Nissan AD Van Driveshaft
KSh6,000.00 Buy Via WhatsappPart Numbers & Identification
- OEM Part Number (Front Left - 1.5L HR15DE): 39101-ED000 / 39101-3ZJ0C
- OEM Part Number (Front Left - 1.2L CR12DE): 39101-JJ01A
- OEM Part Number (Front Left - 1.6L HR16DE 4WD): 39101-CV20A
- Vehicle Families: VAY12 (1.2L), VY12 (1.5L), VZNY12 (1.6L 4WD)
- Compatible Engine Formats: 1.2L CR12DE, 1.5L HR15DE, 1.6L HR16DE, 1.8L MR18DE [1, 2, 3]
Drivetrain & Joint Dimensions (Standard 2WD / 1.5L CVT)
- Fitting Position: Front Axle (Left and Right specific)
- External Spline Count (Wheel / Outer Side): 25 Teeth
- Internal Spline Count (Outer CV Joint Inner Toothing): 22 Teeth
- External Spline Count (Differential / Inner Side): 25 Teeth
- Driveshaft Length (Left Side / Compressed): ~615 mm – 630 mm
- Driveshaft Length (Right Side / Compressed): ~910 mm – 915 mm (Utilizes a 2-piece setup with an intermediate extension shaft)
- Seal Journal/Ring Diameter: 49 mm
- Hub Nut Thread Size: M22 x 1.5
- Outboard Joint Type: Rzeppa (Ball-type CV Joint)
- Inboard Joint Type: Tripod Joint
Chassis & Transmission Specific Variances
- 4WD Variant (e-4WD / VZNY12 Chassis): Models powered by the 1.6L engine feature an electric 4WD system. The front shafts feature reinforced inner joints, while the rear electronic-drive half-shafts operate on a separate independent rear axle configuration with independent spline sets. [1]
- 4-Speed Automatic (Standard Transaxle): Automatic transmission variants (typically paired with the early CR12DE engines) share the 25-spline differential output profile but feature minor variances in overall rod compression lengths. [1]
Nissan Wingroad Y12 Driveshafts
KSh6,000.00 Buy Via WhatsappPart Numbers & Identification
- OEM Part Number (Front Left - HR15DE CVT): 39101-1V10C / 39101-ED000
- OEM Part Number (Front Right - HR15DE CVT): 39100-1V10C / 39100-ED000
- Vehicle Generation: Y12 Series (Wagon)
- Compatible Engine Formats: 1.5L HR15DE, 1.8L MR18DE [1, 2]
Drivetrain & Joint Dimensions
- Fitting Position: Front Axle (Left and Right specific)
- External Spline Count (Wheel / Outer Side): 25 Teeth
- Internal Spline Count (Outer CV Joint Inner Toothing): 22 Teeth
- External Spline Count (Differential / Inner Side): 25 Teeth
- Driveshaft Length (Left Side / Compressed): ~615 mm – 630 mm
- Driveshaft Length (Right Side / Compressed): ~910 mm – 915 mm (Utilizes an intermediate/extension shaft config)
- Seal Journal/Ring Diameter: 49 mm
- Hub Nut Thread Size: M22 x 1.5
- Outboard Joint Type: Rzeppa (Ball-type CV Joint)
- Inboard Joint Type: Tripod Joint [1, 2]
Transmission & Layout Differences
- CVT Variant (RE0F08A / RE0F10A): Standard 25x22x25 spline configuration.
- 4WD Variant (e-4WD / NY12 Chassis): Features distinct specifications for the rear electronic-drive half-shafts, which utilize a smaller outer joint configuration (~21-spline internal mapping on specific sub-components). [1, 2, 3]
Nissan Tiida Driveshaft
KSh6,000.00 Buy Via WhatsappPart Numbers & Identification
- OEM Part Number (Front Left - CVT/HR15DE): 39101-1V10C
- OEM Part Number (Alternative Base Cross-References): 39101-95F0C
- Vehicle Generation: C11 Series (Hatchback / Tiida Latio Sedan)
- Compatible Engine Formats: 1.5L HR15DE, 1.6L HR16DE, 1.8L MR18DE [1, 2, 3, 4]
Automatic / CVT Transmission Variant Specs
- Fitting Position: Front Axle (Left and Right specific)
- External Spline Count (Wheel / Outer Side): 25 Teeth
- External Spline Count (Differential / Inner Side): 25 Teeth
- Driveshaft Length (Right Side / Compressed): ~910 mm – 911 mm (with intermediate/extension shaft)
- Driveshaft Length (Left Side): ~615 mm – 630 mm
- Hub Nut Thread Size: M22 x 1.5
- Seal Ring Diameter: 49 mm
- Outboard Joint Type: Ball-type joint
- Inboard Joint Type: Tripod-type joint [1, 2]
Manual Transmission (6-Speed / Euro-Spec) Variant Specs
- External Spline Count (Wheel / Outer Side): 29 Teeth
- External Spline Count (Differential / Inner Side): 26 Teeth (Note: High-output diesel or MR18DE variants may utilize 29 teeth inner splines)
- Driveshaft Length (Left Side): 692 mm
- Driveshaft Length (Right Side): 941 mm
- Hub Nut Thread Size: M24 x 1.5
- Seal Ring Diameter: 56 mm [1, 2]
Toyota Passo Steering Rack
KSh9,000.00 Buy Via WhatsappPart Numbers & Identification
- OEM Part Number (1st Gen - KGC10/QNC10): 45510-B1020
- OEM Part Number (2nd Gen - NGC30/KGC30): 45502-B1094
- OEM Part Number (Alternative Cross-References): 45502-B1010, 45502-B1012, 45502-B1020
- Vehicle Compatibility: Toyota Passo (also shares assembly layout with Daihatsu Boon / Sirion)
- Drive Configuration: Right-Hand Drive (RHD) [1, 2, 3]
System Specifications
- Operating Mode: Electric Power Steering (EPS) / Manual Gear-type Rack (Assistance is managed via a column-mounted motor EPS system rather than a hydraulic rack)
- Steering Gear Type: Rack and Pinion
- Housing Material: Cast Aluminum and Structural Iron
- Steering Rack End Thread Size: M14
- Tie Rod End Thread Size: M12 x 1.25 [1, 2, 3]
Nissan Serena Model 2018 Steering Rack
KSh20,000.00 Buy Via WhatsappPart Numbers & Identification
- OEM Part Number (2WD / 4x2): 48001-5TA0A
- OEM Part Number (4WD / 4x4): 48001-5TB4A
- Vehicle Generation: C27 Series
- Compatible Engine Models: 2.0L MR20DD / MR20DD (SM24) S-Hybrid [1, 2, 3, 4]
System Specifications
- Operating Mode: Electronic Power Steering (EPS) Assembly
- Steering Gear Type: Rack and Pinion
- Input Shaft Configuration: Toothed connection with 36 teeth
- Input Shaft Diameter: 17.4 mm – 17.5 mm
- Input Shaft Height: 29.6 mm – 37 mm (depending on specific sub-supplier variance like TRW)
- Axle Joint / Tie Rod Thread Size: M12 x 1.5
- Main Housing Thread Connections: M14 x 1.5 / M16 x 1.5
Mitsubishi EK Lower Control Arms
KSh4,500.00 Buy Via WhatsappPart Identification & Cross-References
- 3rd Generation OEM Left (Driver Side): 4013A639, 4013A495 (B11W / B11A Chassis)
- 3rd Generation OEM Right (Passenger Side): 4013A640, 4013A496 (B11W / B11A Chassis)
- 2nd Generation OEM Reference: MR554647 (H82W / H81W Chassis)
- Aftermarket Substitutes: SKF 4013A495-B (Heavy-duty bush application)
- Component Assembly: Pre-assembled, triangular L-shaped unit integrating a small front horizontal pivot bushing, a large rear vertical compliance bushing, and a fixed, non-serviceable ball joint mechanism.
Physical Construction
- Body Material: High-Tensile Stamped Sheet Metal / Heavy-Gauge Pressed Steel
- Coating: Corrosion-resistant black electro-deposition coating (ED-coat)
- Ball Joint Connection: Tapered pin profile built for a cross-axis transverse pinch bolt locking method inside the wheel knuckle base.
Tightening Torque Specifications
- Front Pivot Bolt (Horizontal-to-Subframe): 74 to 85 ft-lbs (100 to 115 N·m)
- Rear Compliance Bushing Bolt (Vertical-to-Subframe): 81 to 96 ft-lbs (110 to 130 N·m)
- Lower Ball Joint Pinch Bolt to Steering Knuckle: 41 to 46 ft-lbs (55 to 62 N·m)
- Anti-Roll / Stabilizer Bar End Link to Lower Arm Nut: 26 ft-lbs (35 N·m)
- Front Wheel Lug Nuts: 76 ft-lbs (103 N·m)
Nissan Dayz Lower Control Arm
KSh4,000.00 Buy Via WhatsappPart Identification & Cross-References
- 1st Generation OEM Right (Passenger Side): 54504-6A00E, 54504-6A00G (B21W / B21A Roox)
- 1st Generation OEM Left (Driver Side): 54505-6A00J (B21W)
- 2nd Generation OEM Right/Left Reference: 54501-7MA0B (B43W, B44W, B45W, B47W chassis architecture)
- Component Assembly: Comprises a pre-pressed horizontal front pivot bushing, a larger vertical rear compliance bushing, and a factory-integrated, non-serviceable outboard lower ball joint.
Physical Construction
- Material Base: Stamped / Pressed High-Tensile Sheet Steel
- Surface Finish: Anti-corrosive black electro-deposition coating (ED-paint)
- Joint Configurations: Tapered ball joint pin designed specifically for a cross-axis horizontal pinch-bolt fitting at the steering knuckle throat base.
Tightening Torque Specifications
- Front Pivot Bolt (Horizontal to Subframe): 74 to 85 ft-lbs (100 to 115 N·m)
- Rear Compliance Bushing Bolt (Vertical to Subframe): 81 to 96 ft-lbs (110 to 130 N·m)
- Lower Ball Joint Pinch Bolt to Steering Knuckle: 41 to 46 ft-lbs (55 to 62 N·m)
- Stabilizer Bar End Link to Control Arm Base Nut: 26 ft-lbs (35 N·m)
- Front Wheel Lug Nuts: 76 ft-lbs (103 N·m)
Nissan Dayz Driveshafts
KSh5,000.00 Buy Via WhatsappPart Identification & Fitment
- 1st Gen OEM Right (Passenger/Long Side) Part Number: 39100-6A00A (B21W 2WD / 3B20 Engine)
- 1st Gen OEM Left (Driver/Short Side) Part Number: 39100-6A00B / 39101-6A00E (B21W 2WD)
- 2nd Gen OEM Left (Driver/Short Side) Part Number: 39101-7MA0A (B44W / BR06 Engine)
- Alternative Aftermarket Equivalents: HDK DS-MI-13 (Left) / HDK DS-MI-14 (Right)
- Drivetrain Variants: Separate configurations exist for Front-Wheel Drive (FF) and Full-time 4WD chassis. 4WD models employ unique length profiles and different rear axle output splines. [1, 2, 3, 4]
Physical & Joint Spline Dimensions
- Outer Spline (Wheel / Steering Knuckle Side): 21 Teeth
- Inner Spline (Differential / Transmission Side): 21 Teeth (Note: Standard manual or CVT transaxles match this count; turbo or 4WD inner joints can alter stub sizing).
- Outer Component Profile: Features an integrated ABS tone/encoder ring or specialized dynamic balancer on the longer passenger shaft.
- ABS Integration Type: Magnetic pickup or toothed rotor variant depending on production tier. [1]
Tightening Torque Specifications
- Front Axle Center Spindle Nut to Hub: 111 to 132 ft-lbs (150 to 180 N·m) (Note: Standard practice requires a brand new locking nut, which must be mechanically peened down or cotter-pinned to prevent back-out after final torquing).
- Lower Ball Joint Pinch Bolt to Steering Knuckle: 44 ft-lbs (60 N·m)
- Tie Rod End Ball Joint Nut: 25 ft-lbs (34 N·m)
- MacPherson Strut Lower Base Mounting Bracket Bolts (2x): 74 ft-lbs (100 N·m)
- Front Wheel Lug Nuts: 76 ft-lbs (103 N·m)
Daihatsu Mira Steering Rack
KSh8,000.00 Buy Via WhatsappPart Identification & Core Engineering
- OEM Reference Part Number (L275S JDM Example): 45502-B2250, 45502-B2240
- Original Equipment Manufacturer: JTEKT / Showa
- Steering Mechanism Type: Manual Rack and Pinion Gearbox (Assisted upstream by a column-mounted EPS motor)
- Vehicle Drive Layout Configurations: Applicable to Front-Wheel Drive (2WD) and All-Wheel Drive (4WD) chassis variations.
Physical & Operational Dimensions
- Total Unit Length (Excluding Outer Tie Rod Ends): 1,075 mm to 1,135 mm (Variant dependent)
- Average Dry Weight: 5.64 kg (12.43 lbs)
- Input Shaft Spline Interface: Toothed pinion shaft
- Input Shaft Height Profile: 42 mm
- Maximum Allowed Steering Wheel Free Play: 10 mm
Tightening Torque Specifications
- Steering Rack Housing-to-Crossmember/Subframe Bolts: 43 to 55 ft-lbs (59 to 75 N·m)
- Inner Tie Rod (Rack End) to Steering Rack Housing Thread: 65 to 87 ft-lbs (88 to 118 N·m)
- Inner Tie Rod Lock Nut (Outer Tie Rod Jam Nut): 33 ft-lbs (45 N·m)
- Outer Tie Rod End Ball Joint Castle Nut to Steering Knuckle: 26 to 34 ft-lbs (35 to 46 N·m)
- Steering Column Intermediate Shaft Pinion Clamping Bolt: 18 to 25 ft-lbs (24.5 to 34.3 N·m)
Subaru Forester BH5 Front Wheel Hubs
KSh6,500.00 Buy Via WhatsappComponent Part Numbers & Fitment
- OEM Wheel Hub Spindle Part Number: 28362AE001, 28362AE000
- OEM Wheel Bearing Part Number: 28316FE000 (Double-row angular contact ball bearing / tapered roller bearing)
- OEM Inner Oil Seal (Axle Side): 28015AA070
- OEM Outer Oil Seal (Wheel Side): 28015AA080
- Chassis Application: BH5 JDM variants including Brighten, TX, TS-R, and GT-B E-Tune (EJ202, EJ204, and Twin-Turbo EJ208 platforms).
Physical & Dimensional Specifications
- Wheel Bolt Pattern (PCD): 5 x 100 mm
- Hub Flange Outer Diameter: 124 mm
- Wheel Stud Bolt Size: M12 x 1.25
- Input Shaft Spline Count (Drive Axle Interface): 27 Teeth
- Bearing Inner Diameter: 42 mm
- Bearing Outer Diameter: 72 mm
- Bearing Width: 38 mm (Inner track) / 35 mm (Outer track) [1]
Tightening Torque Specifications
- Front Axle Center Locknut: 137 ft-lbs (186 N·m) (Note: Always use a new axle nut and peen the locking collar firmly into the axle shaft slot after torquing).
- Strut-to-Steering Knuckle Clevis Bolts (2x 19mm): 129 ft-lbs (175 N·m) (The upper bolt features an eccentric cam lobe used to set front camber alignment).
- Lower Ball Joint Pinch Bolt (to Knuckle Base): 37 ft-lbs (50 N·m) [1]
- Tie Rod End Castle Nut to Knuckle Assembly: 19 ft-lbs (26 N·m) (Tighten up to 22 ft-lbs max only to align cotter pin window).
- Brake Caliper Torque Bracket-to-Knuckle Bolts: 59 ft-lbs (80 N·m) [1]
- Front Wheel Lug Nuts: 89 ft-lbs (120 N·m)
Subaru Forester SG5 Front Wheel Hubs
KSh6,500.00 Buy Via WhatsappComponent Part Numbers & Fitment
- OEM Wheel Hub Spindle Part Number: 28362AE001, 28362AE000
- OEM Wheel Bearing Part Number: 28316FE000 (Double-row angular contact ball bearing / tapered roller bearing)
- OEM Inner Oil Seal (Axle Side): 28015AA070
- OEM Outer Oil Seal (Wheel Side): 28015AA080
- Chassis Application: SG5 2.0L N/A (EJ202), 2.0XT Turbo (EJ205), and cross-compatible JDM/Cross Sports variants.
Physical & Dimensional Specifications
- Wheel Bolt Pattern (PCD): 5 x 100 mm
- Hub Flange Outer Diameter: 124 mm
- Wheel Stud Bolt Size: M12 x 1.25
- Input Shaft Spline Count (Drive Axle Interface): 27 Teeth
- Bearing Inner Diameter: 42 mm
- Bearing Outer Diameter: 72 mm
- Bearing Width: 38 mm (Inner track) / 35 mm (Outer track) [1, 2]
Tightening Torque Specifications
- Front Axle Spindle Center Locknut: 137 ft-lbs (186 N·m) (Note: Always use a new axle nut and peen the locking collar firmly into the axle shaft slot after torquing).
- Strut-to-Steering Knuckle Clevis Bolts (2x 19mm): 129 ft-lbs (175 N·m) (The upper bolt features an eccentric cam lobe used to set front camber alignment). [1, 2]
- Lower Ball Joint Pinch Bolt (to Knuckle Base): 37 ft-lbs (50 N·m) [1, 2]
- Tie Rod End Castle Nut to Knuckle Assembly: 19 ft-lbs (26 N·m) (Tighten up to 22 ft-lbs max only to align cotter pin window). [1]
- Brake Caliper Torque Bracket-to-Knuckle Bolts: 59 ft-lbs (80 N·m) [1]
- Front Wheel Lug Nuts: 89 ft-lbs (120 N·m)[1]
Mitsubishi Mirage Ex-Japan Shocks
KSh6,000.00 Buy Via WhatsappDamper Core Technology & Fitment
- Chassis Codes Covered: DBA-A03A (1.2L 3G12 Engine) and DBA-A05A (1.0L 3G10 Engine)
- Internal Valve Architecture: Low-pressure Nitrogen gas-charged, Twin-Tube hydraulic design
- Front Damping Design: Integrated MacPherson structural suspension strut with top-pin mounting
- Rear Damping Design: Standard telescopic double-acting shock absorber with top-pin/bottom-eye mounting [1, 2, 3]
Part Identification & Cross-References
- OEM Front Strut Reference: 4060A493, 4060A243, 4060A244
- OEM Rear Shock Reference: 4162A395, 4162A199
- KYB Aftermarket Equivalent (Front R/L Interchange): 3320010 / 3320014
- KYB Aftermarket Equivalent (Rear R/L Interchange): 3420010 [1, 2, 3]
Physical & Dimensional Profiles
- Front Strut Assembly Shell Diameter: 51 mm
- Front Strut Internal Piston Rod Diameter: 22 mm
- Front Strut Total Length Profile: 532 mm extended / 383 mm collapsed
- Rear Shock Ext. Flange Cylinder Diameter: 53 mm
- Rear Shock Working Envelope Length: 550 mm maximum extension / 375 mm minimum collapse [1]
Chassis Torque Specifications
- Front Upper Strut Tower Top Flange Nuts (3x): 33 ft-lbs (45 N·m)
- Front Strut Center Piston Shaft Locknut: 44 ft-lbs (60 N·m)
- Front Lower Strut Bracket-to-Knuckle Bolts (2x): 81 ft-lbs (110 N·m)
- Front Brake Hose Bracket Bolt to Strut Body: 7 ft-lbs (10 N·m)
- Rear Upper Shock Access Nut (Inside Cabin): 18 ft-lbs (25 N·m)
- Rear Lower Shock Eye Bolt (To Trailing Arm): 74 ft-lbs (100 N·m)
Toyota Markx GRX 130 Front Wheel Hubs
KSh6,500.00 Buy Via WhatsappPart Identification & Cross-References
- OEM Right (Passenger Side) Part Number: 43550-30010, 43550-30011, 43550-30020
- OEM Left (Driver Side) Part Number: 43560-30010, 43560-30011
- Aftermarket Substitutes: KOYO 3DACF027F-8BS, FEBEST 0182-XFRH
- Platform Compatibility: Rear-Wheel Drive (2WD) chassis codes ONLY (GRX130 2.5L and GRX133 3.5L models). (Note: GRX135 4WD models use a different front hub profile to accommodate an outboard CV axle stub shaft).
Physical & Structural Dimensions
- Assembly Type: Generation 3 Complete Bolt-on Hub Unit (fully sealed double-row angular contact ball bearing pre-assembled to the mounting flange).
- Wheel Bolt Pattern (PCD): 5 x 114.3 mm (5 x 4.5 inches)
- Hub Center Bore Diameter: 60.1 mm
- Flange Outer Diameter: 140 mm
- Wheel Stud Specification: M12 x 1.5 threaded studs (5 per hub)
- ABS Integration: Internal magnetic encoder ring built into the inner bearing race dust seal (accessible via a dedicated sensor channel on the steering knuckle frame).
- Total Component Weight: ~4.90 kg (10.8 lbs)
Tightening Torque Specifications
- Hub Assembly-to-Steering Knuckle Mounting Bolts (4x): 51 ft-lbs (69 N·m)
- Brake Caliper Mounting Bracket-to-Knuckle Bolts: 58 ft-lbs (79 N·m)
- Front Wheel Lug Nuts: 76 ft-lbs (103 N·m)
Toyota Markx GRX 120 Front Wheel Hubs
KSh6,500.00 Buy Via WhatsappPart Identification & Interchanges
- OEM Right (Passenger Side) Part Number: 43550-30010, 43550-30011
- OEM Left (Driver Side) Part Number: 43560-30010, 43560-30011
- Alternative Brand Interchanges: KOYO 3DACF027F-8BS, SKF VKBA 6953, FeBest 0182-XFRH
- Platform Shared Fitments: Toyota Crown (GRS180), Lexus GS300/GS350 (GRS190/GWS191), Lexus IS250/IS350 (GSE20/GSE21) (Note: Specifications listed are strictly for Rear-Wheel Drive (2WD) models). [1, 2, 3]
Physical & Dimensional Specifications
- Assembly Construction Type: Flanged hub unit with an integrated, sealed double-row angular contact ball bearing assembly
- Outer Diameter (Flange): 140 mm
- Wheel Bolt Pattern (PCD): 5 x 114.3 mm (5 x 4.5 inches)
- Wheel Stud Bolt Thread Pitch: M12 x 1.5
- Number of Rim Mounting Holes: 5
- Brake Sensor Integration: Built-in internal magnetic encoder wheel with a dedicated port for the ABS wheel speed sensor wiring harness. [1, 2]
Tightening Torque Specifications
- Hub Assembly-to-Steering Knuckle Mounting Bolts (4x): 51 ft-lbs (69 N·m)
- Brake Caliper Mounting Bracket-to-Knuckle Bolts: 58 ft-lbs (79 N·m)
- Front Wheel Lug Nuts: 76 ft-lbs (103 N·m)
Subaru Legacy B4 Bilstain Shocks
KSh8,000.00 Buy Via WhatsappDamper Core Technology & Design
- Front Internal Layout: Upside-down (Inverted) Monotube Gas Pressure strut assembly (Bilstein patented setup for extreme structural rigidity under high cornering loads).
- Rear Internal Layout: Standard Monotube Gas Pressure or Twin-tube (Variant-dependent, e.g., standard B4 replacement). [1, 2]
- Damping Mechanism: Self-adjusting multi-stage valving (degressive piston design provides higher damping force at low speeds for chassis control, and softer force at high speeds to absorb bumps).
- Gas Type: High-pressure Nitrogen charged to prevent fluid cavitation/foaming under rapid cycling. [1, 2]
OEM Reference Part Numbers (JDM Legacy B4 Spec-B BL5/BP5)
- Front Right (Inverted Monotube): 20310AG420 / VE3-B831 (Bilstein B6 Heavy Duty alternate)
- Front Left (Inverted Monotube): 20310AG430 / VE3-B832
- Rear Damper Assembly: 20365AG260 / BE5-B833
- Standard Bilstein Aftermarket B4 Line (Non-Inverted OE Replacement): Front Right: 22-165572 | Rear: 19-158686. [1, 2]
Physical Dimensions (Bilstein Rear B4 Example)
- Collapsed Length: 255.5 mm (10.06 in)
- Extended Length: 400.5 mm (15.77 in)
- Stroke Profile: Shortened travel window on JDM B4 Spec-B models compared to the standard USDM non-Bilstein Legacy chassis.
- Lower Mount Interface: Eyelet bushing
- Upper Mount Interface: Stem thread [1]
Chassis Interface & Torque Specifications
- Front Upper Strut Top Hat Mount Nuts (3x): 14.5 ft-lbs (20 N·m)
- Front Strut Piston Center Top Nut: 41 ft-lbs (56 N·m)
- Front Lower Strut Mount Clevis Bolts (to Knuckle - 2x): 114 to 129 ft-lbs (155 to 175 N·m) (Note: Upper bolt functions as the factory camber eccentric alignment cam).
- Rear Upper Strut Top Hat Mount Nuts: 22 ft-lbs (30 N·m)
- Rear Lower Strut Mount-to-Trailing Arm Bolt: 88.5 to 110 ft-lbs (120 to 150 N·m) [1, 2]
Factory Spring Rates (Spec-B Bilstein Pairings)
- Front Spring Rate: ~3.2 kg/mm to 3.8 kg/mm (Linear rate configuration)
- Rear Spring Rate: ~4.0 kg/mm to 4.8 kg/mm (Progressive/Linear multi-link arrangement) [1]
Mazda CX3 Lower Control Arms
KSh6,000.00 Buy Via WhatsappPart Identification & Platform Fitment
-
- OEM Right (Passenger Side) Part Number: D10E-34-300 (2015–2018) / D24H-34-300C (2018–2021) [1, 2]
- OEM Left (Driver Side) Part Number: D10E-34-350 (2015–2018) / D24H-34-350C (2018–2021) [1, 2, 3]
- Design Type: Triangular A-Arm / L-Shaped Lower Suspension Arm
- Component Assembly: One-piece stamped high-tensile steel frame with pre-pressed inner horizontal pivot rubber bushing, an outer rear compliance vertical bushing, and a non-serviceable factory-integrated lower ball joint. [1, 2]
- Drivetrain Compatibility: Direct replacement fitment for both Front-Wheel Drive (FWD) and All-Wheel Drive (AWD) variants across 1.5L TD, 1.8L TD, and 2.0L SkyActiv-G engines. [1, 2]
Component Construction & Mass Dimensions
-
- Material Treatment: Electro-deposition (ED) coating/painting for anti-corrosion resistance
- Average Shipping Weight: ~3.65 kg (8.05 lbs) per side
- Ball Joint Stud Profile: Tapered pin, designed for a cross-axis pinch bolt fixing mechanism on the steering knuckle housing. [1]
Tightening Torque Specifications
-
- Front (Horizontal Pivot) Bushing Bolt to Subframe: 97 to 116 N·m (72 to 85 ft-lbs)
- Rear (Vertical Compliance Bushing) Retaining Bracket Bolts: 130 to 154 N·m (96 to 113 ft-lbs)
- Lower Ball Joint Pinch Bolt to Steering Knuckle: 44 to 53 N·m (33 to 39 ft-lbs)
- Front Anti-Roll / Stabilizer Bar End Link to Lower Arm Nut: 44 to 53 N·m (33 to 39 ft-lbs)
Honda Airwave Lower Arm Control
KSh4,000.00 Buy Via WhatsappPart Identification & Fitment
- OEM Right (Passenger Side) Part Number: 51350-SLA-023, 51350-SLA-033
- OEM Left (Driver Side) Part Number: 51360-SLA-023, 51360-SLA-J04
- Design Type: Triangular L-shaped A-arm
- Component Assembly: Rigid steel body with a pre-installed horizontal pivot bushing (front), a vertical compliance bushing (rear), and an integrated non-serviceable lower ball joint. [1, 2, 3, 4]
Physical Dimensions (Standard Aftermarket Market Multi-Fit)
- Material: Pressed Steel
- Length: 480 mm
- Width: 400 mm
- Height: 87 mm
- Average Weight: ~4.51 kg (9.9 lbs) [1]
Fastener Torque Specifications
- Front (Horizontal) Control Arm-to-Subframe Bolt: 40 ft-lbs (54 Nm)
- Rear (Vertical) Compliance Bushing-to-Subframe Bolt: 61 ft-lbs (83 Nm)
- Lower Ball Joint Castle Nut to Steering Knuckle: 36 to 43 ft-lbs (49 to 59 Nm) (Note: Tighten further within this range only to align the castle nut slot with the ball joint cotter pin hole).
- Stabilizer / Sway Bar End Link to Lower Arm Nut: 22 ft-lbs (30 Nm)
Mitsubishi Colt Lower Arms Control
KSh4,000.00 Buy Via WhatsappPart Identification & Fitment
- OEM Left (Driver Side) Part Number: MN101373 (Varies slightly by engine variant)
- OEM Right (Passenger Side) Part Number: MN101374
- Design Type: Triangular A-Arm for independent MacPherson strut front suspension.
- Component Assembly: Sheet metal or hardened steel construction featuring a pre-installed inner horizontal pivot bushing, an outer rear vertical compliance bushing, and an integrated lower ball joint. [1, 2, 3, 4]
Component Dimensions & Interface
- Material Type: Pressed Sheet Metal / Hardened Steel
- Component Mass: ~3.78 kg (8.32 lbs)
- Ball Joint Cone Size: Ø 15 mm
- Ball Joint Pin Thread: M12 x 1.5
- Ball Joint Starting Torque: 0 to 3.9 N·m (0 to 2.9 ft-lbs) [1, 2, 3]
Fastener Torque Specifications
- Rear (Vertical) Control Arm-to-Subframe Fastener: 145 N·m (107 ft-lbs)
- Front (Horizontal) Control Arm-to-Subframe Pivot Bolt: 115 N·m (85 ft-lbs)
- Lower Ball Joint Pinch Bolt to Steering Knuckle: 52 to 60 N·m (38 to 44 ft-lbs)
- Anti-Roll Bar / Stabilizer Link to Lower Arm Nut: 30 N·m (22 ft-lbs) [1, 2]
Standard Front Wheel Alignment Specifications
- Toe-In: 0 ± 2 mm (Toe angle: 0°00' ± 0°06')
- Camber: -0°30' ± 0°30'
- Caster: 2°35' ± 0°30'
- Kingpin Inclination: 13°20' ± 0°30'[1]
Honda Insight Model 2014 Lower Control Arm
KSh4,000.00 Buy Via WhatsappPart Numbers & Placement
- OEM Right (Passenger Side) Part Number: 51350-TM8-A01
- OEM Left (Driver Side) Part Number: 51360-TM8-A01
- Design Type: A-shape / Triangular lower suspension arm
- Component Assembly: Fully integrated unit containing the lower control arm body, compliance rubber bushings, and an integrated non-serviceable lower ball joint. [1, 2, 3, 4, 5]
Physical Dimensions (Standard Aftermarket Market Multi-Fit)
- Material: Sheet Steel
- Length: 590 mm
- Width: 320 mm
- Height: 90 mm [1]
Fastener Torque Specifications
- Front (Horizontal) Control Arm-to-Subframe Bolt: 54 ft-lbs (73 Nm)
- Rear (Vertical) Compliance Bushing-to-Subframe Bolts: 51 ft-lbs (69 Nm)
- Ball Joint Castle Nut to Steering Knuckle: 40 to 47 ft-lbs (54 to 64 Nm) (Note: Tighten further if needed only to align the castle nut gaps with the ball joint hole to insert a new cotter pin).
- Control Arm Guard/Splash Plate Bolts: 16 ft-lbs (22 Nm)
Honda Insight Model 2013 Lower Control Arm
KSh4,000.00 Buy Via WhatsappOEM / Reference Part Numbers
- Front Left Side (LHS): 51360-TK6-A01 / 51360-TF5-A00
- Front Right Side (RHS): 51350-TK6-A01 / 51350-TF5-A00
Dimensional Specifications
- Arm Segment Length: 357 mm
- Ball Joint Cone Size / Pivot Diameter: Ø 17.5 mm
- Ball Pin / Joint External Thread Size: M14 x 1.5 Right-Hand Thread (RHT)
- Subframe Mounting Alignment: Configured for standard factory 17 mm and 19 mm hex flange fasteners.
Material & Component Properties
- Structural Material: High-tensile stamped sheet steel matrix engineered for strict vehicle weight reduction and crash safety energy absorption.
- Pre-assembled Bushings: Features a large, rearward horizontal rubber compliance damper ("hockey puck" style bushing) paired with a forward horizontal steel sleeve inner bushing to manage vehicle NVH (Noise, Vibration, and Harshness).
- Ball Joint Assembly: Integrated pre-greased, sealed heavy-duty lower ball joint with a high-flexibility protective rubber dust boot.
- Surface Coating: High-durability black anti-corrosion electro-deposition paint (E-coating) for maximum rust resistance.
- Net Unit Weight: ~3.24 kg (7.14 lbs) per bare side arm assembly.
Honda Insight Model 2012 Lower Control Arm
KSh4,000.00 Buy Via WhatsappOEM / Reference Part Numbers
- Front Left Side (LHS): 51360-TK6-A01 / 51360-TF5-A00
- Front Right Side (RHS): 51350-TK6-A01 / 51350-TF5-A00
Dimensional Specifications
- Arm Segment Length: 357 mm
- Ball Joint Cone Size / Pivot Diameter: Ø 17.5 mm
- Ball Pin / Joint External Thread Size: M14 x 1.5 Right-Hand Thread (RHT)
- Subframe Mounting Alignment: Configured for standard factory 17 mm and 19 mm hex flange fasteners.
Material & Component Properties
- Structural Material: High-tensile stamped sheet steel matrix engineered for strict vehicle weight reduction and crash safety energy absorption.
- Pre-assembled Bushings: Features a large, rearward horizontal rubber compliance damper ("hockey puck" style bushing) paired with a forward horizontal steel sleeve inner bushing to manage vehicle NVH (Noise, Vibration, and Harshness).
- Ball Joint Assembly: Integrated pre-greased, sealed heavy-duty lower ball joint with a high-flexibility protective rubber dust boot.
- Surface Coating: High-durability black anti-corrosion electro-deposition paint (E-coating) for maximum rust resistance.
- Net Unit Weight: ~3.24 kg (7.14 lbs) per bare side arm assembly.
Honda Insight Model 2011 Lower Control Arm
KSh4,000.00 Buy Via WhatsappOEM / Reference Part Numbers
- Front Left Side (LHS): 51360-TK6-A01 / 51360-TF5-A00
- Front Right Side (RHS): 51350-TK6-A01 / 51350-TF5-A00 [1, 2, 3]
Dimensional Specifications
- Arm Segment Length: 357 mm (Note: Total packaged box profile length spans up to 590 mm)
- Ball Joint Cone Size / Pivot Diameter: Ø 17.5 mm
- Ball Pin / Joint External Thread Size: M14 x 1.5 Right-Hand Thread (RHT)
- Subframe Mounting Alignment: Configured for standard factory 17 mm and 19 mm hex flange fasteners. [1, 2]
Material & Component Properties
- Structural Material: High-tensile stamped sheet steel matrix engineered for strict vehicle weight reduction and crash safety energy absorption. [1]
- Pre-assembled Bushings: Features a large, rearward horizontal rubber compliance damper ("hockey puck" style bushing) paired with a forward horizontal steel sleeve inner bushing to manage vehicle NVH (Noise, Vibration, and Harshness). [1]
- Ball Joint Assembly: Integrated pre-greased, sealed heavy-duty lower ball joint with a high-flexibility protective rubber dust boot. [1, 2]
- Surface Coating: High-durability black anti-corrosion electro-deposition paint (E-coating) for maximum rust resistance.
- Net Unit Weight: ~3.24 kg (7.14 lbs) per bare side arm assembly. [1]
Honda Insight Model 2010 Lower Control Arm
KSh4,000.00 Buy Via WhatsappOEM / Reference Part Numbers
- Front Left Side (LHS): 51360-TK6-A01 / 51360-TF5-A00 / 51360-TG5-C01
- Front Right Side (RHS): 51350-TK6-A01 / 51350-TF5-A00 / 51350-TM8-A01 / 51350-TG5-C01 [1, 2, 3]
Dimensional Specifications
- Ball Joint Cone Size / Pivot Diameter: Ø 17.5 mm
- Ball Pin / Joint External Thread Size: M14 x 1.5
- Subframe Flange Mounting Bolt Compatibility: Matches 17 mm and 19 mm factory hex flange bolt configurations.
Material & Component Properties
- Structural Material: Heavy-duty stamped sheet steel matrix engineered for optimized vehicle weight distribution and strength.
- Pre-assembled Bushings: Features a large, rearward horizontal rubber compliance damper ("hockey puck" style bushing) paired with a forward horizontal inner steel sleeve bushing to absorb road vibrations and isolate Cabin NVH (Noise, Vibration, and Harshness). [1, 2]
- Ball Joint Assembly: Integrated pre-greased, sealed heavy-duty lower ball joint with a high-flexibility protective rubber dust boot. [1]
- Surface Coating: High-durability black anti-corrosion electro-deposition paint (E-coating) for rust prevention.
- Net Unit Weight: ~3.3 kg to 4.7 kg per side (depending on whether it is a bare aftermarket steel variant or a complete factory assembly with bracket layout). [1, 2]
Honda Fit Model 2014 Lower Control Arm
KSh4,000.00 Buy Via WhatsappOEM / Reference Part Numbers
- Third Generation (GK Series – GK5 Chassis, Late 2014+):
- Front Right Side (RHS): 51350-T5G-H01 / 51350-T5R-A00
- Front Left Side (LHS): 51360-T5G-H01 / 51360-T5R-A00 [1]
- Second Generation (GE Series – GE6 / GE8 / GP1, Early 2014 Production):
Dimensional Specifications
- Second Generation (GE Chassis):
- Ball Joint Cone Size / Pivot Diameter: Ø 17.5 mm
- Ball Pin / Joint External Thread Size: M14 x 1.5
- Net Unit Weight: ~3.3 kg (7.27 lbs) per side [1]
- Third Generation (GK Chassis):
- Ball Joint Cone Size: Ø 16 mm
- Ball Pin / Joint External Thread Size: M12 x 1.25
- Net Unit Weight: ~3.1 kg (6.83 lbs) per side
Material & Component Properties
- Structural Material: Heavy-duty stamped sheet steel / structural metal matrix.
- Pre-assembled Bushings: Features a large, rearward horizontal compliance damper ("hockey puck" style rubber bushing) paired with a forward horizontal inner sleeve bushing to isolate NVH.
- Ball Joint Assembly: Integrated pre-greased, sealed heavy-duty lower ball joint with a protective rubber dust boot.
- Surface Coating: High-durability black anti-corrosion electro-deposition paint (E-coating) or powder finish. [1, 2, 3]
Honda Fit Model 2013 Lower Control Arm
KSh4,000.00 Buy Via WhatsappOEM / Reference Part Numbers
- Front Left Side (LHS): 51360-TF0-030 / 51360-TK6-A01 / 51360-TF5-A00
- Front Right Side (RHS): 51350-TF0-030 / 51350-TK6-A01 / 51350-TF5-A00
Dimensional Specifications
- Ball Joint Cone Size / Pivot Diameter: Ø 17.5 mm
- Ball Pin / Joint External Thread Size: M14 x 1.5
- Subframe Flange Mounting Bolt Sizing: 17 mm and 19 mm hex flange bolts
Material & Component Properties
- Structural Material: Heavy-duty stamped sheet steel / structural metal matrix.
- Pre-assembled Bushings: Features a large, rearward horizontal hydraulic/rubber cylindrical compliance damper ("hockey puck" style bushing) paired with a forward horizontal inner sleeve bushing to isolate NVH (Noise, Vibration, and Harshness).
- Ball Joint Assembly: Integrated pre-greased, sealed heavy-duty lower ball joint with a protective rubber dust boot.
- Surface Coating: High-durability black anti-corrosion electro-deposition paint (E-coating).
- Net Unit Weight: ~3.3 kg (7.27 lbs) per side.
Honda Fit Model 2012 Lower Control Arm
KSh4,000.00 Buy Via WhatsappOEM / Reference Part Numbers
- Front Left Side (LHS): 51360-TF0-030 / 51360-TK6-A01 / 51360-TF5-A00
- Front Right Side (RHS): 51350-TF0-030 / 51350-TK6-A01 / 51350-TF5-A00
Dimensional Specifications
- Ball Joint Cone Size / Pivot Diameter: Ø 17.5 mm
- Ball Pin / Joint External Thread Size: M14 x 1.5
- Subframe Flange Mounting Bolt Sizing: 17 mm and 19 mm hex flange bolts
Material & Component Properties
- Structural Material: Heavy-duty stamped sheet steel / structural metal matrix.
- Pre-assembled Bushings: Features a large, rearward horizontal hydraulic/rubber cylindrical compliance damper ("hockey puck" style bushing) paired with a forward horizontal inner sleeve bushing to isolate NVH (Noise, Vibration, and Harshness).
- Ball Joint Assembly: Integrated pre-greased, sealed heavy-duty lower ball joint with a protective rubber dust boot.
- Surface Coating: High-durability black anti-corrosion electro-deposition paint (E-coating).
- Net Unit Weight: ~3.3 kg (7.27 lbs) per side.
Honda Fit Model 2011 Lower Control Arm
KSh4,000.00 Buy Via WhatsappOEM / Reference Part Numbers
- Front Left Side (LHS): 51360-TF0-030 / 51360-TK6-A01 / 51360-TF5-A00
- Front Right Side (RHS): 51350-TF0-030 / 51350-TK6-A01 / 51350-TF5-A00
Dimensional Specifications
- Ball Joint Cone Size / Pivot Diameter: Ø 17.5 mm
- Ball Pin / Joint External Thread Size: M14 x 1.5
- Subframe Flange Mounting Bolt Sizing: 17 mm and 19 mm hex flange bolts
Material & Component Properties
- Structural Material: Heavy-duty stamped sheet steel / structural metal matrix.
- Pre-assembled Bushings: Features a large, rearward horizontal hydraulic/rubber cylindrical compliance damper ("hockey puck" style bushing) paired with a forward horizontal inner sleeve bushing to isolate NVH (Noise, Vibration, and Harshness).
- Ball Joint Assembly: Integrated pre-greased, sealed heavy-duty lower ball joint with a protective rubber dust boot.
- Surface Coating: High-durability black anti-corrosion electro-deposition paint (E-coating).
- Net Unit Weight: ~3.3 kg (7.27 lbs) per side.
Honda Fit Model 2010 Lower Control Arm
KSh4,000.00 Buy Via WhatsappOEM / Reference Part Numbers
- Front Left Side (LHS / Driver Side): 51360-TF0-030 / 51360-TK6-A01 / 51360-TF5-A00
- Front Right Side (RHS / Passenger Side): 51350-TF0-030 / 51350-TK6-A01 / 51350-TF5-A00 [1, 2, 3, 4]
Dimensional Specifications
- Ball Joint Cone Size: Ø 17.5 mm
- Ball Pin / Joint External Thread: M14 x 1.5
- Subframe Flange Mounting Bolt Sizing: 17 mm and 19 mm hex flange bolts [1, 2]
Material & Component Properties
- Structural Material: Heavy-duty stamped sheet steel / structural metal matrix.
- Pre-assembled Bushings: Features a large, rearward horizontal hydraulic/rubber cylindrical damper ("hockey puck" style bushing) paired with a forward horizontal inner sleeve bushing to isolate NVH (Noise, Vibration, and Harshness).
- Ball Joint Assembly: Integrated pre-greased, sealed heavy-duty lower ball joint with a protective rubber dust boot.
- Surface Coating: High-durability black anti-corrosion electro-deposition paint (E-coating).
- Net Unit Weight: ~3.3 kg (7.27 lbs) per side.[1, 2, 3, 4, 5]
Showing 56 of 580 results
