / ABS Ring Diameter: 54 mm
  • Hub Thread Size (Outer CV Stub): M22 x 1.5
Material & Component Properties
  • Shaft Core Construction: Solid, high-tensile induction-hardened chrome steel alloy.
  • Dust Boots / Bellows: High-durability Chloroprene or Neoprene rubber compound engineered for high-angle torsional stress.
  • Lubrication System: Pre-packed with heavy-duty, high-temperature lithium-based molybdenum disulfide (MoS2) friction-reducing grease.

Mazda Demio Model 2012 Driveshafts

KSh6,500.00
OEM Part Numbers
  • Front Right Side (RHS / Long Shaft): F051-25-50X / FA81-25-500A / DG01-25-50X / D09V-25-50X (SkyActiv)
  • Front Left Side (LHS / Short Shaft): F051-25-60X / FA80-25-600A / DG01-25-60X / FA81-25-600B / D09V-25-60X (SkyActiv) [1]
Spline Counts & Joint Engagement
  • External Toothing (Wheel/Hub Side): 25 Teeth [1, 2]
  • External Toothing (Differential/Gearbox Side):
    • Manual Transmission: 24 Teeth
    • CVT / Automatic / SkyActiv-Drive Variants: 26 Teeth
  • Wheel-Sided (Outboard) Joint Type: Ball-type Rzeppa joint [1]
  • Transmission-Sided (Inboard) Joint Type: Tripod-type plunging joint [1]
Dimensional Specifications
  • Compressed Length (Left Hand / LHS): ~590 mm to 620 mm (varies based on specific transmission pairing)
  • Compressed Length (Right Hand / RHS): ~915 mm to 920 mm (includes the integrated intermediate shaft assembly)
  • Wheel-Sided Joint Outer Diameter: 76 mm
  • Transmission-Sided Joint Outer Diameter: 78 mm to 80 mm
  • Hub Oil Seal Seat / ABS Ring Diameter: 54 mm
  • Hub Thread Size (Outer CV Stub): M22 x 1.5 [1]
Material & Component Properties
  • Shaft Core Construction: Solid, high-tensile induction-hardened chrome steel alloy.
  • Dust Boots / Bellows: High-durability Chloroprene or Neoprene rubber compound engineered for high-angle torsional stress.
  • Lubrication System: Pre-packed with heavy-duty, high-temperature lithium-based molybdenum disulfide (MoS2) friction-reducing grease.

Mazda Demio Model 2011 Driveshafts

KSh6,500.00
OEM Part Numbers
  • Front Right Side (RHS / Long Shaft): F051-25-50X / FA81-25-500A / DG01-25-50X / D09V-25-50X (SkyActiv)
  • Front Left Side (LHS / Short Shaft): F051-25-60X / FA80-25-600A / DG01-25-60X / D09V-25-60X (SkyActiv)
Spline Counts & Joint Engagement
  • External Toothing (Wheel/Hub Side): 25 Teeth
  • External Toothing (Differential/Gearbox Side):
    • Manual Transmission: 24 Teeth
    • CVT / Automatic / SkyActiv-Drive Variants: 26 Teeth
  • Wheel-Sided (Outboard) Joint Type: Ball-type Rzeppa joint
  • Transmission-Sided (Inboard) Joint Type: Tripod-type plunging joint
Dimensional Specifications
  • Compressed Length (Left Hand / LHS): ~590 mm to 620 mm (varies based on specific transmission type)
  • Compressed Length (Right Hand / RHS): ~915 mm to 920 mm (includes the integrated intermediate shaft assembly)
  • Wheel-Sided Joint Outer Diameter: 76 mm
  • Transmission-Sided Joint Outer Diameter: 78 mm to 80 mm
  • Hub Oil Seal Seat / ABS Ring Diameter: 54 mm
  • Hub Thread Size (Outer CV Stub): M22 x 1.5
Material & Component Properties
  • Shaft Core Construction: Solid, high-tensile induction-hardened chrome steel alloy.
  • Dust Boots / Bellows: High-durability Chloroprene or Neoprene rubber compound engineered for high-angle torsional stress.
  • Lubrication System: Pre-packed with heavy-duty, high-temperature lithium-based molybdenum disulfide (MoS2) friction-reducing grease.

Mazda Demio Model 2010 Driveshafts

KSh6,500.00
OEM Part Numbers
  • Front Right Side (RHS / Long Shaft): F051-25-50X / FA81-25-500A / DG01-25-50X
  • Front Left Side (LHS / Short Shaft): F051-25-60X / FA80-25-600A / DG01-25-60X
Spline Counts & Joint Engagement
  • External Toothing (Wheel/Hub Side): 25 Teeth
  • External Toothing (Differential/Gearbox Side):
    • Manual Transmission (5-Speed): 24 Teeth
    • CVT / Automatic Variants: 26 Teeth
  • Wheel-Sided (Outboard) Joint Type: Ball-type Rzeppa joint
  • Transmission-Sided (Inboard) Joint Type: Tripod-type plunging joint
Dimensional Specifications
  • Compressed Length (Left Hand / LHS): ~590 mm to 620 mm (varies based on specific transmission type)
  • Compressed Length (Right Hand / RHS): ~915 mm to 920 mm (includes the integrated intermediate shaft assembly)
  • Wheel-Sided Joint Outer Diameter: 76 mm
  • Transmission-Sided Joint Outer Diameter: 78 mm to 80 mm
  • Hub Oil Seal Seat / ABS Ring Diameter: 54 mm
  • Hub Thread Size (Outer CV Stub): M22 x 1.5
Material & Component Properties
  • Shaft Core Construction: Solid, high-tensile induction-hardened chrome steel alloy.
  • Dust Boots / Bellows: High-durability Chloroprene or Neoprene rubber compound engineered for high-angle torsional stress.
  • Lubrication System: Pre-packed with heavy-duty, high-temperature lithium-based molybdenum disulfide (MoS2) friction-reducing grease.

Mazda Demio Model 2009 Driveshafts

KSh6,500.00
OEM Part Numbers
  • Front Right Side (RHS / Long Shaft): F051-25-50X / FA81-25-500A / DG01-25-50X
  • Front Left Side (LHS / Short Shaft): F051-25-60X / FA80-25-600A / DG01-25-60X
Spline Counts & Joint Engagement
  • External Toothing (Wheel/Hub Side): 25 Teeth
  • External Toothing (Differential/Gearbox Side):
    • Manual Transmission (5-Speed): 24 Teeth
    • CVT / Automatic Variants: 26 Teeth
  • Wheel-Sided (Outboard) Joint Type: Ball-type Rzeppa joint
  • Transmission-Sided (Inboard) Joint Type: Tripod-type plunging joint
Dimensional Specifications
  • Compressed Length (Left Hand / LHS): ~590 mm to 620 mm (varies based on specific transmission type)
  • Compressed Length (Right Hand / RHS): ~915 mm to 920 mm (includes the integrated intermediate shaft assembly)
  • Wheel-Sided Joint Outer Diameter: 76 mm
  • Transmission-Sided Joint Outer Diameter: 78 mm to 80 mm
  • Hub Oil Seal Seat / ABS Ring Diameter: 54 mm
  • Hub Thread Size (Outer CV Stub): M22 x 1.5
Material & Component Properties
  • Shaft Core Construction: Solid, high-tensile induction-hardened chrome steel alloy.
  • Dust Boots / Bellows: High-durability Chloroprene or Neoprene rubber compound engineered for high-angle torsional stress.
  • Lubrication System: Pre-packed with heavy-duty, high-temperature lithium-based molybdenum disulfide (MoS2) friction-reducing grease.

Mazda Demio Model 2008 Driveshafts

KSh6,500.00
OEM Part Numbers
  • Front Right Side (RHS / Long Shaft): F051-25-50X / FP01-25-500B / FA81-25-500A
  • Front Left Side (LHS / Short Shaft): F051-25-60X / FA80-25-600A [1]
Spline Counts & Joint Engagement
  • External Toothing (Wheel/Hub Side): 25 Teeth
  • External Toothing (Differential/Gearbox Side):
    • Manual Transmission (5-Speed): 24 Teeth
    • CVT / Automatic Variants: 26 Teeth
  • Wheel-Sided (Outboard) Joint Type: Ball-type Rzeppa joint
  • Transmission-Sided (Inboard) Joint Type: Tripod-type plunging joint
Dimensional Specifications
  • Compressed Length (Left Hand / LHS): ~590 mm to 620 mm (varies slightly by specific transmission type)
  • Compressed Length (Right Hand / RHS): ~915 mm to 920 mm (models utilizing integrated intermediate bearing bracket supports)
  • Wheel-Sided Joint Outer Diameter: 76 mm
  • Transmission-Sided Joint Outer Diameter: 78 mm to 80 mm
  • Hub Oil Seal Seat / ABS Ring Diameter: 54 mm
  • Hub Thread Size (Outer CV Stub): M22 x 1.5
Material & Component Properties
  • Shaft Core Construction: Solid, high-tensile induction-hardened chrome steel alloy.
  • Dust Boots / Bellows: High-flexibility Chloroprene or Neoprene rubber compound formulated for high-angle torsional stress.
  • Lubrication System: Pre-packed with heavy-duty, high-temperature lithium-based molybdenum disulfide (MoS2) friction-reducing grease.

Mazda Demio Model 2007 Driveshafts

KSh6,500.00
OEM / Reference Part Numbers
  • Third Generation (DE3FS / DE5FS – 1.3L ZJ / 1.5L ZY engines with CVT or Manual):
    • Front Right Side (RHS): FA81-25-500A / F051-25-50X
    • Front Left Side (LHS): FA80-25-600A / F051-25-60X
  • Second Generation (DY3W / DY5W – 1.3L / 1.5L FWD variants):
    • Front Right Side (RHS): D351-25-50X
    • Front Left Side (LHS): D351-25-60X
Spline Counts & Joint Engagement
  • External Toothing (Wheel/Hub Side): 25 Teeth [1]
  • External Toothing (Differential/Gearbox Side):
    • DE Series (Third Gen): 24 Teeth (Manual) / 26 Teeth (CVT/Auto variants)
    • DY Series (Second Gen): 26 Teeth [1]
  • Wheel-Sided (Outboard) Joint Type: Ball-type Rzeppa joint
  • Transmission-Sided (Inboard) Joint Type: Tripod-type plunging joint [1]
Dimensional Specifications
  • Compressed Length (Left Hand / Short Side): ~590 mm to 640 mm (varies slightly by transmission pairing)
  • Compressed Length (Right Hand / Long Side): ~919 mm (models utilizing intermediate bearing supports extend up to this bracket profile)
  • Wheel-Sided Joint Diameter: 72.8 mm to 76 mm
  • Transmission-Sided Joint Diameter: 75 mm to 80 mm
  • Hub Oil Seal/ABS Ring Seat Diameter: 53.7 mm to 54 mm
  • Hub Thread Size (Outer CV Stub): M22 x 1.5 [1, 2, 3]
Material & Component Properties
  • Shaft Body: Solid, high-tensile heat-treated chrome steel alloy.
  • Dust Boots / Bellows: High-flexibility Chloroprene or Neoprene rubber compound built to withstand high torsional fatigue.
  • Lubrication: Pre-packed with heavy-duty, high-temperature molybdenum disulfide (MoS2) grease. [1]

Toyota Wish Steering Rack

KSh15,000.00
OEM Part Numbers
  • First Generation (ZNE10G / ANE10G / ANE11W): 45510-68010
  • Second Generation (ZGE20G / ZGE20W / ZGE21G): 45510-68020 / 45510-68021 / 45510-68030 / 45510-68041
Dimensional Specifications
  • Overall Component Length: ~952 mm
  • Input Shaft Pinion Height: 43 mm
  • Input Shaft Pinion Diameter: 17.4 mm
  • Input Shaft Spline Count: 36 teeth
  • Tie Rod / Inner Socket Thread Size: M16 x 1.5
System Performance & Mechanics
  • Steering Mechanism Type: Conventional Mechanical Rack and Pinion (Note: Power assist is provided via an external column-mounted Electronic Power Steering (EPS) motor setup on ZGE20 models, meaning the rack itself contains no internal hydraulic fluid passages).
  • Total Lock-to-Lock Turns: 2.88 turns
  • Primary Manufacturer Reference: NSK / Toyota Genuine
  • Net Unit Weight: 6.6 kg (bare assembly) to 8.0 kg (packaged with inner tie rods installed). [1, 2, 3, 4]
Material Composition
  • Main Housing Gear Body: Die-cast structural aluminum alloy.
  • Internal Rack & Pinion Gears: Carbon-hardened forged steel.
  • Dust Boots / Bellows: High-flexibility Chloroprene / Nitrile rubber compound. [1]

Toyota Markx GRX 130 X Japan Shocks

KSh5,000.00
System Configurations & Variants
  • Standard Suspension (Gas Type): Uses conventional twin-tube hydraulic gas-pressurized dampers.
  • AVS / Electric Dampers: Premium grades (e.g., 250G S-Package, Premium) utilize an Adaptive Variable Suspension (AVS) electronic damping system. These feature an actuator mounting bracket on top of the shaft to change internal valving dynamically. [1, 2, 3, 4]
OEM / KYB Part Numbers
  • Front Axle Assembly:
    • Standard (Left/Right): 48510-22B20 / 48520-22B20
    • Electronic / AVS (KYB OE Eco-Line): 721001 (Front RH) and 721002 (Front LH) [1]
  • Rear Axle Assembly:
    • Standard (Left/Right): 48530-22680 / 48540-22680
    • Electronic / AVS (KYB OE Eco-Line): 721003 (Rear Universal) [1]
Dimensional & Mounting Specifications
  • Design Profile: MacPherson Strut equivalent configuration for the Front (Double Wishbone integration) and an Eye-to-Pin/Pin-Bottom style Shock for the Multi-link Rear.
  • Upper Shaft Stem Thread: M10 x 1.25 mm (Standard) / M12 configuration for localized AVS stepper-motor engagement caps.
  • Upper Mounting Nut Torque Spec: 25 N·m (255 kgf·cm)
  • Lower Installation Bolt Size: M14 (Front lower clevis mount to lower arm; Rear lower eyelet mount to carrier). [1, 2, 3, 4]
Damping & Spring Calibration (KYB Reference)
  • Damping Medium: High-pressure Nitrogen gas (N₂) paired with premium multi-grade all-weather fluid to combat cavitation. [1]
  • Factory-Matched Spring Rates (KYB Extage Reference):
    • Front Spring Rate: 52.9 N/mm (5.4 kg/mm)
    • Rear Spring Rate: 58.3 N/mm (6.0 kg/mm)[1]

Suzuki Alto Model 2016 Lower Control Arm

KSh5,000.00
OEM Part Numbers
  • Japan-market/HA36 Generation:
    • Front Right Side (RHS): 45201-74P10 / 45201-74P00
    • Front Left Side (LHS): 45202-74P10 [1]
  • Export-market/GF Generation (1.0L K10B):
    • Front Right Side (RHS): 45201M68K00
    • Front Left Side (LHS): 45202M68K00 [1, 2]
Dimensional Specifications
  • Total Length: 281.2 mm (Note: Select international 1.0L variations feature an extended profile up to 460 mm)
  • Overall Height: 81 mm
  • Ball Pin / Joint External Thread: M12 x 1.25
  • Fitted / Cone Stud Diameter: 13.5 mm to 15 mm
  • Bushing Inner/Bore Diameter: 12 mm [1, 2, 3, 4]
Material & Build Properties
  • Structural Material: Heavy-duty stamped sheet steel (Premium aftermarket options utilize high-tensile forged steel).
  • Pre-assembled Components: Integrated natural rubber silent-block bushings and pre-greased, sealed lower ball joint assembly.
  • Surface Coating: Anti-corrosion electro-deposition paint (E-coating) or black powder coat finish.
  • Average Weight: 1.05 kg – 1.15 kg per side. [1, 2]

Suzuki Alto Model 2017 Lower Control Arm

KSh5,000.00
OEM Part Numbers
  • Front Right Side (RHS): 45201-74P10 / 45201-74P00
  • Front Left Side (LHS): 45202-74P10 [1, 2]
Dimensional Specifications
  • Total Length: ~281.2 mm to 282 mm
  • Overall Height: 81 mm
  • Ball Pin / Joint External Thread: M12 x 1.25
  • Cone / Ball Joint Stud Size: 13.4 mm to 15 mm
  • Inner/Bore Diameter (Bushing Sleeve): 12 mm to 14 mm [1, 2, 3, 4]
Material & Build Properties
  • Structural Material: Heavy-duty stamped/sheet structural steel (select premium variants use forged steel).
  • Component Assembly: Pre-installed premium natural rubber silent-block bushings and integrated lower ball joint mount.
  • Coatings: Anti-corrosion electro-deposition paint (E-coating) or black oxide layer finish.
  • Average Weight: 1.05 kg – 1.15 kg per side. [1, 2, 3, 4, 5]

Suzuki Alto Model 2018 Lower Control Arm

KSh5,000.00
Component Overview & Dimensions
  • Component Type: Front Suspension Lower Control Arm (A-Arm / Wishbone).
  • Material Composition: Stamped high-strength sheet steel.
  • Control Arm Type: Trailing link configuration with integrated ball joint and rubber silent-block bushings.
  • Dimensional Profile:
    • Center-to-Center Length: Approximately 281.2 mm.
    • Overall Height: 81.0 mm.
    • Ball Joint External Stud Thread: M12 x 1.25.
    • Inner Bushing Sleeve Diameter: 12.0 mm. [1]
Part Numbers & Factory Designations
  • Front Right Hand (RH) OEM Reference: 45201-74P10 (Alternative factory supersede: 45201-74P00).
  • Front Left Hand (LH) OEM Reference: 45202-74P10 (Alternative factory supersede: 45202-74P00).
  • Interchange Aftermarket ID: 273C0853 (Ridex). [1, 2, 3, 4]
Platform & Vehicle Compatibility
  • Chassis Platform / Generation: Suzuki HA36 Platform (8th Generation Alto).
  • Applicable Model Codes: HA36S, HA36V (including standard JDM versions, Alto Works, and Alto Turbo RS).
  • Cross-Brand Shared Footprint: Swaps its exact geometric layout and mounting pattern with the Suzuki Alto Lapin (HE33S), Suzuki Wagon R (MH35S/MH55S), Suzuki Hustler (MR52S), and Mazda Carol (HB36S). [1, 2]
Fastener Tightening Torque Specifications
  • Inner Pivot/Frame Horizontal Bolt (Control arm front nut): 55 Nm to 70 Nm {41 to 52 ft-lbs}.
  • Rear Vertical Bushing Clamp Mounting Nut: 70 Nm to 85 Nm {52 to 63 ft-lbs}.
  • Ball Joint Pinch Bolt to Steering Knuckle: 45 Nm to 55 Nm {33 to 40 ft-lbs}.
  • Stabilizer/Sway Bar Link to Control Arm Connecting Nut: 30 Nm to 40 Nm.

Mazda Demio Model 2018 Crossmember Mountain

KSh4,000.00
Component Overview & Construction
  • Component Type: Front Suspension Axle Subframe Member / Engine Carrier Support Cradle.
  • Material Composition: Stamped high-tensile structural steel.
  • Mounting Design: Multi-point isolated perimeter layout containing factory press-fitted, high-density elastomer damping rubber bushings.
Part Numbers & Identifiers
  • Primary OE/OEM Reference: DA6A-34-80X (or DA6A3480X).
  • Alternative / Factory Variation Numbers: DA6A-34-800, DB2R-34-80X, DB2R3480X.
  • Component Interchange Warning: The crossmember layout changed between generations. A front crossmember from the prior generation (DE Series) will not interchange with the 2018 DJ Series vehicle.
Platform & Vehicle Compatibility
  • Chassis Platform: Mazda DJ Platform (SkyActiv-Chassis architecture).
  • Model Codes: DJ3FS, DJ5FS, DJ3AS, DJ5AS, DJLFS.
  • Model Range Variants: Demio 13C, 13S, XD, Touring, Touring L Package, and 15MB.
  • Production Range: 2014–2019 (Japan-market Demio nameplate, later renamed globally as the MAZDA2).
  • Cross-Brand Footprint: Shares basic structural architecture and mounting geometric parameters with the Toyota Yaris iA / Scion iA (North American variants co-developed on this SkyActiv platform).
Powertrain & Alignment Specifications
  • Compatible Engine Applications: 1.3L Petrol (P3-VPS), 1.5L Petrol (P5-VPS), and 1.5L SkyActiv-D Clean Diesel (S5-DPTS / S5-DPTR).
  • Drivetrain Constraints: Configured for Front-Wheel Drive (FF) models, with altered structural clearances on the "AS" suffix all-wheel-drive (4WD / AWD) chassis codes.
  • Baseline Alignment Settings (Unladen Member Geometry):
    • Camber: -0°05' (Acceptable factory tolerance: -1°05' to +0°55')
    • Caster: 4°20' (Acceptable factory tolerance: 3°20' to 5°20')
    • Total Toe-In: 1.0 mm to 3.0 mm
Tightening Torque Specifications
  • Main Subframe-to-Chassis Structural Bolts: 115 Nm to 140 Nm {85 to 103 ft-lbs} (Two-stage torque-to-yield tracking on primary frame mounting layers).
  • Steering Rack Gearbox to Subframe Connecting Bolts: 75 Nm to 104 Nm {56 to 76 ft-lbs}.
  • Sway Bar Center Bracket-to-Crossmember Fasteners: 33 Nm to 42 Nm {24 to 31 ft-lbs}.
  • Lower Control Arm Rear Pivot Bolt (Large Bushing): 135 Nm to 160 Nm {100 to 118 ft-lbs}.

Mazda Demio Model 2017 Crossmember Mountain

KSh4,000.00
Component Overview & Construction
  • Component Type: Front Suspension Axle Subframe Member / Engine Carrier Support Cradle.
  • Material Composition: Stamped high-tensile structural steel.
  • Mounting Design: Multi-point isolated perimeter layout containing factory press-fitted, high-density elastomer damping rubber bushings.
Part Numbers & Identifiers
  • Primary OE/OEM Reference: DA6A-34-80X (or DA6A3480X).
  • Alternative / Factory Variation Numbers: DA6A-34-800, DB2R-34-80X, DB2R3480X.
  • Component Interchange Warning: The crossmember layout changed between generations. A front crossmember from the prior generation (DE Series) will not interchange with the 2017 DJ Series vehicle.
Platform & Vehicle Compatibility
  • Chassis Platform: Mazda DJ Platform (SkyActiv-Chassis architecture).
  • Model Codes: DJ3FS, DJ5FS, DJ3AS, DJ5AS, DJLFS.
  • Model Range Variants: Demio 13C, 13S, XD, Touring, Touring L Package, and 15MB.
  • Production Range: 2014–2019 (Japan-market Demio nameplate, later renamed globally as the MAZDA2).
  • Cross-Brand Footprint: Shares basic structural architecture and mounting geometric parameters with the Toyota Yaris iA / Scion iA (North American variants co-developed on this SkyActiv platform).
Powertrain & Alignment Specifications
  • Compatible Engine Applications: 1.3L Petrol (P3-VPS), 1.5L Petrol (P5-VPS), and 1.5L SkyActiv-D Clean Diesel (S5-DPTS / S5-DPTR).
  • Drivetrain Constraints: Configured for Front-Wheel Drive (FF) models, with altered structural clearances on the "AS" suffix all-wheel-drive (4WD / AWD) chassis codes.
  • Baseline Alignment Settings (Unladen Member Geometry):
    • Camber: -0°05' (Acceptable factory tolerance: -1°05' to +0°55')
    • Caster: 4°20' (Acceptable factory tolerance: 3°20' to 5°20')
    • Total Toe-In: 1.0 mm to 3.0 mm
Tightening Torque Specifications
  • Main Subframe-to-Chassis Structural Bolts: 115 Nm to 140 Nm {85 to 103 ft-lbs} (Two-stage torque-to-yield tracking on primary frame mounting layers).
  • Steering Rack Gearbox to Subframe Connecting Bolts: 75 Nm to 104 Nm {56 to 76 ft-lbs}.
  • Sway Bar Center Bracket-to-Crossmember Fasteners: 33 Nm to 42 Nm {24 to 31 ft-lbs}.
  • Lower Control Arm Rear Pivot Bolt (Large Bushing): 135 Nm to 160 Nm {100 to 118 ft-lbs}.

Mazda Demio Model 2016 Crossmember Mountain

KSh4,000.00
Component Overview & Construction
  • Component Type: Front Suspension Axle Subframe Member / Engine Carrier Support Cradle.
  • Material Composition: Stamped high-tensile structural steel.
  • Component Weight: Approximately 11.0 kg to 14.6 kg (depending on specific factory underbody guarding and regional market specs).
  • Mounting Design: Multi-point isolated perimeter layout containing factory press-fitted, high-density elastomer damping rubber bushings. [1, 2, 3]
Part Numbers & Identifiers
  • Primary OE/OEM Reference: DA6A-34-80X (or DA6A3480X).
  • Alternative / Factory Variation Numbers: DA6A-34-800, DB2R-34-80X, DB2R3480X.
  • Component Interchange Warning: The crossmember layout changed between generations. A front crossmember from the prior generation (DE Series) will not interchange with the 2016 DJ Series vehicle. [1, 2, 3]
Platform & Vehicle Compatibility
  • Chassis Platform: Mazda DJ Platform (SkyActiv-Chassis architecture).
  • Model Codes: DJ3FS, DJ5FS, DJ3AS, DJ5AS, DJLFS.
  • Model Range Variants: Demio 13C, 13S, XD, Touring, Touring L Package, and 15MB.
  • Production Range: 2014–2019 (Japan-market Demio nameplate, later renamed globally as the MAZDA2).
  • Cross-Brand Footprint: Shares basic structural architecture and mounting geometric parameters with the Toyota Yaris iA / Scion iA (North American variants co-developed on this SkyActiv platform). [1, 2, 3]
Powertrain & Alignment Specifications
  • Compatible Engine Applications: 1.3L Petrol (P3-VPS), 1.5L Petrol (P5-VPS), and 1.5L SkyActiv-D Clean Diesel (S5-DPTS / S5-DPTR). [1]
  • Drivetrain Constraints: Configured for Front-Wheel Drive (FF) models, with altered structural clearances on the "AS" suffix all-wheel-drive (4WD / AWD) chassis codes. [1]
  • Baseline Alignment Settings (Unladen Member Geometry):
    • Camber: -0°05' (Acceptable factory tolerance: -1°05' to +0°55')
    • Caster: 4°20' (Acceptable factory tolerance: 3°20' to 5°20')
    • Total Toe-In: 1.0 mm to 3.0 mm
Tightening Torque Specifications
  • Main Subframe-to-Chassis Structural Bolts: 115 Nm to 140 Nm {85 to 103 ft-lbs} (Two-stage torque-to-yield tracking on primary frame mounting layers).
  • Steering Rack Gearbox to Subframe Connecting Bolts: 75 Nm to 104 Nm {56 to 76 ft-lbs}.
  • Sway Bar Center Bracket-to-Crossmember Fasteners: 33 Nm to 42 Nm {24 to 31 ft-lbs}.
  • Lower Control Arm Rear Pivot Bolt (Large Bushing): 135 Nm to 160 Nm {100 to 118 ft-lbs}.

Mazda Demio Model 2015 Crossmember Mountain

KSh4,000.00
Component Overview & Construction
    • Component Type: Front Suspension Member Crossmember / Engine Carrier Cradle.
    • Material Composition: Stamped high-tensile structural steel.
    • Mounting Pattern: Multi-point perimeter bolt-on layout incorporating pre-installed, high-density rubber damping isolation bushings.
    • Integrated Mounts: Features pre-formed bracket points for the steering rack gearbox, front stabilizer/sway bar, lower control arms, and the rear torque-rod engine mount. [1, 2]
Part Numbers & Identifiers
    • Primary OE/OEM Reference: DA6A-34-80X (or DA6A3480X).
    • Superseded / Production Variations: DA6A-34-800, DB2R-34-80X.
    • Associated Stabilizer Link/Stay Component Fitment: Matches factory 22mm–24mm front anti-roll bar bracket spacing. [1, 2]
Platform & Vehicle Compatibility
    • Chassis Generation: Mazda DJ Platform (SkyActiv-Chassis architecture).
    • Model Codes: DJ3FS, DJ5FS, DJ3AS, DJ5AS, DJLFS (covering Demio 13C, 13S, XD, Touring, and 15MB variants).
    • Production Range: 2014–2019 (Japan-market Demio nameplate).
    • Cross-Brand Architecture: Shares geometric base configurations with the 2016+ Toyota Yaris IA / Scion iA (which were rebadged Mazda 2/Demio sedans built on this platform). [1, 2, 3]
Powertrain & Alignment Specifications
    • Compatible Engine Layouts: 1.3L Petrol (P3-VPS), 1.5L Petrol (P5-VPS / F-VPT), and 1.5L SkyActiv-D Clean Diesel (S5-DPTS / S5-DPTR). [1, 2]
    • Drivetrain Variations: Configured primarily for Front-Wheel Drive (FF) models with specific structural relief cutouts on AS-series 4WD / AWD options. [1, 2]
    • Baseline Alignment Settings (Unladen Member Position):
        • Camber: -0°05' (Acceptable tolerance: -1°05' to +0°55')
        • Caster: 4°20' (Acceptable tolerance: 3°20' to 5°20')
        • Total Toe-In: 1 mm to 3 mm
Tightening Torque Specifications
  • Main Subframe-to-Chassis Structural Bolts: 115 Nm to 140 Nm (Subject to two-stage torque-to-yield specifications on specific structural frame layers).
  • Steering Rack Gearbox to Subframe Connecting Bolts: 75 Nm to 104 Nm {56 to 76 ft-lbs}.
  • Sway Bar Center Bracket-to-Crossmember Fasteners: 33 Nm to 42 Nm {24 to 31 ft-lbs}.
  • Lower Control Arm (Rear Large Bushing) Pivot Bolt: 135 Nm to 160 Nm. [1, 2]

Nissan Dayz Gearbox Mountain

KSh3,500.00
Component Overview & Construction
  • Component Type: Left-Hand (LH) Transmission / Gearbox Insulator Mount.
  • Material Composition: Stamped structural steel bracket combined with natural rubber vibration-damping inserts.
  • Mounting Method: Multi-bolt frame attachment with a through-bolt core bushing layout to suspend the CVT/manual transmission case.
Part Numbers & Factory Designations
  • Primary OE/OEM Reference (Transmission Mount): 75860-6A00C
  • Alternative Manufacturer Part Identification: MN120289 (Cross-referenced due to joint development under the NMKV venture with Mitsubishi).
  • Associated Left-Hand Bracket Reference: 24236-6A00B [1]
Platform & Vehicle Compatibility
  • Chassis Platform/Generation:
    • 1st Generation: B21W Series (AA0 chassis code) spanning 2013–2019.
    • 2nd Generation: B44W, B45W, B47W, B48W Series (AA1 chassis code) spanning 2019–present. [1, 2]
  • Model Variants: Nissan Dayz, Nissan Dayz Highway Star, and Nissan Dayz Roox (B21A). [1]
  • Shared Architecture: Shared mechanical footprint and component styling with the Mitsubishi eK Wagon / eK Space (B11W series).
Powertrain Configurations
  • Engine Compartment Applications: Engineered specifically for the 659cc 3-cylinder power plants: 3B20 (Naturally Aspirated) and 3B20T (Turbocharged), along with newer BR06 engine codes. [1, 2]
  • Transmission Layout Support: Built for front-wheel-drive (2WD) and all-wheel-drive (4WD) layouts mated to an Xtronic Continuously Variable Transmission (CVT) or 5-speed manual transmission gearbox. [1, 2]
Tightening Torque Specifications
  • Main Gearbox Mount-to-Chassis Frame Bolts: 55 Nm (41 ft-lbs)
  • Central Through-Bolt / Hex Nut (Bushing Core Pin): 62 Nm (46 ft-lbs)
  • Gearbox Support Bracket-to-Transmission Case Fasteners: 59 Nm (43 ft-lbs) [1, 2]

Nissan Note Model E12 Crossmember Mountain

KSh3,000.00
Component Overview & Bushing Dimensions
  • Component Type: Front Axle Subframe Crossmember / Engine Carrier Cradle.
  • Material Composition: High-strength stamped structural steel.
  • Bushing Dimensional Profile (OEM / Polyurethane Upgrades):
    • Inner Bolt Diameter: 17.2 mm
    • Outer Fitting Diameter: 39.7 mm
    • Total Bushing Height: 80.3 mm
    • Bushing Core Width: 35.0 mm
  • Mounting Pattern: 4-point isolated high-density rubber dampening configuration.
Part Numbers & Component Identifiers
  • Primary OE/OEM Reference (FWD Models): 54401-3VA0A
  • Alternative / Regional Variations: 8200371332, 54401-5WH0A
  • Lower Cross Rail Support (Manual Transmission): L02952
  • Lower Cross Rail Support (Automatic/CVT): L02953
  • Associated Left Side Bracket/Stay: 54525-3VA0A
  • Associated Right Side Bracket/Stay: 54524-3VA0A [1]
Platform & Vehicle Compatibility
  • Chassis Platform: Nissan V Platform (Evolutionary successor to the B platform).
  • Model Range/Codes: Nissan Note 2nd Generation (E12, NE12 - 4WD) spanning production years 2012–2020.
  • Shared Geometric Footprint: Shares basic subframe isolation dimensions and steering rack mounting positions with the Nissan Micra/March (K13). [1]
Powertrain & Mechanical Layout
  • Compatible Engine Layouts: 1.2L 3-cylinder (HR12DE), 1.2L DIG-S (HR12DDR), 1.6L 4-cylinder (HR16DE), and 1.5L dCi Diesel.
  • Drivetrain Variances: Standard front relief for FWD versions; modified rear transfer case clearances on NE12 4WD and e-POWER variants. [1]
Tightening Torque Specifications
  • Main Subframe Cradle-to-Body Bolts (4 points): 127 Nm (94 ft-lbs)
  • Subframe Lower Stay/Bracket Reinforcement Bolts: 97 Nm (72 ft-lbs)
  • Rear Torque-Rod Engine Mount (Pins to Subframe): 95 Nm (70 ft-lbs)
  • Steering Rack Gearbox to Subframe Mounting Bolts: 147 Nm (109 ft-lbs)
  • Lower Control Arm Ball Joint (Pins to Steering Knuckle): 37 Nm (27 ft-lbs) [1]

Nissan AD Crossmember Mountain

KSh3,000.00
Component Overview & Bushing Dimensions
  • Component Type: Front Axle Subframe Member / Engine Carrier Support Cradle. [1]
  • Material Composition: High-strength stamped structural steel.
  • Bushing Dimensional Profile (OEM / Direct Replacement):
    • Inner Bolt Diameter: 17.2 mm
    • Outer Fitting Diameter: 39.7 mm
    • Total Bushing Height: 80.3 mm
    • Bushing Core Width: 35.0 mm
  • Damping Configuration: 4-point isolated press-fit rubber bushings engineered for high-durability commercial van duty cycles. [1]
Part Numbers & Interchangability
  • Primary OE/OEM Reference: 54400-EW000 [1, 2]
  • Factory Substitution/Supercession Reference: 54400-1FS0A [1]
  • Associated Left Support Link/Stay: 54525-EL000
  • Associated Right Support Link/Stay: 54524-EL000 / NSL-NM1 [1]
  • Lower Control Arm Bushing Identifiers (Pins to Crossmember):
    • Large Bushing: 54570-ED500
    • Small Bushing: 54560-ED530
Platform & Vehicle Compatibility
  • Chassis Platform: Nissan B Platform (Commercial Wagon Layout).
  • Model Range/Codes: Nissan AD / AD Expert 4th Generation (VAY12, VY12, VJY12, VZNY12) spanning production years 2006–2021.
  • Shared Architecture: Swaps its mechanical footprint, structural mounting geometries, and internal bush dimensions directly with the Nissan Wingroad (Y12) and Nissan Tiida (C11). [1, 2, 3, 4, 5]
Powertrain & Mechanical Layout
  • Compatible Engine Layouts: 1.2L (CR12DE), 1.5L (HR15DE), 1.6L (HR16DE), and 1.8L (MR18DE).
  • Drivetrain Layouts: Optimized for Front-Wheel Drive (FF/FWD) setups (Automatic / CVT) with altered rear relief profiles on VZNY12 4WD e-4WD systems. [1, 2, 3]
Tightening Torque Specifications
  • Primary Main Subframe Cradle Bolts (4 points): 127 Nm (94 ft-lbs)
  • Subframe Stay Bracket Reinforcement Bolts: 97 Nm (72 ft-lbs)
  • Transaxle/Engine Mount Rear Torque Bracket (Pins to Subframe): 88 to 107 Nm
  • Steering Rack Gearbox to Subframe Connecting Bolts: 147 Nm (109 ft-lbs)

Nissan Wingroad Crossmember Mountain

KSh3,000.00
Component Overview & Bushing Dimensions
  • Component Type: Front Suspension Axle Subframe Member / Engine Carrier Cradle. [1, 2]
  • Material Composition: High-strength stamped structural steel.
  • Bushing Dimensional Profile (OEM / Direct Replacement):
    • Inner Diameter: 17.2 mm
    • Outer Fitting Diameter: 39.7 mm
    • Total Bushing Height: 80.3 mm
    • Bushing Core Width: 35.0 mm
  • Mounting Design: 4-point isolated high-density press-fit rubber damping configuration. [1, 2]
Part Numbers & Component Identifiers
  • Primary OE/OEM Reference: 54400-EW000 [1, 2]
  • Associated Left Support Link/Stay: 54525-EL000
  • Associated Right Support Link/Stay: 54524-EL000 [1]
  • Lower Control Arm Bushing Identifiers (Connects to Crossmember):
    • Large Bushing: 54570-ED500
    • Small Bushing: 54560-ED530 [1]
Platform & Vehicle Compatibility
  • Chassis Platform: Nissan B Platform.
  • Model Range/Codes: Nissan Wingroad 3rd Generation (Y12, JY12, NY12) spanning production years 2005–2018.
  • Shared Architecture: Interchanges chassis core components, internal bushing inserts, and control arm dimensions directly with the Nissan Tiida (C11) and Nissan Note (E11). [1, 2]
Powertrain & Mechanical Layout
  • Compatible Engine Layouts: 1.5L Petrol (HR15DE) and 1.8L Petrol (MR18DE).
  • Drivetrain Support: Configured for Front-Wheel Drive (FF/FWD) layouts with Continuously Variable Transmissions (CVT) or Automatic Transmissions (AT). [1, 2, 3]
Tightening Torque Specifications
  • Primary Main Subframe Cradle Bolts (4 points): 127 Nm (94 ft-lbs)
  • Subframe Stay Bracket Reinforcement Bolts: 97 Nm (72 ft-lbs)
  • Transaxle/Engine Mount Rear Torque Bracket (Pins to Subframe): 88 to 107 Nm
  • Steering Rack Gearbox to Subframe Connecting Bolts: 147 Nm (109 ft-lbs) [1, 2, 3]

Nissan NV200 Crossmember Mountain

KSh3,000.00
Component Overview & Bushing Dimensions
  • Component Type: Front Suspension Axle Subframe Crossmember / Engine Cradle. [1]
  • Material Composition: High-tensile stamped structural steel. [1]
  • Bushing Dimensional Profile:
    • Interchanges layout configurations with the Nissan Tiida platform architecture.
    • Inner Diameter: 17.2 mm
    • Outer Fitting Diameter: 39.7 mm
    • Total Bushing Height: 80.3 mm
    • Bushing Core Width: 35.0 mm [1]
  • Mounting Configuration: 4-point isolated press-fit rubber bushing mounting assembly. [1, 2]
Part Numbers & Factory Designations
  • Primary OE/OEM Reference (Front): 54400-9SA0A [1]
  • Superseded / Alternative Part Numbers:
    • 54400-3LM0A
    • 54525-JX00A (Associated Subframe Support Link/Stay - Left)
    • 54524-JX00A (Associated Subframe Support Link/Stay - Right) [1]
  • Rear Axle Crossmember Reference (If applicable): 43010-BJ00A [1]
Platform & Vehicle Compatibility
  • Chassis Platform: Nissan B Platform (Van/Commercial Variant Layout).
  • Model Range/Codes: Nissan NV200 / Evalia (M20, M20X) spanning production years 2009–2021.
  • Shared Architecture: Shares internal bushing dimensions and specific steering rack mounting geometric alignments with the Nissan Tiida (C11) and Nissan Cube (Z12) global configurations. [1, 2]
Powertrain & Alignment Baseline Specifications
  • Engine Compartment Compatibility: Built for 1.5L dCi Diesel (K9K), 1.6L Petrol (HR16DE), and 2.0L Petrol (MR20DE) engine layouts. [1]
  • Drivetrain Support: Engineered for Front-Wheel Drive (FWD) layouts across Manual, Automatic, and CVT options.
  • Factory Alignment Baseline Constraints (Unladen Crossmember Geometry):
    • Camber: 0°00' (Acceptable factory tolerance: -0°45' to +0°45')
    • Caster: 3°55' (Acceptable factory tolerance: 3°10' to 4°40')
    • Total Toe-In: 1 mm to 2 mm

Nissan Tiida Crossmember Mountain

KSh3,000.00
Component Overview & Bushing Dimensions
  • Component Type: Front Axle Subframe Member / Engine Carrier Cradle. [1, 2]
  • Material Composition: High-strength stamped structural steel.
  • Bushing Dimensional Profile (OEM / Direct Replacement):
    • Inner Diameter (A): 17.2 mm
    • Outer Fitting Diameter (B): 39.7 mm
    • Total Height/Length (C): 80.3 mm
    • Bushing Flange/Core Width (D): 35.0 mm [1]
  • Bushing Compound: Hardened high-density anti-crack rubber (OEM standard). [1]
Part Numbers & Factory Designations
  • Primary OE/OEM Reference: 54401-HV70B [1]
  • Alternative / Cross-Reference Part Numbers:
    • 54400-BB50A, 54401-6605R (Renault global platform sharing)
    • 54525-EL000 (Associated Subframe Mounting Link - Left)
    • 54524-EL000 / NSL-NM1 (Associated Subframe Mounting Link/Stay - Right) [1, 2, 3, 4]
Platform & Vehicle Compatibility
  • Chassis Platform: Nissan B Platform.
  • Model Range/Codes: Tiida / Tiida Latio Hatchback and Sedan (C11, C11X, SC11, SC11X) spanning production years 2004–2014.
  • Shared Architecture: Interchanges structural configuration attributes with the Nissan Cube (Z12) and Nissan Livina (L10/L11). [1, 2, 3, 4]
Powertrain & Alignment Specifications
  • Compatible Engine Codes: 1.5L Petrol (HR15DE), 1.6L Petrol (HR16DE), 1.8L Petrol (MR18DE), and 1.5L dCi Diesel. [1, 2, 3]
  • Drivetrain Support: Configured for Front-Wheel Drive (FWD) transmissions (Automatic, Manual, and CVT variants). [1]
  • Associated Factory Wheel Alignment Constraints (Unladen Crossmember Baseline):
    • Camber (Nominal): -0°10' (Acceptable factory range: -0°55' to +0°35')
    • Caster (Nominal): 4°35' (Acceptable factory range: 3°50' to 5°20')
    • Total Toe-In: 1 mm (Acceptable factory range: 0 mm to 2 mm) [1]

Nissan Note Model E11 Crossmember Mountain

KSh3,000.00
Component Overview & Dimensions
  • Component Type: Front Axle Subframe Crossmember / Suspension Cradle.
  • Material Composition: High-grade structural stamped steel.
  • Surface Protective Treatment: Dual-layer protection featuring a Ceramic Conversion Coating combined with an Electrophoretic (E-coat) anti-corrosion finish.
  • Bushing Fitment Specifications: Inner Diameter: 17mm | Outer Diameter: 41mm.
  • Installation Profile: Bolt-on configuration with pre-installed bushings. [1, 2, 3, 4, 5, 6, 7]
Part Numbers & Interchangability
  • Primary OE/OEM Reference: 8200371332. [1, 2]
  • Alternative & Superseded Part Numbers:
    • 544009U000, 544009U21A, 544009U22A, 544009U23A
    • 54400AX602, 54400BC10A, 54400BC11A, 54400BC12A
    • 8200475469, 8200766078, 8200766079, 8200766085, 8200500491 [1, 2]
  • Platform Compatibility: Nissan B Platform (Shared layout across Nissan Note E11/NE11 2005–2013, Nissan Micra K12, Renault Clio III, and Renault Modus). [1, 2, 3, 4]
Engine & Powertrain Matching
  • Compatible Engine Displacements: 1.4L, 1.5L, 1.6L Petrol (including HR15DE) and 1.5L dCi Diesel variants.
  • Drivetrain Layout: Front-Wheel Drive (FWD) layouts. [1, 2, 3, 4, 5]

Mazda CX5 Petrol Model 2015 Gearbox Mountain

KSh4,000.00
Part Numbers & Interchanges
  • OEM Part Numbers: GHR9-39-070, GHR9-39-070A, KD45-39-070A, KR11-39-070A
  • Aftermarket Cross-References: A4438, SKMA4438, 9813
Physical & Material Specifications
  • Mounting Type: Rubber-to-Metal Insulator Mount (Elastomer dampened, solid rubber core)
  • Chassis Bracket Material: Heavy-duty Stamped Steel / Cast Aluminum
  • Fitting Position: Left Front (Engine/Gearbox Left Side Bay, structurally positioned beneath the air intake box, ECU assembly, and battery tray)
  • Inner Bushing Diameter: 14 mm to 15 mm
  • Average Mount Width: 75 mm
  • Average Weight: Approx. 0.96 kg to 1.1 kg (insulator core only)
Installation Torque Specifications
  • Chassis Mounting Bolts (19mm socket): 131 – 153 N·m (96 – 113 lb-ft)
  • Transmission Mounting Nut (17mm socket): 54 – 62 N·m (40 – 45 lb-ft)
  • Long Main Support Through-Bolt (17mm socket): 81 – 99 N·m (60 – 73 lb-ft)

Mazda CX5 Petrol Model 2016 Gearbox Mountain

KSh4,000.00
Part Numbers & Interchanges
  • OEM Part Numbers: GHR9-39-070, GHR9-39-070A, KD45-39-070A, KR11-39-070A
  • Aftermarket Cross-References: A4438, SKMA4438, 9813 [1, 2, 3]
Physical & Material Specifications
  • Mounting Type: Rubber-to-Metal Insulator Mount (Elastomer dampened, solid rubber core)
  • Chassis Bracket Material: Heavy-duty Stamped Steel / Cast Aluminum
  • Fitting Position: Left Front (Engine/Gearbox Left Side Bay, structurally positioned beneath the air intake box, ECU assembly, and battery tray)
  • Inner Bushing Diameter: 14 mm to 15 mm
  • Average Mount Width: 75 mm
  • Average Weight: Approx. 0.96 kg to 1.1 kg (insulator core only) [1, 2, 3, 4]
Installation Torque Specifications
  • Chassis Mounting Bolts (19mm socket): 131 – 153 N·m (96 – 113 lb-ft)
  • Transmission Mounting Nut (17mm socket): 54 – 62 N·m (40 – 45 lb-ft)
  • Long Main Support Through-Bolt (17mm socket): 81 – 99 N·m (60 – 73 lb-ft) [1]

Mazda CX5 Diesel Model 2018 Gearbox Mountain

KSh4,000.00
Part Numbers & Interchanges
  • OEM Part Numbers: K123-39-070A, K123-39-070, KD45-39-070A
  • Aftermarket Cross-References: U9813, TED40312, TED98369 [1, 2]
Physical & Material Specifications
  • Mounting Type: Rubber-to-Metal Insulator Mount (Elastomer dampened structural support)
  • Chassis Bracket Material: Heavy-duty Cast Aluminum / Stamped Steel
  • Fitting Position: Left Front / Rear Left (Engine/Gearbox Left Side Bay, structurally positioned beneath the battery tray and ECU assembly)
  • Inner Bushing Diameter: 14 mm to 15 mm
  • Average Weight: Approx. 1.2 kg to 1.4 kg (complete assembly) [1, 2]
Installation Torque Specifications
  • No. 4 Engine Mount Bracket Installation Nuts (Main Frame): 92 – 116 N·m (68 – 85 lb-ft)
  • Transaxle Stud Bolts: 15 – 25 N·m (12 – 18 lb-ft)
  • Chassis Alignment Bolts (19mm socket): 131 – 153 N·m (96 – 113 lb-ft)
  • Transmission Mounting Nut (17mm socket): 54 – 62 N·m (40 – 45 lb-ft)
  • Long Main Support Through-Bolt (17mm socket): 81 – 99 N·m (60 – 73 lb-ft) [1]

Mazda CX5 Diesel Model 2017 Gearbox Mountain

KSh4,000.00
Part Numbers & Interchanges
  • OEM Part Numbers: K123-39-070A, K123-39-070, KD45-39-070A
  • Aftermarket Cross-References: TED40312, TED98369 [1, 2, 3]
Physical & Material Specifications
  • Mounting Type: Rubber-to-Metal Insulator Mount (Elastomer dampened structural mount)
  • Chassis Bracket Material: Heavy-duty Cast Aluminum / Stamped Steel
  • Fitting Position: Left Front / Rear Left (Engine/Gearbox Left Side Bay, structurally positioned beneath the battery tray and ECU assembly)
  • Inner Bushing Diameter: 14 mm to 15 mm
  • Average Weight: Approx. 1.2 kg to 1.4 kg (complete assembly) [1, 2, 3]
Installation Torque Specifications
  • No. 4 Engine Mount Bracket Installation Nuts (Main Frame): 92 – 116 N·m (68 – 85 lb-ft)
  • Transaxle Stud Bolts: 15 – 25 N·m (12 – 18 lb-ft)
  • Chassis Alignment Bolts (19mm assembly variant): 131 – 153 N·m (96 – 113 lb-ft)
  • Transmission Mounting Nut / Support Bolt: 54 – 62 N·m (40 – 45 lb-ft) [1, 2]
Showing 84 of 580 results
Please select your product
Product has been added to your cart
Compare (0)
