Toyota Noah Model 2003-2015 Rear Heavy Duty Springs

KSh7,000.00
Technical Engineering Specifications
Heavy-duty rear springs deviate from factory dimensions primarily in wire thickness and rate structure to combat load sagging: [1]
  • Material Wire Diameter (Gauge): 13.5 mm to 14.5 mm (Factory standard is typically ~12.0 mm to 12.5 mm).
  • Spring Type: Cylindrical, Progressively Wound (Coil pitch narrows at one end to maintain smooth comfort during unladen driving but stiffens rapidly under load).
  • Free Height (Unloaded): 380 mm to 410 mm (Depending on the specific target lift).
  • Outer Diameter: ~125 mm to 132 mm (Sized exactly to lock cleanly into the factory upper and lower rubber insulators).
  • Stiffness / Spring Rate: Stiffened by 15% to 30% over stock limits to withstand extreme commercial or multi-passenger weights. [1, 2, 3, 4]
Chassis & Architecture Profiles
Rear HD springs are direct-fit replacements but must align with your drivetrain layout, as 4WD versions use specific compression behavior to account for the rear differential weight:
  • 1st Generation (2001–2007): Fits AZR60G (2WD) and AZR65G (4WD) chassis. Uses factory cross-reference base 48231-28A60 (2WD) / 48231-28A70 (4WD).
  • 2nd Generation (2007–2014): Fits ZRR70G / ZRR70W (2WD) and ZRR75G / ZRR75W (4WD) chassis. Uses factory cross-reference base 48231-28C10. [1, 2, 3, 4]
Note: Springs for the 3rd Generation (ZRR80/ZWR80 2014+) feature a slightly modified base seat taper and are generally packaged separately from the 2001–2014 sets.
Installation Torque & Reassembly Rules
When installing heavy-duty springs, ensuring the rear axle beam and shock mounts are properly secured under load prevents premature bushing wear:
  • Lower Shock Absorber Mount Bolt: 90 Nm (66 ft-lbs)
  • Rear Axle Beam-to-Frame Trailing Arm Bolts: 135 Nm (100 ft-lbs)
  • Wheel Lug Nuts: 103 Nm (76 ft-lbs)
  • Installation Tip: Always inspect the Upper Coil Spring Insulator (48257-28060) during replacement. Heavy-duty springs will chew through cracked or worn rubber seats quickly, causing metal-on-metal noise over bumps. [1, 2]

Toyota Probox Steering Rack

KSh10,000.00
Core Mechanical Specifications
Depending on the specific aftermarket or OEM manufacturer (such as NSK or JTEKT) supplying the system, the core dimensions and technical metrics include: [1, 2]
  • Steering Wheel Turns: 2.88 turns lock-to-lock.
  • Overall Length: Ranges between 1105 mm and 1110 mm.
  • Net Weight: Roughly 5.9 kg to 6.6 kg.
  • Input Shaft Height: 48 mm to 49 mm.
  • Input Shaft Diameter: 17.3 mm.
  • Tie Rod Thread Size: M15x1.5 or M16x1.5 (varies by manufacturer specification). [1, 2]
OEM Part Numbers & Chassis Compatibility
Because the Probox has evolved across multiple generations, steering racks must be matched with exact OEM part numbers to ensure proper fitment for right-hand drive (RHD) configurations: [1, 2]
  • First Generation (XP50 / NCP50 series, 2002–2014): Commonly uses OEM part numbers 44200-52300, 40120-52170, and 44250-52300.
  • Second Generation (NCP150 / NCP160 series, 2014–present): Features part numbers 45510-52420 (often electric/manual rack assembly for NCP160) and 44200-52290 (for NCP150/151 series). [1, 2, 3, 4]

Toyota Mark X GRX 120 Shocks Absorbers

KSh10,000.00
Front Axle Specifications
  • Suspension Type: Double Wishbone
  • Shock Absorber System: Twin-Tube Gas Pressure
  • Operating Principle: Hydraulic Double-Acting
  • Mounting Type: Upper structural Strut Mount (3-bolt top plate) with a lower Fork/Eyelet bush mount securing to the lower control arm.
  • Electronic Variable Dampening: Models equipped with AVS (Adaptive Variable Suspension) utilize an electronic actuator port on top of the front piston rod.
  • Aftermarket Cross-Reference (KYB Excel-G): 341357 (Right) / 341358 (Left)
Rear Axle Specifications
  • Suspension Type: Multi-Link Independent
  • Shock Absorber System: Mono-Tube or Twin-Tube Gas Pressure (depending on sport/standard trim levels)
  • Operating Principle: Hydraulic Double-Acting
  • Mounting Type: Top Pin/Stud mount with a lower Eyelet bush mount.
  • Aftermarket Cross-Reference (KYB Excel-G): 341423
Critical Installation Torque Specifications
  • Front Strut Tower Top Nut: 25 N·m (18 ft-lbf)
  • Front Strut Base Fork to Control Arm Bolt: 157 N·m (116 ft-lbf)
  • Rear Shock Upper Mount Base Bolts: 30 N·m (22 ft-lbf)
  • Rear Shock Lower Eyelet Bush Bolt: 84 N·m (62 ft-lbf)
OEM Part Numbers & Platform Sharing
  • Standard Front Left/Right OEM Numbers: 48510-80227, 48520-80047, 48510-30740
  • AVS (Electronic) Front Left/Right OEM Numbers: 48510-80255, 48520-80125
  • Standard Rear OEM Numbers: 48530-80287, 48530-30510
  • AVS (Electronic) Rear OEM Numbers: 48530-80327
  • Platform Architecture: Shares identical dampener chassis mount geometry with the Toyota Crown (GRS180 / GRS182 / GRS200 series) and the Lexus GS (GRS190 series) 2WD platforms.

Toyota Axio Steering Rack

KSh15,000.00
Core Engineering Specifications
  • Steering Gear Type: Rack and Pinion
  • Operating Mode: Electric Power Steering (EPS) manual rack configuration (assisted via a column-mounted motor)
  • Drive Layout: Factory designed for Right-Hand Drive (RHD) setups
  • Total Assembly Length: 1085 mm to 1164.5 mm (depending on specific generation track width variations)
  • Net Weight: 7.5 kg
  • Minimum Turning Radius: 4.9 meters [1, 2, 3]
Hardware & Component Dimensions
  • Rack End Mounting Thread Size: M14 x 1.5
  • Mounting Bracket Distance: 448 mm
  • Key Internal Sub-Assemblies: Tie rod inner rack ends, rubber dust protection boots, outer tie rod ends, and internal micro-bushing [1, 2, 3]
Part Numbers & Platform Compatibility
  • E140 Series (2006–2012) OEM Part Numbers: 45510-12410, 45510-12290
  • E160 Series (2012–Present) OEM Part Numbers: 45510-52241, 45510-52300
  • Chassis Code Fitment: Fits DBA-NZE141, DBA-NZE161 (1.5L 1NZ-FE), and NKE165 (1.5L Hybrid) variants.
  • Platform Sharing Architecture: Fully interchangeable within respective generation platforms, sharing sub-assembly geometry with the Toyota Corolla Fielder, Aqua (NHP10), Vitz/Yaris (P130 series), Sienta (P170 series), Ractis, and Sienta. [1, 2, 3, 4, 5, 6]

Toyota Premio 260 Steering Rack

KSh18,000.00
Core Engineering Specifications
  • Steering Gear Type: Rack and Pinion
  • Operating Mode: Electric Power Steering (EPS) with column-mounted or rack-integrated motor assistance
  • Drive Layout: Factory configured for Right-Hand Drive (RHD) setups
  • Lock-to-Lock Turns: Approximately 3.2 turns
  • Power Assist Mechanism: Electronic Actuator (Does not utilize hydraulic fluid, pumps, or pressure lines)
Hardware & Component Dimensions
  • Rack End / Tie Rod Inner Thread: M15 x 1.5
  • Tie Rod End Cross-Reference (555 Brand): SR-T360 / SE-T361
  • Boot Kit Code Hardware: 45535 (No.1 Boot) and 45536 (No.2 Boot)
  • Material Housing: Lightweight cast aluminum alloy shell with high-tensile steel internal rack shaft [1, 2]
Part Numbers & Platform Compatibility
  • Primary OEM Part Numbers: 45510-20100, 44200-28510
  • Chassis Code Coverage: Fits NZT260 (1.5L 1NZ-FE), ZRT260 (1.8L 2ZR-FE/FAE), ZRT261 (2.0L 3ZR-FAE), and 4WD variants (ZRT265).
  • Platform Sharing Architecture: Fully interchangeable with the T260-generation Toyota Allion (NZT260 / ZRT260) and shares geometric sub-assembly dimensions with the Toyota Premio/Allion T240 or Prius systems depending on localized revision cycles. [1, 2, 3, 4]

Toyota AE91 Steering Rack

KSh20,000.00
Core Engineering Specifications
  • Steering Gear Type: Rack and Pinion
  • Operating Mode Option 1: Hydraulic Power Steering (HPS)
  • Operating Mode Option 2: Manual / Mechanical steering (non-servotronic configurations)
  • Drive Layout: Right-Hand Drive (RHD) factory standard (Left-Hand Drive [LHD] aftermarket replacements available)
  • Overall Assembly Length: 836 mm (Hydraulic unit) to 1165 mm (Manual unit variants depending on the integrated tie-rod span).
  • Net Weight: 7.5 kg to 8.2 kg [1, 2, 3]
Hardware & Interface Dimensions
  • Axle Joint Thread Size (Rack End): M14 x 1.5
  • Input Shaft Pinion Connector Type: Toothed / Splined spline configuration
  • Cylinder Sealing System: Uses a primary power steering rack piston ring and secondary rubber dust bellows. [1, 2]
Part Numbers & Platform Compatibility
  • Hydraulic OEM Part Numbers: 44250-12230, 44250-12231, 44250-12232, 44250-12060
  • Manual OEM Part Numbers: 45510-12170, 45510-02020
  • Chassis Platform Sharing: Directly interchangeable within the Toyota E90 platform architecture, including the Toyota Corolla EE90, AE92, AE95 4WD, and Sprinter variants of the same era. [1, 2, 3]

Toyota G Touring Steering Rack

KSh20,000.00
Core Engineering Specifications
  • Steering Gear Type: Rack and Pinion
  • Operating Mode: Hydraulic Power Steering (HPS)
  • Drive Layout: Right-Hand Drive (RHD) default configuration (LHD aftermarket cross-references available)
  • Total Assembly Length: Approximately 955 mm
  • Net Weight: 6.9 kg to 7.2 kg [1, 2, 3, 4, 5]
Hardware & Interface Dimensions
  • Input Shaft Pinion Diameter: 17.3 mm
  • Input Shaft Splines: 36 teeth
  • Input Shaft Connector Type: Toothed / Splined
  • Tie Rod Thread Connection: Female tierods / inner rack end configuration [1]
Installation Torque Specifications
  • Rack Guide Spring Cap / Lock Nut: 70 N·m (51 ft-lbf)
  • Rack Housing End Cap: 60 N·m (43 ft-lbf)
  • Turn Pressure Tubes / Lines: 13.5 N·m to 15 N·m (10 to 11 ft-lbf)
  • Fluid Lubricant Type: Dexron II / III Automatic Transmission Fluid (ATF) / Power Steering Fluid [1]
Part Numbers & Platform Compatibility
  • OEM Part Numbers: 44250-12530, 44250-12400, 44250-12480, 44250-12330
  • Chassis Platform Sharing: Directly interchangeable within the E100/E110 platform ecosystem, including the Toyota Corolla Sedan/Wagon (AE100, AE101, AE110), Corolla L Touring, and Sprinter variants. [1, 2, 3, 4]

Toyota Mark X Hub Knuckle

KSh6,000.00
Core Engineering & Structural Specs
    • Material Composition: High-tensile cast iron or forged steel alloy for structural load-bearing rigidity.
    • Suspension System Design: Integrated components built specifically for a Double-Wishbone front suspension configuration.
    • ABS Integration: Provisions built into the knuckle body to accept an active wheel speed sensor with specialized harness mounting tabs. [1, 2, 3, 4]
Hub & Bearing Interface Geometry
    • Wheel Lug Pattern (PCD): 5 x 114.3 mm
    • Wheel Rim Center Bore (Hub Pilot): 60.1 mm
    • Wheel Stud Thread Size: M12 x 1.5
    • Wheel Bearing Outer Housing Type: Bolted-flange unit (4-bolt mounting pattern directly to the steering knuckle assembly). [1, 2]
Critical Installation Torque Specifications
    • Steering Knuckle to Upper Control Arm (Ball Joint): 110 N·m (81 ft-lb)
    • Steering Knuckle to Lower Control Arm (Ball Joint): 159 N·m (118 ft-lb)
    • Steering Knuckle Arm to Tie Rod End: 122 N·m (90 ft-lb)
    • Brake Caliper Mounting Bracket to Knuckle: 123 N·m (91 ft-lb)
    • ABS Speed Sensor Mounting Bolt: 8.0 N·m (71 in-lbf) [1, 2, 3]
OEM Part Numbers & Platform Sharing
  • Front Steering Knuckle (Right): 43201-30010
  • Front Steering Knuckle (Left): 43202-30020
  • Front Axle Hub Assembly: 43550-30010
  • Chassis Cross-Compatibility: Shared architectural structural points across the Toyota Crown (GRS180 / GRS200 series) and Lexus GS (GRS190 series).

Toyota Markx 2WD Steering Rack

KSh25,000.00
Core Engineering Specifications
  • Steering Gear Type: Rack and Pinion
  • Operating Mode: Electric Power Steering (EPS) with integrated motor/actuator assembly
  • Drive Layout: Built exclusively for Right-Hand Drive (RHD) configurations
  • Rack Sliding Force: 210.6 to 269.4 N (21.5 to 27.5 kg)
  • Wheel Turning Angle (Inner): Minimum 32° 31′ | Nominal 35° 31′ | Maximum 36° 31′ [1, 2, 3, 4]
Fitment & Hardware Details
  • Rack End Mounting Thread: M15 x 1.5
  • Primary Components: Includes internal torque sensor, EPS rack housing, dual inner tie-rod end sub-assemblies, outer rods, and rubber dust boots.
  • Chassis Platform Group: Shared system geometry across Toyota's rear-wheel-drive (RWD) "S" platform architecture. [1, 2, 3]
Part Numbers & Platform Compatibility
  • OEM Part Numbers: 44200-30302, 44200-30300, 44200-30330, 44200-30610
  • Tie Rod End OEM Number: 45503-30070
  • Vehicle Compatibility: Toyota Mark X 250G/350S (GRX120, GRX130 chassis), Toyota Crown (GRS180, GRS200 series), and Lexus GS (GRS190 series) 2WD platforms.

Toyota Passo Sette Shock Absorber

KSh7,500.00
Front Axle Specifications
  • Suspension Type: MacPherson Strut
  • Shock Absorber System: Twin-Tube Gas Pressure
  • Operating Principle: Hydraulic Double-Acting
  • Mounting Type: Top Pin/Stud (Strut Mount) with Bottom Bracket clamp (Two-Bolt Steering Knuckle mount)
  • Aftermarket Cross-Reference (KYB): 3340117 / 3340116 (Varies by Left/Right side orientation) [1]
Rear Axle Specifications
  • Suspension Type: Torsion Beam (Trailing Arm layout)
  • Shock Absorber System: Separate Spring and Damper configuration
  • Operating Principle: Twin-Tube Gas Pressure
  • Mounting Type: Top Pin/Eyelet and Bottom Eyelet bush [1]
OEM Part Numbers & Compatibility
  • Front Right OEM Part Number: 48510-B1130, 48510-B1140
  • Front Left OEM Part Number: 48520-B1130, 48520-B1140
  • Rear OEM Part Number: 48531-B1090
  • Platform Sharing: Component configuration shares architectural commonality with the Daihatsu Boon Luminas, Toyota Avanza, and Perodua Alza platforms. [1, 2]

Toyota Wish Model 2015 Steering Rack

KSh18,000.00
Part Numbers & Identification
  • OEM Part Number (Standard 2WD - ZGE20G / ZGE21G): 45510-68020, 45510-68021
  • OEM Part Number (4WD - ZGE25G / ZGE25W): 45510-68051
  • Chassis Platform Base: Toyota New MC Platform (Shared profile elements with the Toyota Isis ZGM10G)
  • Chassis Layout Codes: DBA-ZGE20G, DBA-ZGE20W, DBA-ZGE21G, DBA-ZGE25G
  • Compatible Engine Platforms: 1.8L 2ZR-FAE I4, 2.0L 3ZR-FAE I4 [1, 2]
System Specifications
  • Operating Mode: Manual Gear-type Rack / Column-Assisted Electric Power Steering (EPS)
  • Steering Gear Type: Rack and Pinion
  • Input Shaft Pinion Configuration: Toothed spline connection
  • Input Shaft Spline Count: 36 Teeth
  • Input Shaft Diameter: 17.4 mm
  • Input Shaft Pinion Height: 43 mm
  • Overall Assembly Length: ~952 mm (Standard baseline chassis tracking width)
  • Rack End Lock Nut Thread Fitment: M15 x 1.5
  • Housing Construction: Light-weight die-cast Aluminum alloy casing with high-tensile carbon steel internal rack gear teeth

Toyota Corolla AE100 Steering Rack

KSh20,000.00
Part Numbers & Identification
  • OEM Part Numbers (RHD - Right Hand Drive): 44250-12480, 44250-12620, 44250-12180, 44250-12181
  • OEM Part Numbers (LHD - Left Hand Drive): 44250-02010, 44250-12400, 44250-12560, 44250-12232
  • Chassis Compatibility: AE100, AE101, EE100, CE100 (Corolla Sedan, Ceres, FX Hatchback, and Wagon variants)
  • Associated Engine Platforms: 1.5L 5A-FE, 1.6L 4A-FE / 4A-GE, 1.3L 2E / 4E-FE, 2.0L 2C Diesel [1, 2, 3, 4]
System Specifications
  • Operating Mode: Hydraulic Power Assisted Steering (HPS)
  • Steering Gear Type: Rack and Pinion
  • Total Assembly Length: ~1045 mm – 1050 mm (excluding outer tie rod ends)
  • Input Shaft configuration: 36-spline configuration
  • Input Shaft Diameter: 17.5 mm
  • Inner Tie Rod (Rack End) Thread Size: M14 x 1.5
  • Outer Tie Rod End Thread Size: M12 x 1.25
  • Hydraulic Pressure Port Thread (Inlet): M14 x 1.5 flare nut
  • Hydraulic Return Port Thread (Outlet): M16 x 1.5 flare nut
  • Main Housing Material: Die-cast Aluminum alloy cylinder body with structural steel rack shaft

Toyota Passo Steering Rack

KSh9,000.00
Part Numbers & Identification
  • OEM Part Number (1st Gen - KGC10/QNC10): 45510-B1020
  • OEM Part Number (2nd Gen - NGC30/KGC30): 45502-B1094
  • OEM Part Number (Alternative Cross-References): 45502-B1010, 45502-B1012, 45502-B1020
  • Vehicle Compatibility: Toyota Passo (also shares assembly layout with Daihatsu Boon / Sirion)
  • Drive Configuration: Right-Hand Drive (RHD) [1, 2, 3]
System Specifications
  • Operating Mode: Electric Power Steering (EPS) / Manual Gear-type Rack (Assistance is managed via a column-mounted motor EPS system rather than a hydraulic rack)
  • Steering Gear Type: Rack and Pinion
  • Housing Material: Cast Aluminum and Structural Iron
  • Steering Rack End Thread Size: M14
  • Tie Rod End Thread Size: M12 x 1.25 [1, 2, 3]

Toyota Markx GRX 130 Front Wheel Hubs

KSh6,500.00
Part Identification & Cross-References
  • OEM Right (Passenger Side) Part Number: 43550-30010, 43550-30011, 43550-30020
  • OEM Left (Driver Side) Part Number: 43560-30010, 43560-30011
  • Aftermarket Substitutes: KOYO 3DACF027F-8BS, FEBEST 0182-XFRH
  • Platform Compatibility: Rear-Wheel Drive (2WD) chassis codes ONLY (GRX130 2.5L and GRX133 3.5L models). (Note: GRX135 4WD models use a different front hub profile to accommodate an outboard CV axle stub shaft).
Physical & Structural Dimensions
  • Assembly Type: Generation 3 Complete Bolt-on Hub Unit (fully sealed double-row angular contact ball bearing pre-assembled to the mounting flange).
  • Wheel Bolt Pattern (PCD): 5 x 114.3 mm (5 x 4.5 inches)
  • Hub Center Bore Diameter: 60.1 mm
  • Flange Outer Diameter: 140 mm
  • Wheel Stud Specification: M12 x 1.5 threaded studs (5 per hub)
  • ABS Integration: Internal magnetic encoder ring built into the inner bearing race dust seal (accessible via a dedicated sensor channel on the steering knuckle frame).
  • Total Component Weight: ~4.90 kg (10.8 lbs)
Tightening Torque Specifications
  • Hub Assembly-to-Steering Knuckle Mounting Bolts (4x): 51 ft-lbs (69 N·m)
  • Brake Caliper Mounting Bracket-to-Knuckle Bolts: 58 ft-lbs (79 N·m)
  • Front Wheel Lug Nuts: 76 ft-lbs (103 N·m)

Toyota Markx GRX 120 Front Wheel Hubs

KSh6,500.00
Part Identification & Interchanges
  • OEM Right (Passenger Side) Part Number: 43550-30010, 43550-30011
  • OEM Left (Driver Side) Part Number: 43560-30010, 43560-30011
  • Alternative Brand Interchanges: KOYO 3DACF027F-8BS, SKF VKBA 6953, FeBest 0182-XFRH
  • Platform Shared Fitments: Toyota Crown (GRS180), Lexus GS300/GS350 (GRS190/GWS191), Lexus IS250/IS350 (GSE20/GSE21) (Note: Specifications listed are strictly for Rear-Wheel Drive (2WD) models). [1, 2, 3]
Physical & Dimensional Specifications
  • Assembly Construction Type: Flanged hub unit with an integrated, sealed double-row angular contact ball bearing assembly
  • Outer Diameter (Flange): 140 mm
  • Wheel Bolt Pattern (PCD): 5 x 114.3 mm (5 x 4.5 inches)
  • Wheel Stud Bolt Thread Pitch: M12 x 1.5
  • Number of Rim Mounting Holes: 5
  • Brake Sensor Integration: Built-in internal magnetic encoder wheel with a dedicated port for the ABS wheel speed sensor wiring harness. [1, 2]
Tightening Torque Specifications
  • Hub Assembly-to-Steering Knuckle Mounting Bolts (4x): 51 ft-lbs (69 N·m)
  • Brake Caliper Mounting Bracket-to-Knuckle Bolts: 58 ft-lbs (79 N·m)
  • Front Wheel Lug Nuts: 76 ft-lbs (103 N·m)

Toyota Wish Steering Rack

KSh15,000.00
OEM Part Numbers
  • First Generation (ZNE10G / ANE10G / ANE11W): 45510-68010
  • Second Generation (ZGE20G / ZGE20W / ZGE21G): 45510-68020 / 45510-68021 / 45510-68030 / 45510-68041
Dimensional Specifications
  • Overall Component Length: ~952 mm
  • Input Shaft Pinion Height: 43 mm
  • Input Shaft Pinion Diameter: 17.4 mm
  • Input Shaft Spline Count: 36 teeth
  • Tie Rod / Inner Socket Thread Size: M16 x 1.5
System Performance & Mechanics
  • Steering Mechanism Type: Conventional Mechanical Rack and Pinion (Note: Power assist is provided via an external column-mounted Electronic Power Steering (EPS) motor setup on ZGE20 models, meaning the rack itself contains no internal hydraulic fluid passages).
  • Total Lock-to-Lock Turns: 2.88 turns
  • Primary Manufacturer Reference: NSK / Toyota Genuine
  • Net Unit Weight: 6.6 kg (bare assembly) to 8.0 kg (packaged with inner tie rods installed). [1, 2, 3, 4]
Material Composition
  • Main Housing Gear Body: Die-cast structural aluminum alloy.
  • Internal Rack & Pinion Gears: Carbon-hardened forged steel.
  • Dust Boots / Bellows: High-flexibility Chloroprene / Nitrile rubber compound. [1]

Toyota Markx GRX 130 X Japan Shocks

KSh5,000.00
System Configurations & Variants
  • Standard Suspension (Gas Type): Uses conventional twin-tube hydraulic gas-pressurized dampers.
  • AVS / Electric Dampers: Premium grades (e.g., 250G S-Package, Premium) utilize an Adaptive Variable Suspension (AVS) electronic damping system. These feature an actuator mounting bracket on top of the shaft to change internal valving dynamically. [1, 2, 3, 4]
OEM / KYB Part Numbers
  • Front Axle Assembly:
    • Standard (Left/Right): 48510-22B20 / 48520-22B20
    • Electronic / AVS (KYB OE Eco-Line): 721001 (Front RH) and 721002 (Front LH) [1]
  • Rear Axle Assembly:
    • Standard (Left/Right): 48530-22680 / 48540-22680
    • Electronic / AVS (KYB OE Eco-Line): 721003 (Rear Universal) [1]
Dimensional & Mounting Specifications
  • Design Profile: MacPherson Strut equivalent configuration for the Front (Double Wishbone integration) and an Eye-to-Pin/Pin-Bottom style Shock for the Multi-link Rear.
  • Upper Shaft Stem Thread: M10 x 1.25 mm (Standard) / M12 configuration for localized AVS stepper-motor engagement caps.
  • Upper Mounting Nut Torque Spec: 25 N·m (255 kgf·cm)
  • Lower Installation Bolt Size: M14 (Front lower clevis mount to lower arm; Rear lower eyelet mount to carrier). [1, 2, 3, 4]
Damping & Spring Calibration (KYB Reference)
  • Damping Medium: High-pressure Nitrogen gas (N₂) paired with premium multi-grade all-weather fluid to combat cavitation. [1]
  • Factory-Matched Spring Rates (KYB Extage Reference):
    • Front Spring Rate: 52.9 N/mm (5.4 kg/mm)
    • Rear Spring Rate: 58.3 N/mm (6.0 kg/mm)[1]

Toyota Mark X GRX 120 Ex-Japan Shocks

KSh5,000.00
Internal Technology & Damping Profile
  • Front Shock Internal Design: Double-acting, Gas-charged High-Pressure Twin-Tube Strut Architecture.
  • Rear Shock Internal Design: Heavy-duty, Gas-charged Monotube Damper Assembly. [1, 2]
  • Damping Medium: Nitrogen gas (N₂) combined with multi-grade all-weather hydraulic fluid to reduce aeration and fade during hard cycling.
  • Standard Operating Valence: Velocity-sensitive valving engineered to maintain vehicle stability under high-speed cornering while preserving classic executive rear-wheel-drive (RWD) highway comfort.
Part Numbers & Aftermarket Cross-Reference
  • Front Axle OEM Part Numbers (Toyota / JDM Factory):
    • Right Hand (RH): 48510-80160, 48510-80161, 48510-22A00, 48510-22A40, 48510-80403
    • Left Hand (LH): 48520-29845, 48520-29855, 48520-80045, 48520-80126 [1, 2, 3]
  • Rear Axle OEM Part Numbers (Toyota / JDM Factory): 48530-80397, 48530-22620, 48530-22510 [1]
  • KYB (Kayaba) Aftermarket Reference Numbers (JDM Gas-A-Just / Excel-G):
    • Front Right Hand (RH): 551112
    • Front Left Hand (LH): 551113
    • Rear Axle (Universal LH/RH): 551120 [1, 2, 3, 4, 5]
Chassis, Platform & Fitment Compatibility
  • Chassis Range: Toyota S180 Platform (Rear-Wheel Drive luxury configuration).
  • Target Model Codes: GRX120 (2.5L 250G variants) and GRX121 (3.0L 300G variants).
  • Platform Architecture Sharing: Swaps identical structural dimensions, lower clevis mounts, upper rod threads, and mounting stroke geometry with the JDM Toyota Crown (GRS180, GRS182, GRS200) and Lexus IS/GS series of the same production era.
  • Fitment Exclusion: GRX125 (4WD) models use specific front differential layout cutouts and unique stroke lengths; standard GRX120 front struts do not bolt onto 4WD spindles. [1, 2, 3, 4]
Component Sizing & Interface Layout
  • Front Lower Mounting Clevis: Eye-joint bracket configured to mate directly to the front double-wishbone lower control arm pivot.
  • Rear Lower Mounting Bushing: Integral metal sleeve insulated by a vulcanized, high-durometer rubber bushing.
  • Piston Rod Configuration: Micro-smooth chrome-plated piston rods featuring factory integrated hard stops to prevent bottoming out against the upper seat assembly.
  • AVS Note: Non-electronic variations use a standard manual threaded piston rod tip; models equipped with Toyota’s Adaptive Variable Suspension (AVS) use a hollow-top rod profile to insert the electronic actuator control pin.

Toyota Passo Model 2017 Engine Mountain

KSh4,000.00
1. Mechanical Layout & Component Breakdown
The 2017 model utilizes a revised three-point engine containment layout optimized for the newer high-efficiency powertrain:
  • Right-Hand Mount (Front Right / Engine Side):
    • OEM Part Numbers: 12305-B1140 / 12305-B1220
    • Function: Primary weight-bearing stabilizer. It anchors the cylinder block to the right body rail frame and absorbs structural engine vibration.
  • Left-Hand Mount (Front Left / Transmission Side):
    • OEM Part Numbers: 12306-B1130 / 12306-B1131
    • Function: Gearbox casing insulator. It isolates noise and absorbs shifting torque from the Continuous Variable Transmission (CVT).
  • Rear Torque Rod (Lower Engine Stabilizer):
    • OEM Part Numbers: 12309-B1080 (Rod) and 12321-B1050 / 12321-B1070 (Bracket)
    • Function: Lower control torque rod. Connects directly to the front suspension cross-member to limit back-and-forth structural rocking during acceleration and deceleration.
2. Vehicle Structural Fitment
  • Engine Installation: Transverse alignment (East-West layout)
  • Chassis & Powertrain Compatibility:
    • M700A: 1.0L 3-cylinder Petrol (1KR-FE), Front-Wheel Drive (FWD)
    • M710A: 1.0L 3-cylinder Petrol (1KR-FE), All-Wheel Drive (AWD)
3. Material Specifications
  • Core Material: Heavy-duty vulcanized natural rubber formulation chemically bonded to a lightweight, reinforced cast aluminum casing and stamped steel base bracket assembly.
  • Damping Classification: Passive, solid-core high-absorption elastomeric system tailored to control 3-cylinder idle harmonics.

Toyota Passo Model 2012 Engine Mountain

KSh4,000.00
1. Mechanical Layout & Component Breakdown
The 2012 model features a structural, multi-point isolation configuration split into three key positions to absorb vibration:
  • Right-Hand Mount (Front Right / Engine Side):
    • OEM Part Numbers: 12305-B1050 / 12305-B1051 / 12305-B1052
    • Function: Weight-bearing insulator assembly. Anchors the primary engine block structure to the right chassis frame rail. [1]
  • Left-Hand Mount (Front Left / Transmission Side):
    • OEM Part Numbers: 12306-B1030 / 12306-B1050
    • Function: Transmission casing insulator. Controls rotational torque loads generated through the drivetrain and transaxle.
  • Rear Torque Rod (Lower Engine Stabilizer):
    • OEM Part Numbers: 12309-B1060 (Rod Assembly) and 12321-B1040 (Mounting Bracket)
    • Function: Control link rod. Mounted directly to the vehicle lower cross-member subframe to constrain back-and-forth structural "rocking" or pitching during sudden throttle inputs. [1, 2]
2. Vehicle Structural Fitment
  • Engine Installation: Transverse alignment (East-West configuration)
  • Chassis & Powertrain Compatibility:
    • KGC30: 1.0L 3-cylinder Petrol (1KR-FE), Front-Wheel Drive (FWD)
    • KGC35: 1.0L 3-cylinder Petrol (1KR-FE), All-Wheel Drive (AWD)
    • NGC30: 1.3L 4-cylinder Petrol (1NR-FE), Front-Wheel Drive (FWD) [1, 2, 3]
3. Material Specifications
  • Core Material: Vulcanized natural rubber compound bonded to a stamped carbon steel and reinforced iron casting frame casing.
  • Damping Classification: Standard solid-core passive elastomeric rubber setup.

Toyota Passo Model 2013 Engine Mountain

KSh4,000.00
1. Mechanical Layout & Component Breakdown
The 2013 model employs a multi-point containment design to manage powertrain vibration, divided into three core positions: [1, 2]
    • Right-Hand Mount (Engine Side):
        • OEM Part Numbers: 12305-B1080 / 12305-B1050 / 12305-B1100
        • Function: Primary weight-bearing insulator assembly. Supports the cylinder block casing and dampens structural vibrations. [1, 2]
    • Left-Hand Mount (Gearbox / Transmission Side):
        • OEM Part Numbers: 12306-B1050 / 12306-B1080
        • Function: Gearbox housing insulator. Absorbs longitudinal and lateral loads generated during gear changes or CVT ratio shifts. [1, 2]
    • Rear Torque Rod (Lower Stabilization Link):
        • OEM Part Numbers: 12309-B1060 (Rod) and 12321-B1040 (Rear Bracket)
        • Function: Moving control torque rod. Attaches directly to the lower subframe to limit back-and-forth structural "rocking" under acceleration and braking. [1, 2, 3]
2. Vehicle Structural Fitment
    • Engine Installation: Transverse alignment (East-West layout)
    • Chassis Codes Covered:
        • KGC30: 1.0L 3-cylinder Petrol (1KR-FE), Front-Wheel Drive (FWD)
        • KGC35: 1.0L 3-cylinder Petrol (1KR-FE), All-Wheel Drive (AWD)
        • NGC30: 1.3L 4-cylinder Petrol (1NR-FE), Front-Wheel Drive (FWD) [1, 2]
3. Material Specifications
  • Core Material: High-elasticity natural rubber vulcanized directly onto stamped sheet steel and cast iron base frames.
  • Damping Classification: Passive, high-damping solid elastomeric rubber design (non-hydraulic setup for standard 1.0L configurations).

Toyota Passo Model 2014 Engine Mountain

KSh4,000.00
1. Component Breakdown & OEM Part Numbers
The 2014 Toyota Passo utilizes a multi-point engine isolation setup: [1]
    • Right-Hand Mount (Front Right / Engine Side):
        • Part Number: 12305-B1110 (or 12305-B1052 depending on market frame)
        • Function: Primary insulator sub-assembly engine mounting RH. Holds engine weight and dampens rotational torque. [1, 2]
    • Left-Hand Mount (Front Left / Transmission Side):
        • Part Number: 12306-B1090 (or 12306-B1030 alternate code)
        • Function: Insulator sub-assembly engine mounting LH. Secures the gearbox housing to the frame. [1, 2]
    • Rear Torque Rod (Lower Engine Mount):
        • Part Number: 12309-B1110
        • Function: Rod sub-assembly engine moving control. Constrains the "pitching" or rocking motion of the engine during acceleration and gear shifts. [1]
2. Vehicle Structural Fitment
    • Engine Orientation: Transverse (East-West installation) [1]
    • Chassis Compatibility:
        • KGC30: 1.0L Petrol, FWD layout
        • KGC35: 1.0L Petrol, AWD layout
        • NGC30: 1.3L Petrol, FWD layout [1]
3. Material Specifications
    • Composition: High-damping natural rubber bonded to heavy-gauge stamped steel base frames.
    • Design Type: Solid rubber bushing inserts enclosed in cast/stamped metal brackets (non-hydraulic/passive dampening system).

Toyota Passo Model 2015 Engine Mountain

KSh4,000.00
Engine & Performance Specifications
    • Engine Model: 1KR-FE (Alternatively available with the 1.3L 1NR-FE)
    • Displacement: 996 cc (1.0 Litre)
    • Cylinder Configuration: Inline 3-cylinder, 12-Valve
    • Valvetrain: DOHC (Double Overhead Camshaft)
    • Bore × Stroke: 71.0 mm × 83.9 mm
    • Compression Ratio: 11.5:1 (Upgraded in 2014 for higher thermal efficiency)
    • Maximum Power Output: 69 PS (51 kW) @ 6,000 RPM
    • Maximum Torque: 92 N·m (9.4 kg·m) @ 4,400 RPM [1, 2, 3, 4, 5, 6]
Drivetrain & Transmission
    • Transmission Type: Continuously Variable Transmission (CVT) [1, 2]
    • Drive System Configurations:
        • 2WD / Front-Wheel Drive (Chassis Model: KGC30)
        • 4WD / All-Wheel Drive (Chassis Model: KGC35) [1, 2, 3]
Engine Mounting Setup (Physical Mounts)
  • Mounting Configuration: 3-Point Insulator Isolation Setup [1]
  • Right-Hand (RH) Mount: Hydraulic (Fluid-filled) Insulator assembly to absorb 3-cylinder engine idling vibrations (OEM Base Part No: 12305). [1, 2]
  • Left-Hand (LH) Mount: Transmission-side rubber insulator bracket assembly (OEM Base Part No: 12306). [1]
  • Rear (RR) Mount: Engine moving control rod/rear structural engine stay to limit longitudinal engine twisting during acceleration (OEM Base Part No: 12380 / 12309). [1]

Toyota Passo Model 2018 Engine Mountain

KSh4,000.00
Engine & Performance Specifications
  • Engine Model: 1KR-FE
  • Displacement: 996 cc (1.0 Litre)
  • Cylinder Configuration: Inline 3-cylinder, 4-cycle
  • Valvetrain: DOHC (Double Overhead Camshaft)
  • Bore × Stroke: 71.0 mm × 83.9 mm
  • Maximum Power Output: 69 PS (51 kW) @ 6,000 RPM
  • Maximum Torque: 92 N·m (9.4 kg·m) @ 4,400 RPM
  • Fuel Type: Petrol [1, 2, 3, 4, 5, 6]
Drivetrain & Transmission
  • Transmission Type: Continuously Variable Transmission (CVT) [1, 2]
  • Drive System Options:
    • 2WD / Front-Wheel Drive (Chassis Model: M700A)
    • 4WD / All-Wheel Drive (Chassis Model: M710A) [1, 2, 3]
Fuel & Capacity
  • Fuel Tank Capacity: 36 to 38 Litres
  • Average Fuel Efficiency: Approximately 20.0 km/L to 24.0 km/L depending on driving conditions

Toyota fielder Model 2015-2010 Lower Control Arms

KSh4,000.00
Toyota Corolla Fielder (2010–2015) Lower Control Arm Technical Specifications
The Toyota Corolla Fielder spanning the 2010–2015 timeline transitions across two structural generations: the Late E140 Series (2010–2012) and the Early E160 Series (2012–2015). Both generations utilize an L-shaped MacPherson strut lower wishbone arm matrix, but they feature distinct factory part configurations and physical bushing dimensions. [1, 2, 3, 4]
1. E140 Series Fielder (2010–2012 Production)
  • Chassis System Codes: NZE141G, NZE144G (4WD), ZRE142G, ZRE144G (4WD) [1]
  • Right Hand (RH) Control Arm OEM: 48068-12300 / 48068-12290 [1, 2]
  • Left Hand (LH) Control Arm OEM: 48069-12300 / 48069-12290 [1, 2]
  • Dimensional Parameters & Bushings:
    • Forward Pivot Bolt Sleeve ID: 14.2 mm
    • Rear Large Bushing Outer Diameter (OD): 65.2 mm
    • Bushing Component Component Refs: Small Front Bushing (48654-12150 / RU-494); Large Rear Bushing (48655-12120 / RU-495 / TAB-145).
2. E160 Series Fielder (2012–2015 Production)
  • Chassis System Codes: NZE161G, NZE164G (4WD), NRE161G, NKE165G (Hybrid Wagon) [1, 2]
  • Right Hand (RH) Control Arm OEM: 48068-59135 / 48068-59145 [1, 2]
  • Left Hand (LH) Control Arm OEM: 48069-59135 / 48069-59145 [1, 2]
  • Bushing Configuration Specs:
    • Features a redesigned low-profile stamped frame geometry to decrease vehicle curb weight on the E160 platform.
    • Pressed Elastomeric Bushing Ref: RU-519 (Masuma tracking variant).
    • Ball Joint Compatibility Ref: MB-3602 (Features specialized dust boot configuration MO-2112). [1, 2]
3. Engineering Material & Layout Layout Specs
  • Structural Frame Shell: Robotic-welded heavy-gauge stamped carbon steel sheet matrix. [1]
  • Pivot Configuration: 3-Point multi-axis movement tracking (Inner front horizontal rubber bush, inner rear vertical trailing bush, and outer ball joint knuckle receptacle). [1]
  • Drivetrain Variance (2WD vs 4WD): 4WD platforms (NZE144G / NZE164G) utilize alternative bushing durometer tolerances along the inner sleeves to absorb transfer-case counter-shudder, despite sharing spatial geometries with FWD counterparts.[1, 2]

Toyota Nze Lower Control Arms

KSh4,000.00
Toyota Corolla NZE Series Front Lower Control Arm Technical Specifications
The front lower control arms for the Toyota Corolla NZE series (predominantly the NZE121 and NZE141 chassis generations, matching the 1.5L 1NZ-FE platform) utilize a conventional L-shaped MacPherson strut lower wishbone architecture. This assembly establishes a structural connection between the lower steering knuckle and the vehicle’s main engine subframe crossmember. [1, 2, 3]
1. E120 Generation NZE Series (Production 2000–2006)
  • Chassis Codes Covered: NZE121, ZZE122, CZE121 [1, 2]
  • Right Hand (RH) Front Lower Control Arm OE: 48068-20400 / 48068-12220 [1, 2]
  • Left Hand (LH) Front Lower Control Arm OE: 48069-20400 / 48069-12220 [1, 2]
  • Structural Material: Stamped structural carbon sheet steel. [1, 2]
  • Bushing Internal Steel Sleeve Dimensions:
    • Forward Horizontal Pivot Sleeve (Inner Diameter): 14.2 mm (Matches M14 alignment fasteners).
    • Rear Vertical Trailing Bush Sleeve (Inner Diameter): 14.5 mm
  • Pressed Elastomeric Sub-Components:
    • Small Front Bushing Ref: 48654-12120 / RU-357 (Dimensions: 14.2mm ID × 39.0mm OD × 59.0mm Length)
    • Large Rear Bushing Ref: 48655-12170 / RU-385 / TAB-026 (Dimensions: 14.5mm ID × 68.5mm OD × 60.0mm Length) [1]
  • Platform Sharing / Cross-Compatibility: Interchanges directly with the Toyota Allion/Premio (240 series), Toyota Wish (10 series), and the Toyota Matrix (ZZE130). [1, 2]
2. E140 Generation NZE Series (Production 2007–2012)
  • Chassis Codes Covered: NZE141 (Axio / Fielder variants) [1, 2]
  • Right Hand (RH) Front Lower Control Arm OE: 48068-12300 / 48068-12290 [1, 2]
  • Left Hand (LH) Front Lower Control Arm OE: 48069-12300 / 48069-12290 [1]
  • Component Weight: Approximately 3.15 kg per side assembly.
  • Bushing Internal Steel Sleeve Dimensions:
    • Forward Horizontal Pivot Sleeve (Inner Diameter): 14.2 mm
    • Rear Vertical Trailing Bush Sleeve (Inner Diameter): 14.4 mm
  • Pressed Elastomeric Sub-Components:
    • Small Front Bushing Ref: 48654-12150 / RU-494 (Dimensions: 14.2mm ID × 38.2mm OD × 61.0mm Length)
    • Large Rear Bushing Ref: 48655-12120 / RU-495 / TAB-145 (Dimensions: 14.4mm ID × 65.2mm OD × 55.0mm Length)
3. Structural Alignment & Geometry Overview
  • Mounting Interface Layout: 3-Point multi-axis tracking (Inner forward horizontal bushing + Inner rear vertical bush + Outer steering knuckle ball joint receiver flange).
  • Elastomeric Compound Type: High-durometer vulcanized natural rubber (NR) bonded inside steel backing sleeves. [1, 2, 3]

Toyota Axio Model 2007-2012 Lower Control Arms

KSh4,000.00
Toyota Corolla Axio (2007–2012) Lower Control Arm Technical Specifications
The front lower control arms for the E140 generation Toyota Corolla Axio (chassis codes: NZE141, NZE144 [4WD], ZRE142, ZRE144 [4WD], production range 2007–2012) feature a conventional L-shaped MacPherson strut lower wishbone architecture. This assembly structurally joins the lower steering knuckle to the vehicle's engine crossmember subframe.
1. Core Part Identification & OEM Numbers
  • Right Hand (RH) Front Lower Control Arm:
    • 48068-12300 (Primary factory baseline number)
    • Interchangeable Structural Refs: 48068-02140, 48068-12290, 48068-02160
  • Left Hand (LH) Front Lower Control Arm:
    • 48069-12300
    • Interchangeable Structural Refs: 48069-02140, 48069-12290, 48069-02160
  • Component Weight: Approximately 3.15 kg per side (complete stamped shell assembly with bushings pressed).
2. Dimensional & Physical Parameters
  • Structural Frame Material: Stamped heavy-gauge cold-rolled structural carbon steel plate.
  • Chassis Attachment Layout: 3-Point orientation (Inner forward horizontal bushing + Inner rear vertical trailing bushing + Outer steering knuckle ball joint receiver flange).
  • Bushing Internal Steel Sleeve Dimensions:
    • Forward Horizontal Bolt Sleeve (Inner Diameter): 14.2 mm (Engineered to receive an M14 pivot bolt)
    • Rear Vertical Trailing Bush Sleeve (Inner Diameter): 14.4 mm
  • Rear Large Bushing Outer Barrel Diameter (OD): 65.2 mm
  • Rear Large Bushing Metal Casing Height: 55.0 mm
3. Elastomeric Component & Bushing Specifications
  • Material Compound: High-durometer vulcanized natural rubber (NR) bonded inside carbon steel inner and outer backing sleeves.
  • Bushing Sub-Components (For Independent Pressing/Rebuilds):
    • Small Front Bushing Ref: 48654-12150 / RU-494 (Dimensions: 14.2mm ID × 38.2mm OD × 61.0mm Length)
    • Large Rear Bushing Ref: 48655-12120 / RU-495 / TAB-145 (Dimensions: 14.4mm ID × 65.2mm OD × 55.0mm Length)
4. Drivetrain & Platform Cross-Compatibility
  • 2WD vs. 4WD Architecture: 2WD models (NZE141, ZRE142) share identical base control arms. 4WD models (NZE144, ZRE144) utilize alternative rear bushing durometers to mitigate drivetrain twist from the transfer case, though the physical arm geometry remains interchangeable.
  • Platform Sharing: The E140 Axio lower control arm shares an identical structural chassis footprint with the Toyota Corolla Fielder (E140), Toyota Auris (E150), and Toyota Blade (E150) variations of the same production era.

Toyota Allion 240 Lower Control Arms

KSh4,000.00
Toyota Allion 240 Series Lower Control Arm Technical Specifications
The front lower control arms for the first-generation Toyota Allion 240 series (chassis codes: NZT240, ZZT240, AZT240, ZZT245 [4WD], production range 2001–2007) utilize an L-shaped MacPherson strut lower wishbone architecture. This assembly structurally joins the front steering knuckle to the main engine crossmember subframe.
1. Core Part Identification & OEM Numbers
  • Right Hand (RH) Front Lower Control Arm:
    • 48068-20400 (Primary factory baseline number)
    • Interchangeable Structural Refs: 48068-02050, 48068-12220, 48068-0M010
  • Left Hand (LH) Front Lower Control Arm:
    • 48069-20400
    • Interchangeable Structural Refs: 48069-02050, 48069-12220, 48069-0M010
  • Component Weight: Approximately 3.39 kg per side (complete stamped assembly with bushings pressed).
2. Dimensional & Physical Parameters
  • Structural Frame Material: Stamped heavy-gauge cold-rolled carbon sheet steel.
  • Chassis Attachment Layout: 3-Point orientation (Inner forward horizontal bushing + Inner rear vertical trailing bushing + Outer steering knuckle ball joint receiver).
  • Bushing Internal Steel Sleeve Dimensions:
    • Forward Horizontal Bolt Sleeve (Inner Diameter): 14.2 mm (Engineered for an M14 pivot bolt)
    • Rear Vertical Trailing Bush Sleeve (Inner Diameter): 14.5 mm
  • Rear Large Bushing Outer Barrel Diameter (OD): 68.5 mm
  • Rear Large Bushing Metal Casing Height: 59.2 mm
3. Elastomeric Component & Bushing Specifications
  • Material Compound: High-durometer vulcanized natural rubber (NR) bonded to carbon steel inner and outer sleeves.
  • Bushing Sub-Components (For Independent Pressing/Rebuilds):
    • Small Front Bushing Ref: 48654-12120 / RU-357 (Dimensions: 14.2mm ID × 39.0mm OD × 59.0mm Length)
    • Large Rear Bushing Ref: 48655-12170 / RU-385 / TAB-026 (Dimensions: 14.5mm ID × 68.5mm OD × 60.0mm Length)
4. Platform Cross-Compatibility
  • The T240 Allion lower control arm shares an identical structural chassis footprint and geometry with the Toyota Premio (T240), Toyota Wish (ANE10/ZNE10), Toyota Corolla (NZE121/ZZE122), and the Toyota Matrix/Voltz (ZZE130) platform variations of the same production era.
Showing 28 of 180 results
Please select your product
Product has been added to your cart
Compare (0)
