Mazda CX5 Petrol Model 2016 Gearbox Mountain
KSh4,000.00 Buy Via WhatsappPart Numbers & Interchanges
- OEM Part Numbers:
GHR9-39-070,GHR9-39-070A,KD45-39-070A,KR11-39-070A - Aftermarket Cross-References:
A4438,SKMA4438,9813[1, 2, 3]
Physical & Material Specifications
- Mounting Type: Rubber-to-Metal Insulator Mount (Elastomer dampened, solid rubber core)
- Chassis Bracket Material: Heavy-duty Stamped Steel / Cast Aluminum
- Fitting Position: Left Front (Engine/Gearbox Left Side Bay, structurally positioned beneath the air intake box, ECU assembly, and battery tray)
- Inner Bushing Diameter: 14 mm to 15 mm
- Average Mount Width: 75 mm
- Average Weight: Approx. 0.96 kg to 1.1 kg (insulator core only) [1, 2, 3, 4]
Installation Torque Specifications
- Chassis Mounting Bolts (19mm socket): 131 – 153 N·m (96 – 113 lb-ft)
- Transmission Mounting Nut (17mm socket): 54 – 62 N·m (40 – 45 lb-ft)
- Long Main Support Through-Bolt (17mm socket): 81 – 99 N·m (60 – 73 lb-ft) [1]
Mazda CX5 Diesel Model 2018 Gearbox Mountain
KSh4,000.00 Buy Via WhatsappPart Numbers & Interchanges
- OEM Part Numbers:
K123-39-070A,K123-39-070,KD45-39-070A - Aftermarket Cross-References:
U9813,TED40312,TED98369[1, 2]
Physical & Material Specifications
- Mounting Type: Rubber-to-Metal Insulator Mount (Elastomer dampened structural support)
- Chassis Bracket Material: Heavy-duty Cast Aluminum / Stamped Steel
- Fitting Position: Left Front / Rear Left (Engine/Gearbox Left Side Bay, structurally positioned beneath the battery tray and ECU assembly)
- Inner Bushing Diameter: 14 mm to 15 mm
- Average Weight: Approx. 1.2 kg to 1.4 kg (complete assembly) [1, 2]
Installation Torque Specifications
- No. 4 Engine Mount Bracket Installation Nuts (Main Frame): 92 – 116 N·m (68 – 85 lb-ft)
- Transaxle Stud Bolts: 15 – 25 N·m (12 – 18 lb-ft)
- Chassis Alignment Bolts (19mm socket): 131 – 153 N·m (96 – 113 lb-ft)
- Transmission Mounting Nut (17mm socket): 54 – 62 N·m (40 – 45 lb-ft)
- Long Main Support Through-Bolt (17mm socket): 81 – 99 N·m (60 – 73 lb-ft) [1]
Mazda CX5 Diesel Model 2017 Gearbox Mountain
KSh4,000.00 Buy Via WhatsappPart Numbers & Interchanges
- OEM Part Numbers:
K123-39-070A,K123-39-070,KD45-39-070A - Aftermarket Cross-References:
TED40312,TED98369[1, 2, 3]
Physical & Material Specifications
- Mounting Type: Rubber-to-Metal Insulator Mount (Elastomer dampened structural mount)
- Chassis Bracket Material: Heavy-duty Cast Aluminum / Stamped Steel
- Fitting Position: Left Front / Rear Left (Engine/Gearbox Left Side Bay, structurally positioned beneath the battery tray and ECU assembly)
- Inner Bushing Diameter: 14 mm to 15 mm
- Average Weight: Approx. 1.2 kg to 1.4 kg (complete assembly) [1, 2, 3]
Installation Torque Specifications
Mazda CX5 Diesel Model 2016 Gearbox Mountain
KSh4,000.00 Buy Via WhatsappPart Numbers & Interchanges
Physical & Material Specifications
-
- Mounting Type: Rubber-to-Metal Insulator Mount (Solid/Elastomer dampened)
- Chassis Bracket Material: Heavy-duty Stamped Steel / Cast Aluminum
- Fitting Position: Left Front (Engine/Gearbox Left Side Bay, underneath the battery tray/ECU assembly)
- Inner Bushing Diameter: 14 mm to 15 mm
- Average Mount Width: 75 mm
- Average Weight: Approx. 0.96 kg to 1.1 kg (insulator core only) [1, 2, 3]
Installation Torque Specifications
- Chassis Mounting Bolts (19mm socket): 131 – 153 N·m (96 – 113 lb-ft)
- Transmission Mounting Nut (17mm socket): 54 – 62 N·m (40 – 45 lb-ft)
- Long Main Support Through-Bolt (17mm socket): 81 – 99 N·m (60 – 73 lb-ft) [1]
Mazda CX5 Diesel Model 2015 Gearbox Mountain
KSh4,000.00 Buy Via WhatsappPart Numbers & Interchanges
Physical & Material Specifications
-
- Mounting Type: Rubber-to-Metal Insulator Mount (Elastomer dampened)
- Chassis Bracket Material: Heavy-duty Stamped Steel / Cast Aluminum
- Fitting Position: Left Front (Engine/Gearbox Left Side Bay, beneath the battery tray/ECU assembly)
- Inner Bushing Diameter: 14 mm to 15 mm
- Average Mount Width: 75 mm
- Average Weight: Approx. 0.96 kg to 1.1 kg (insulator core only) [1, 2, 3, 4, 5, 6]
Installation Torque Specifications
- Chassis Mounting Bolts (19mm socket): 131 – 153 N·m (96 – 113 lb-ft)
- Transmission Mounting Nut (17mm socket): 54 – 62 N·m (40 – 45 lb-ft)
- Long Main Support Through-Bolt (17mm socket): 81 – 99 N·m (60 – 73 lb-ft) [1]
Mazda CX5 Model 2015 Gearbox Mountain
KSh4,000.00 Buy Via Whatsapp1. Component Breakdown & OEM Part Numbers
The 2015 Mazda CX-5 utilizes a multi-point SkyActiv powertrain isolation layout, relying on two distinct mounting components directly responsible for holding and stabilizing the gearbox assembly:
- Left-Hand Gearbox Mount (Transmission Main Insulator):
- OEM Part Numbers:
BJS7-39-070/GHR9-39-070B/KD47-39-070 - Function: Primary weight-bearing insulator for the transmission housing. It fastens the gearbox structural casing to the left frame rail to isolate high-frequency driveline harmonics. [1]
- OEM Part Numbers:
- Rear Torque Strut Mount (Lower "Dog-Bone" Roll Stopper):
2. Vehicle Structural Fitment
- Engine & Gearbox Alignment: Transverse configuration (East-West installation)
- Chassis Series Covered: Mazda CX-5 (KE Platform / First Gen Pre-facelift & Facelift crossover periods). [1, 2]
- Powertrain Compatibility:
- Drivetrain Adaptability: Identical mounting geometry handles both Front-Wheel Drive (FWD) and All-Wheel Drive (AWD) intelligent subframe layouts. [1]
3. Material Specifications
- Structural Composition: Laser-cut, stamped high-tensile structural steel combined with cast aluminum frame adapters.
- Damping Material: Heavy-duty vulcanized natural rubber (NBR-metal bonded matrix).
- Damping Classification: Passive elastomeric design. The left transmission side features a solid-core rubber cushion block specifically calibrated to isolate SkyActiv-Drive torque converter lockup frequencies. [1, 2, 3]
4. Standard Factory Torque Specifications
- Main Transmission Mount-to-Chassis Frame Bolts: ~62 Nm to 80 Nm (approx. 45 to 59 ft-lbs)
- Transmission Mount-to-Gearbox Bracket Center Nut: ~85 Nm to 100 Nm (approx. 62 to 74 ft-lbs)
- Rear Torque Strut Lower Subframe Cross-bolt: ~90 Nm (approx. 66 ft-lbs)
Mazda Demio Model 2018 Lower Control Arm
KSh5,500.00 Buy Via Whatsapp1. Dimensional & Sizing Specifications
- Total Component Length: 350 mm (Note: Certain unbracketed aftermarket replacements indicate up to 422 mm across extended geometric measurement points).
- Total Component Height: 82 mm
- Component Width: ~50 mm (at base structural track profile)
- Ball Joint Cone/Pin Diameter: Ø 16 mm (Note: Factory-fitted original equipment measures 16 mm, though some heavy-duty replacement matrices use a 17.5 mm variant).
- Fitting Configuration Type: Pinch Bolt alignment configuration (16 mm)
- Inner Bushing Bolt Hole Diameter: 10.4 mm
2. OEM Part Numbers & Cross-References
- Left-Hand Side (LH):
- Mazda Original Equipment (OE) Codes:
DA7H-34-350B,DA6A-34-350C,DB2R-34-350 - Major Aftermarket Match: Delphi TC3286
- Mazda Original Equipment (OE) Codes:
- Right-Hand Side (RH):
- Mazda Original Equipment (OE) Codes:
DA7H-34-300B,DA6A-34-300C,DB2R-34-300 - Major Aftermarket Match: Delphi TC3287
- Mazda Original Equipment (OE) Codes:
3. Material & Component Architecture
- Structural Material: High-tensile forged or stamped steel alloy structural matrix finished with an anti-corrosion black powder layer.
- Pre-Assembled Bushings: Premium vulcanized natural rubber silent-block bushings (one forward cylindrical pivot bushing and one large rear compliance load bushing) engineered to minimize cabin NVH (Noise, Vibration, and Harshness).
- Ball Joint Mechanism: Maintenance-free, non-adjustable, factory-sealed, pre-greased low-friction ball joint enclosed in a flexible neoprene protective dust boot.
4. Vehicle & Platform Fitment Geometry
- Chassis Codes Covered: Mazda Demio / Mazda 2 Hatchback and Sedan (DBA-DJ3FS, DBA-DJ3AS 4WD, 3BA-DJLFS, 5BA-DJLFS, DJ5FS, DJ5AS).
- Powertrain Compatibility: 1.3L SkyActiv-G (
P3-VPS), 1.5L SkyActiv-G (F5-VPT/P5-VPS), and 1.5L SkyActiv-D Diesel (S5-DPTS). - Platform Sharing: Shared geometric subframe attachment layout with the Toyota Yaris / Yaris iA (North American variants derived from the Mazda DJ platform partnership).
Mazda Demio Model 2017 Lower Control Arm
KSh5,500.00 Buy Via Whatsapp1. Dimensional & Sizing Specifications
- Total Component Length: 350 mm (Note: Certain unbracketed aftermarket replacements indicate up to 422 mm across extended geometric points). [1]
- Total Component Height: 82 mm [1]
- Component Width: ~50 mm (at base structural track profile)
- Ball Joint Cone/Pin Diameter: Ø 16 mm (Note: Some heavy-duty premium replacement matrices specify a 17.5 mm cone variant; standard factory factory-fitted OE measures 16 mm). [1]
- Fitting Configuration Type: Pinch Bolt alignment configuration (16 mm)
- Inner Bushing Bolt Hole Diameter: 10.4 mm
2. OEM Part Numbers & Cross-References
- Left-Hand Side (LH):
- Mazda Original Equipment (OE) Codes:
DA7H-34-350B,DA6A-34-350C,DA7H-34-350 - Major Aftermarket Match: Delphi TC3286 [1, 2]
- Mazda Original Equipment (OE) Codes:
- Right-Hand Side (RH):
- Mazda Original Equipment (OE) Codes:
DA7H-34-300B,D23H-34-300,DA6A-34-300C - Major Aftermarket Match: Delphi TC3287 [1, 2]
- Mazda Original Equipment (OE) Codes:
3. Material & Component Architecture
- Structural Material: High-tensile forged or stamped steel alloy structural matrix finished with an anti-corrosion black powder layer.
- Pre-Assembled Bushings: Premium vulcanized natural rubber silent-block bushings (one forward cylindrical pivot bushing and one large rear compliance load bushing) engineered to minimize cabin NVH (Noise, Vibration, and Harshness).
- Ball Joint Mechanism: Maintenance-free, non-adjustable, factory-sealed, pre-greased low-friction ball joint enclosed in a flexible neoprene protective dust boot. [1, 2]
4. Vehicle & Platform Fitment Geometry
- Chassis Codes Covered: Mazda Demio / Mazda 2 Hatchback and Sedan (DBA-DJ3FS, DBA-DJ3AS 4WD, DJ5FS, DJ5AS).
- Powertrain Compatibility: 1.3L SkyActiv-G (
P3-VPS), 1.5L SkyActiv-G (F5-VPT), and 1.5L SkyActiv-D Diesel (S5-DPTS). - Platform Sharing: Shared geometric subframe attachment layout with the Toyota Yaris / Yaris iA (2016+ North American variants derived from the Mazda DJ platform partnership). [1, 2]
Mazda Demio Model 2016 Lower Control Arm
KSh5,500.00 Buy Via Whatsapp1. Dimensional & Sizing Specifications
- Total Component Length: 350 mm
- Total Component Height: 82 mm
- Component Width: ~50 mm (at base structural track profile)
- Ball Joint Cone/Pin Diameter: Ø 16 mm (Note: Certain reinforced aftermarket replacement matrices utilize a 17.5 mm variant; standard factory OE specification measures 16 mm).
- Thread Size / Fitting Type: Pinch Bolt alignment configuration (16 mm)
- Inner Bushing Bolt Hole Diameter: 10.4 mm [1, 2, 3]
2. OEM Part Numbers & Cross-References
- Left-Hand Side (LH):
- Mazda Original Equipment (OE) Codes:
DA6A-34-350C,DA7H-34-350,D201-34-350B - Major Aftermarket Match: Delphi TC3286 [1]
- Mazda Original Equipment (OE) Codes:
- Right-Hand Side (RH):
- Mazda Original Equipment (OE) Codes:
DA6A-34-300C,DA7H-34-300B,D23H-34-300 - Major Aftermarket Match: Delphi TC3287 [1, 2, 3]
- Mazda Original Equipment (OE) Codes:
3. Material & Component Architecture
- Structural Material: High-tensile forged or stamped steel alloy structural matrix finished with an anti-corrosion black powder layer. [1, 2]
- Pre-Assembled Bushings: Premium vulcanized natural rubber silent-block bushings (one forward cylindrical pivot bushing and one large rear compliance load bushing) engineered to minimize cabin NVH (Noise, Vibration, and Harshness). [1]
- Ball Joint Mechanism: Maintenance-free, non-adjustable, factory-sealed, pre-greased low-friction ball joint enclosed in a flexible neoprene protective dust boot. [1, 2]
4. Vehicle & Platform Fitment Geometry
- Chassis Codes Covered: Mazda Demio / Mazda 2 Hatchback and Sedan (CBA-DJLFS, DBA-DJ3FS, DJ5FS, DJ5AS 4WD).
- Powertrain Compatibility: 1.3L SkyActiv-G (
P3-VPS), 1.5L SkyActiv-G (F5-VPT), and 1.5L SkyActiv-D Diesel (S5-DPTS). - Platform Sharing: Shared geometric subframe attachment layout with the Toyota Yaris / Yaris iA (2016+ North American variants derived from the Mazda DJ platform partnership).
Mazda Demio Model 2015 Lower Control Arm
KSh5,500.00 Buy Via Whatsapp1. Dimensional & Sizing Specifications
- Total Component Length: 350 mm
- Total Component Height: 82 mm
- Component Width: ~50 mm (at base structural track)
- Ball Joint Cone/Pin Size: Ø 16 mm
- Thread Size / Fitting Type: Pinch Bolt alignment configuration (16 mm)
- Inner Bushing Bolt Hole Diameter: 10.4 mm [1, 2]
2. OEM Part Numbers & Cross-References
- Left-Hand Side (LH):
- Mazda Original Equipment (OE) Codes:
DA6A-34-350C,D201-34-350B,DA7H-34-350 - Major Aftermarket Match: Delphi TC3286 [1, 2]
- Mazda Original Equipment (OE) Codes:
- Right-Hand Side (RH):
- Mazda Original Equipment (OE) Codes:
D23H-34-300,DA7H-34-300B,D201-34-300B - Major Aftermarket Match: Delphi TC3287 [1, 2, 3, 4]
- Mazda Original Equipment (OE) Codes:
3. Material & Component Architecture
- Structural Material: High-tensile forged or stamped carbon steel alloy finished with an anti-corrosion black powder layer. [1, 2]
- Pre-Assembled Bushings: Premium vulcanized natural rubber silent-block bushings (one forward cylindrical pivot bushing and one large rear compliance load bushing) engineered to minimize cabin NVH (Noise, Vibration, and Harshness). [1]
- Ball Joint Mechanism: Maintenance-free, non-adjustable, factory-sealed, pre-greased low-friction ball joint enclosed in a flexible neoprene protective dust boot. [1]
4. Vehicle & Platform Fitment Geometry
- Chassis Codes Covered: Mazda Demio / Mazda 2 Hatchback and Sedan (CBA-DJLFS, DBA-DJ3FS, DJ5FS, DJ5AS 4WD).
- Powertrain Compatibility: 1.3L SkyActiv-G (
P3-VPS), 1.5L SkyActiv-G (F5-VPT), and 1.5L SkyActiv-D Diesel (S5-DPTS). - Platform Sharing: Shared geometric subframe attachment layout with the Toyota Yaris / Yaris iA (2016+ North American variants derived from the Mazda DJ platform partnership). [1, 2]
Nissan Note Model E12 Engine Mounting
KSh4,000.00 Buy Via Whatsapp1. Component Breakdown & OEM Part Numbers
The E12 platform utilizes a three-point suspended engine containment setup designed to isolate the low-frequency vibrations typical of 3-cylinder powertrains:
- Right-Hand Engine Mount (Front Right / Timing Side):
- Left-Hand Transmission Mount (Front Left / Gearbox Side):
- OEM Part Numbers:
11220-3HD2A,11360-1HC3C - Function: Gearbox casing insulator. It bears the weight of the transmission case, counteracting drivetrain movement during deceleration and CVT ratio adjustments. [1]
- OEM Part Numbers:
- Rear Torque Rod (Lower Engine Stabilizer / "Dog-Bone" Mount):
2. Vehicle Structural Fitment
- Engine Installation: Transverse alignment (East-West configuration)
- Chassis & Powertrain Compatibility:
- Platform Sharing Interchangeability: The engine mounts directly match the mounting layout used on the Nissan March / Micra (
K13) and the Nissan Latio (N17) platforms. [1, 2]
3. Material Specifications
- Material Composition: Specially treated, high-absorption vulcanized natural rubber chemically bonded to stamped structural carbon steel base plates and cast aluminum brackets.
- Damping Classification: Standard solid-core high-damping elastomeric design (passive configuration) optimized to target secondary-order idle frequencies.
4. Standard Installation Torque Specifications
Nissan Note Beam Model E12
KSh20,000.00 Buy Via Whatsapp1. Structural Geometry & Alignment Specs
The E12 platform utilizes a semi-independent rear suspension layout with a semi-rigid twist profile:
- Suspension Architecture Type: Torsion Beam / Twist Beam Axle with trailing arms. [1, 2]
- Rear Track Width: 1,485 mm (standard variants). [1, 2]
- Wheelbase Compatibility: 2,600 mm. [1, 2]
- Brake Integration Interface: Formed with integral backing plates designed to accept factory 203 mm hydraulic drum brake units or specialized solid disc calipers (market/trim dependent). [1, 2]
- Stabilizer Element: Built with an integrated inner anti-roll sway bar welded directly inside the V-shape profile of the torsion beam structure to control body roll.
2. OEM Part Numbers & Drive Layouts
- Standard Front-Wheel Drive Layout (2WD / 4x2 / FF):
- Nissan Original Equipment (OE) Codes:
55501-3VA0A,55501-3VA0B,55501-5WH0A[1]
- Nissan Original Equipment (OE) Codes:
- All-Wheel Drive / Four-Wheel Drive Layout (4WD / 4x4 / e-POWER 4WD):
- Nissan Original Equipment (OE) Code:
55501-3VE1B[1]
- Nissan Original Equipment (OE) Code:
- Matching Rear Pivot Axle Bushing Code:
55045-1HJ0A[1]
3. Material & Component Composition
- Material Matrix: High-tensile cold-stamped structural spring steel with variable wall thickness for progressive roll rigidity.
- Mounting Interface: Dual forward-facing eyelets carrying pre-pressed vulcanized natural rubber silent-block compliance bushings.
- Coil Spring Mount Geometry: Dual welded structural lower spring seats configured for linear-rate coil springs and single-tube vertical dampening shock absorbers. [1]
4. Vehicle Platform Alignment
Nissan Cube Lower Arms
KSh4,000.00 Buy Via Whatsapp1. Dimensional & Sizing Specifications
- Ball Joint Cone/Pin Diameter:
- Z11 Platform (2002–2008): Ø 16 mm [The Nissan Note Z11 shares this spec with the K12 Micra/E11 Note].
- Z12 Platform (2008–2020): Ø 18 mm [Upgraded to match the C11 Tiida/NV200 standard for a wider wheel track].
- Bushing Bolt Hole Diameters: 12 mm (Main subframe pivot alignment points)
- Average Assembly Weight: ~2.25 kg to 2.40 kg per arm (dependent on platform width)
2. OEM Part Numbers & Cross-References
- Z11 Generation (2002–2008 / B-Platform):
- Left-Hand Side (LH):
54501-AX000,54501-14B0A - Right-Hand Side (RH):
54500-AX000,54500-14B0A - Aftermarket Matches:
Delphi TC1307(LH) /Delphi TC1308(RH)
- Left-Hand Side (LH):
- Z12 Generation (2008–2020 / B-Lounge Platform):
- Left-Hand Side (LH):
54501-1FU0A,54501-ED000,54501-EE50A - Right-Hand Side (RH):
54500-1FU0A,54500-ED000,54500-ED00A - Aftermarket Matches:
Delphi TC2873(LH) /Delphi TC2874(RH)
- Left-Hand Side (LH):
3. Material & Component Architecture
- Structural Composition: Heavy-gauge stamped sheet steel matrix frame finished in an anti-corrosion black protective coating.
- Pre-Installed Bushings: High-damping vulcanized natural rubber silent-block bushings (one small horizontal pivot bushing at the front position, one large vertical compliance cylindrical bushing at the rear position).
- Ball Joint Mechanism: Maintenance-free, non-adjustable, factory-sealed and pre-greased low-friction ball joint integrated with a neoprene protective dust boot.
4. Vehicle & Platform Fitment Geometry
- Chassis Codes Covered: Nissan Cube (BZ11, BNZ11, YZ11, Z12, NZ12).
- Engine Alignment: 1.4L (
CR14DE), 1.5L (HR15DE), 1.6L (HR16DE), 1.8L (MR18DE). - Platform Interchangeability:
- Z11 arms directly swap with the Nissan March/Micra (
K12) and Nissan Note (E11). - Z12 arms directly swap with the Nissan Tiida (
C11), NV200 (M20), and Wingroad (Y12).
- Z11 arms directly swap with the Nissan March/Micra (
Nissan NV200 Lower Arms
KSh4,000.00 Buy Via Whatsapp1. Dimensional & Sizing Specifications
- Ball Joint Cone/Pin Diameter: Ø 18 mm
- Ball Joint Body Diameter (Press-fit size): Ø 38.5 mm
- Bushing Bolt Hole Diameters: 12 mm (Main frame pivot points)
- Total Component Length: 540 mm
- Total Component Width: 280 mm
- Total Component Height: 80 mm
- Average Assembly Weight: ~2.45 kg per side [1, 2]
2. OEM Part Numbers & Cross-References
- Left-Hand Side (LH / Driver Side or Passenger depending on market):
- Nissan Original Equipment (OE) Codes:
54501-EL000,54501-3SH2A,54501-9AM1A,54501-9AM1B - Major Premium Aftermarket Match: Delphi TC2496 [1, 2]
- Nissan Original Equipment (OE) Codes:
- Right-Hand Side (RH):
- Nissan Original Equipment (OE) Codes:
54500-EL000,54500-3SH2A,54500-3SH2B,54500-9AM1A,54500-9AM1B - Major Premium Aftermarket Match: Delphi TC2497 [1, 2, 3]
- Nissan Original Equipment (OE) Codes:
3. Material & Component Architecture
- Structural Composition: Heavy-duty stamped structural sheet steel or cast steel matrix shell, designed to withstand commercial van payload distributions. [1, 2, 3]
- Pre-Installed Bushings: High-damping vulcanized natural rubber silent-block bushings (one horizontal inner pivot bushing, one vertical large compliance rear cylindrical bushing). [1, 2]
- Ball Joint Mechanism: Maintenance-free, non-adjustable, factory-sealed and pre-greased low-friction ball joint integrated with a durable neoprene dust boot. [1, 2]
4. Vehicle & Platform Fitment Geometry
- Chassis Codes Covered: Nissan NV200 Van / Combi / Evalia Bus (M20, M20M).
- Engine Variant Alignment: 1.5L dCi (
K9K), 1.6L (HR16DE), 2.0L (MR20DE). - Platform Sharing Interchangeability: Built on a modified variant of the global Nissan B-platform. The tracking arm architecture directly shares subframe layout points with the Nissan Tiida (
C11), Bluebird Sylphy (G11), and Wingroad (Y12).
Nissan Note E11 Lower Arms
KSh4,000.00 Buy Via Whatsapp1. Dimensional & Sizing Specifications
- Ball Joint Cone/Stud Diameter: Ø 16 mm
- Bushing Bolt Hole Inner Diameters: 12 mm (mounts to the subframe via 18 mm bolt heads)
- Component Length: ~383 mm to 390 mm
- Component Width: ~365 mm to 375 mm
- Average Assembly Weight: ~2.25 kg to 2.37 kg per side [1, 2, 3, 4]
2. OEM Part Numbers & Cross-References
- Left-Hand Side (LH / Passenger Side in RHD markets):
- Nissan Original Equipment (OE) Codes:
54501-AX000,54501-9U00A,54501-BC40A - Major Premium Aftermarket Match: Delphi TC1307 [1, 2]
- Nissan Original Equipment (OE) Codes:
- Right-Hand Side (RH / Driver Side in RHD markets):
- Nissan Original Equipment (OE) Codes:
54500-AX000,54500-9U00A,54500-BC40A - Major Premium Aftermarket Match: Delphi TC1308 [1]
- Nissan Original Equipment (OE) Codes:
- Standalone Replacement Ball Joint Code (Pressed-In Type):
40160-AX000[1]
3. Material & Component Architecture
- Structural Composition: Heavy-duty stamped sheet steel (matrix shell format) painted with an anti-corrosion protective layer. [1, 2]
- Pre-Assembled Bushings: Two high-damping natural rubber silent-block bushings per arm (one small horizontal pivot bushing at the front position, one large vertical compliance cylindrical bushing at the rear position). [1, 2]
- Ball Joint Mechanism: Maintenance-free, factory-sealed, pre-greased low-friction ball joint integrated with a neoprene protective dust boot. [1, 2]
4. Vehicle & Platform Fitment Geometry
- Chassis Codes Covered: Nissan Note (E11 / NE11 4WD variant).
- Engine Alignment: 1.4L (
CR14DE), 1.5L dCi (K9K), and 1.6L (HR16DE). - Platform Sharing Interchangeability: Built on the global Nissan B-platform architecture. The track control arm dimensions directly match and swap with the Nissan March/Micra (
K12), Nissan Cube (Z11), and select Renault platform cousins like the Clio III. [1, 2, 3]
Nissan Tiida Lower Arms
KSh4,000.00 Buy Via Whatsapp1. Dimensional & Sizing Specifications
- Ball Joint Cone/Stud Size: Ø 18 mm
- Bushing Inner Bore Diameter: 12 mm
- Total Component Length: 510 mm
- Total Component Width: 235 mm
- Total Component Height: 62 mm
- Average Assembly Weight: ~2.3 kg to 2.35 kg per side [1, 2, 3, 4]
2. OEM Part Numbers & Cross-References
- Left-Hand Side (LH / Driver Side or Passenger depending on market alignment):
- Right-Hand Side (RH):
- Major Premium Aftermarket Matches:
3. Material & Component Architecture
- Structural Material: High-strength heavy-gauge stamped sheet steel (welded matrix frame structure).
- Pre-Installed Bushings: High-durability vulcanized natural rubber silent-block bushings (one horizontal pivot bush, one vertical rear compliance bush).
- Ball Joint Setup: Non-adjustable, pre-greased, sealed low-friction heavy-duty ball joint assembly with integrated neoprene dust boot. [1, 2, 3, 4]
4. Vehicle & Platform Fitment Geometry
- Chassis Codes Covered: Nissan Tiida Hatchback / Sedan (C11, C11X, SC11, C12).
- Engine Variant Alignment: 1.5L (
HR15DE), 1.6L (HR16DE), 1.8L (MR18DE). - Platform Sharing: Completely interchangeable with the Nissan Wingroad (
Y12), Bluebird Sylphy (G11), NV200 (M20), and Nissan Cube (Z12) front suspension subframe geometry. [1, 2, 3, 4]
Daihatsu Mira Engine Mountain
KSh4,000.00 Buy Via Whatsapp1. Component Breakdown & OEM Part Numbers
The Daihatsu Mira relies on a 3-piece multi-point containment setup optimized to counteract the low-frequency vibrations typical of 3-cylinder engines:
- Right-Hand Mount (Front Right / Timing Belt Side):
- Left-Hand Mount (Front Left / Transmission Side):
- Rear Roll Stopper (Lower Center Torque Rod):
2. Vehicle Structural Fitment
- Engine Installation: Transverse alignment (East-West layout)
- Chassis & Powertrain Compatibility:
3. Material & Damping Specifications
- Material Composition: Natural vulcanized rubber chemically bonded to stamped structural steel, reinforced cast aluminum casings, and iron framing brackets. [1]
- Damping Classification:
- Right-Hand Position: Specially engineered Hydraulic Design (Hydro-Mount) containing internal fluid to absorb the rough secondary-order idle harmonics inherent to light 3-cylinder setups.
- Left and Rear Positions: Standard solid-core rubber-metal elastomeric bushings.
Honda Fit Model 2012 Gearbox Mountain
KSh3,500.00 Buy Via Whatsapp1. Component Breakdown & OEM Part Numbers
The 2012 Honda Fit utilizes a multi-point engine and transmission isolation configuration:
- Left-Hand Gearbox Mount (Transmission Main Insulator):
- Automatic / CVT Transmission (GE6 / GE8 standard):
50850-TF0-981(or50850-TF0-J81) - Manual Transmission:
50850-TF0-G01 - Function: Primary weight-bearing insulator for the transmission housing. Connects the gearbox directly to the left frame rail.
- Automatic / CVT Transmission (GE6 / GE8 standard):
- Transmission Rear Torque Strut Mount (Lower Dog-Bone Mount):
- Part Number:
50890-TF0-911(or50890-TF0-981) - Function: Controls the back-and-forth structural "pitching" and rotational torque twist of the transmission assembly under acceleration and deceleration.
- Part Number:
2. Vehicle Structural Fitment
- Engine & Gearbox Orientation: Transverse (East-West installation)
- Chassis & Drivetrain Compatibility:
- GE6: 1.3L L13A I4 Petrol engine, paired with CVT or 5-speed Automatic
- GE8: 1.5L L15A I4 Petrol engine, paired with 5-speed Manual, 5-speed Automatic, or CVT
- GP1: 1.3L LDA I4 Hybrid (Fit Hybrid), paired with CVT
3. Material Specifications
- Composition: Premium vulcanized natural rubber formulation bonded directly to stamped carbon steel casing brackets.
- Design Type: Fluid-filled hydraulic design (hydro-mount) for the main left-hand transmission insulator to absorb severe high-frequency CVT/Automatic harmonic vibrations; solid rubber bushing for the lower rear torque rod.
Suzuki Alto Model 2018 Rear Drum
KSh6,500.00 Buy Via Whatsapp1. Dimensional Specifications
- Inner Drum Diameter (Working Friction Surface): 180.0 mm
- Maximum Wear/Reboring Limit (Discard Diameter): 182.0 mm
- Outer Brake Drum Diameter: 208.0 mm
- Inner Brake Drum Width / Working Depth: 34.6 mm to 35.0 mm
- Total Component Height (Overall Thickness): 63.0 mm
- Centering / Center Bore Diameter: 52.1 mm [1]
2. Wheel Lug Bolt Pattern & Mounting
- Number of Holes: 4 holes
- Pitch Circle Diameter (PCD): 4 x 100 mm
- Hub Bolt Circle (Bore) Diameter: 12.0 mm [1]
3. OEM Part Numbers & Cross-References
- Suzuki Original Equipment (OE) Codes:
43511-74P00(Standard Japanese Domestic Market HA36 platform code),43511-68K00/43511-76G50[1, 2] - Major Premium Aftermarket Matches:
4. Architecture & Engineering Layout
- Drivetrain Position: Rear Axle Only
- Material Composition: High-thermal cast grey alloy iron
- Design Type: Integral wheel hub carrier assembly casing (machined outer shell containing the inner hub profile, structurally designed without pre-pressed wheel bearings or pre-fitted wheel studs).
- Braking System Type: Mechanical leading-trailing shoe setup activated by a dual-piston hydraulic rear wheel cylinder.[1, 2]
Suzuki Alto Model 2017 Rear Drum
KSh6,500.00 Buy Via Whatsapp1. Dimensional Specifications
- Inner Drum Diameter (Friction Surface): 180.0 mm
- Maximum Wear/Reboring Limit (Discard Diameter): 182.0 mm
- Outer Brake Drum Diameter: 208.0 mm
- Inner Brake Drum Width / Working Depth: 34.6 mm to 35.0 mm
- Total Component Height (Overall Thickness): 63.0 mm
- Centering / Center Bore Diameter: 52.0 mm to 52.1 mm [1, 2, 3, 4]
2. Wheel Lug Bolt Pattern & Mounting
- Number of Holes: 4 holes
- Pitch Circle Diameter (PCD): 4 x 100 mm
- Hub Bolt Hole Diameter: 12.0 mm [1, 2]
3. OEM Part Numbers & Cross-References
- Suzuki Original Equipment (OE) Codes:
43511-74P00(HA36 platform standard),43511-68K00/43511-76G50(Cross-over compatibility codes) [1, 2] - Major Premium Aftermarket Matches:
4. Architecture & Engineering Layout
- Drivetrain Position: Rear Axle Only
- Material Composition: High-thermal cast grey alloy iron.
- Design Type: Integral wheel hub carrier assembly casing (machined outer shell containing the inner hub profile, structurally designed without pre-pressed wheel bearings or pre-fitted wheel studs).
- Braking System Type: Mechanical leading-trailing shoe setup activated by a hydraulic rear wheel cylinder.
Suzuki Alto Model 2016 Rear Drum
KSh6,500.00 Buy Via Whatsapp1. Dimensional Specifications
- Inner Drum Diameter (Working Surface): 180.0 mm
- Maximum Wear/Reboring Limit (Discard Diameter): 182.0 mm
- Outer Brake Drum Diameter: 208.0 mm
- Inner Brake Drum Width / Depth: 35.0 mm
- Total Component Height (Thickness): 63.0 mm
- Centering/Center Bore Diameter: 52.0 mm to 52.1 mm [1, 2]
2. Wheel Lug Bolt Pattern & Mounting
- Number of Holes: 4 holes
- Pitch Circle Diameter (PCD): 4 x 100 mm
- Hub Bolt Circle (Bore) Diameter: 12.0 mm [1, 2]
3. OEM Part Numbers & Cross-References
- Suzuki Original Equipment (OE) Codes:
43511-74P00(Main code for HA36 platform),43511-76G50/43511-68K00(GF platform cross-over) [1, 2, 3] - Major Premium Aftermarket Matches:
4. Architecture & Engineering Layout
- Drivetrain Position: Rear Axle
- Design Type: Integral wheel hub carrier assembly casing (cast high-thermal grey alloy iron structure without wheel bearings/studs pre-pressed).
- Braking System Type: Mechanical leading-trailing drum configuration expanding outward via dual-piston rear hydraulic brake cylinders. [1, 2, 3]
Suzuki Alto Model 2015 Rear Drum
KSh6,500.00 Buy Via Whatsapp1. Dimensional Specifications
-
- Inner Drum Diameter (Working Surface): 180.0 mm
- Maximum Wear/Reboring Limit (Discard Diameter): 182.0 mm
- Outer Brake Drum Diameter: 208.0 mm
- Inner Brake Drum Width / Depth: 35.0 mm
- Total Component Height (Thickness): 63.0 mm
- Centering/Center Bore Diameter: 52.0 mm [1]
2. Wheel Lug Bolt Pattern & Mounting
-
- Number of Holes: 4 holes
- Pitch Circle Diameter (PCD): 4 x 100 mm
- Hub Bolt Circle (Bore) Diameter: 12.0 mm [1]
3. OEM Part Numbers & Cross-References
4. Architecture & Engineering Layout
Suzuki Alto Model 2014 Rear Drum
KSh6,500.00 Buy Via Whatsapp1. Dimensional Specifications
- Inner Drum Diameter (Working Surface): 180.0 mm
- Maximum Wear/Reboring Limit (Discard Diameter): 182.0 mm
- Outer Brake Drum Diameter: 208.0 mm
- Inner Brake Drum Width / Depth: 34.6 mm to 35.0 mm
- Total Component Height (Depth): 63.0 mm
- Centering/Center Bore Diameter: 52.0 mm [1, 2]
2. Wheel Lug Bolt Pattern & Mounting
- Number of Holes: 4 holes
- Pitch Circle Diameter (PCD): 4 x 100 mm
- Bore Diameter: 12.0 mm [1]
3. OEM Part Numbers & Cross-References
- Suzuki Original Equipment (OE) Numbers:
43511-76G00,43511-76G50[1] - Major Premium Aftermarket Matches:
4. Architecture & Engineering Layout
- Drivetrain Position: Rear Axle only.
- Design Type: Integral wheel hub design (the brake drum casing houses the outer wheel hub, built to fit directly over the rear spindle setup).
- Braking System Type: Standard dual-circuit hydraulic drum brake utilizing leading and trailing brake shoe architecture.
Nissan Xtrail Model NT31 Rear Wheel Hub Bearing
KSh7,000.00 Buy Via Whatsapp1. Dimensional & Structural Specifications
The NT31 chassis (specifically the 4WD variant) utilizes a complete, integrated wheel hub and bearing assembly (Generation 3 hub unit): [1]
- Inner Diameter (Spindle Fitment): 26 mm
- Outer Diameter (Hub Flange): 91 mm (bearing outer diameter) / 147 mm (total flange outer diameter)
- Total Assembly Height: 94.5 mm
- Spline/Teeth Count (Drive Axle Entry): 25 teeth (Note: Some aftermarket cross-references measure 24 teeth depending on the exact CV axle manufacturer match, but factory NT31 4WD standard is 25 teeth).
- Wheel Lug Bolt Pattern: 5 holes / Mounting bores (5 x 114.3 mm Pitch Circle Diameter) [1, 2, 3]
2. OEM Part Numbers & Cross-References
- Nissan Original Equipment (OE) Codes:
43202-JG200,43202-JG000,43202-4BA0B[1, 2] - Major Premium Aftermarket Matches:
- NSK:
53BWKH20 - SKF:
VKBA 3997 - FAG:
713 6138 10[1]
- NSK:
3. Material, Sensor & Component Architecture
- Bearing Construction: Double-row angular contact ball bearing pre-packed with heavy-duty, high-temperature lithium-based grease.
- ABS Integration: Includes an integrated magnetic encoder ring/tone wheel embedded within the inner oil seal to interface directly with the vehicle’s anti-lock braking system sensor.
- Sealing: Double-lip rubber contact seals (NBR/Nitrile) on both faces to prevent moisture and road debris contamination.[1]
Toyota Passo Model 2017 Engine Mountain
KSh4,000.00 Buy Via Whatsapp1. Mechanical Layout & Component Breakdown
The 2017 model utilizes a revised three-point engine containment layout optimized for the newer high-efficiency powertrain:
- Right-Hand Mount (Front Right / Engine Side):
- OEM Part Numbers:
12305-B1140/12305-B1220 - Function: Primary weight-bearing stabilizer. It anchors the cylinder block to the right body rail frame and absorbs structural engine vibration.
- OEM Part Numbers:
- Left-Hand Mount (Front Left / Transmission Side):
- OEM Part Numbers:
12306-B1130/12306-B1131 - Function: Gearbox casing insulator. It isolates noise and absorbs shifting torque from the Continuous Variable Transmission (CVT).
- OEM Part Numbers:
- Rear Torque Rod (Lower Engine Stabilizer):
- OEM Part Numbers:
12309-B1080(Rod) and12321-B1050/12321-B1070(Bracket) - Function: Lower control torque rod. Connects directly to the front suspension cross-member to limit back-and-forth structural rocking during acceleration and deceleration.
- OEM Part Numbers:
2. Vehicle Structural Fitment
- Engine Installation: Transverse alignment (East-West layout)
- Chassis & Powertrain Compatibility:
- M700A: 1.0L 3-cylinder Petrol (
1KR-FE), Front-Wheel Drive (FWD) - M710A: 1.0L 3-cylinder Petrol (
1KR-FE), All-Wheel Drive (AWD)
- M700A: 1.0L 3-cylinder Petrol (
3. Material Specifications
- Core Material: Heavy-duty vulcanized natural rubber formulation chemically bonded to a lightweight, reinforced cast aluminum casing and stamped steel base bracket assembly.
- Damping Classification: Passive, solid-core high-absorption elastomeric system tailored to control 3-cylinder idle harmonics.
Toyota Passo Model 2012 Engine Mountain
KSh4,000.00 Buy Via Whatsapp1. Mechanical Layout & Component Breakdown
The 2012 model features a structural, multi-point isolation configuration split into three key positions to absorb vibration:
- Right-Hand Mount (Front Right / Engine Side):
- OEM Part Numbers:
12305-B1050/12305-B1051/12305-B1052 - Function: Weight-bearing insulator assembly. Anchors the primary engine block structure to the right chassis frame rail. [1]
- OEM Part Numbers:
- Left-Hand Mount (Front Left / Transmission Side):
- OEM Part Numbers:
12306-B1030/12306-B1050 - Function: Transmission casing insulator. Controls rotational torque loads generated through the drivetrain and transaxle.
- OEM Part Numbers:
- Rear Torque Rod (Lower Engine Stabilizer):
2. Vehicle Structural Fitment
- Engine Installation: Transverse alignment (East-West configuration)
- Chassis & Powertrain Compatibility:
3. Material Specifications
- Core Material: Vulcanized natural rubber compound bonded to a stamped carbon steel and reinforced iron casting frame casing.
- Damping Classification: Standard solid-core passive elastomeric rubber setup.
Toyota Passo Model 2013 Engine Mountain
KSh4,000.00 Buy Via Whatsapp1. Mechanical Layout & Component Breakdown
The 2013 model employs a multi-point containment design to manage powertrain vibration, divided into three core positions: [1, 2]
-
- Right-Hand Mount (Engine Side):
- Left-Hand Mount (Gearbox / Transmission Side):
- Rear Torque Rod (Lower Stabilization Link):
2. Vehicle Structural Fitment
3. Material Specifications
- Core Material: High-elasticity natural rubber vulcanized directly onto stamped sheet steel and cast iron base frames.
- Damping Classification: Passive, high-damping solid elastomeric rubber design (non-hydraulic setup for standard 1.0L configurations).
Toyota Passo Model 2014 Engine Mountain
KSh4,000.00 Buy Via Whatsapp1. Component Breakdown & OEM Part Numbers
The 2014 Toyota Passo utilizes a multi-point engine isolation setup: [1]
-
- Right-Hand Mount (Front Right / Engine Side):
- Left-Hand Mount (Front Left / Transmission Side):
- Rear Torque Rod (Lower Engine Mount):
-
- Part Number:
12309-B1110 - Function: Rod sub-assembly engine moving control. Constrains the "pitching" or rocking motion of the engine during acceleration and gear shifts. [1]
- Part Number:
-
2. Vehicle Structural Fitment
3. Material Specifications
-
- Composition: High-damping natural rubber bonded to heavy-gauge stamped steel base frames.
- Design Type: Solid rubber bushing inserts enclosed in cast/stamped metal brackets (non-hydraulic/passive dampening system).
Showing 112 of 641 results
